| Ref | Part Number | Description |
|---|
| 2 |
82-5780 |
CAP-THREAD Price: $94.64 |
| 3 |
82-5770 |
ROD Price: $244.95 |
| 6 |
82-5790 |
HEAD-CAP, THREAD Price: $279.42 |
| 13 |
82-5760 |
PISTON Price: $211.58 |
| 14 |
82-5750 |
NUT-LOCK, ELASTIC Price: $9.02 |
| 16 |
82-5740 |
NUT-JAM Price: $29.95 |
| 17 |
82-5730-01 |
END-ROD, TIE This part replaces 82-5730. Price: $310.82 |
| 18 |
32121-44 |
PIN-ROLL Price: $0.47 |
| 506538501 |
506538501 |
Arm Price: $22.27 |
| 506538601 |
506538601 |
Bracket Price: $18.98 |
| 506538701 |
506538701 |
Button Price: $7.95 |
| 506538801 |
506538801 |
Pin Price: $7.33 |
| 506538901 |
506538901 |
Spring Price: $3.61 |
| 506556002 |
506556002 |
SCREW Price: $5.99 |
| 506570103 |
506570103 |
BOLT Price: $3.99 |
| 506576301 |
590735401 |
Brackets This part replaces 506576301. Price: $12.99 |
| 506576401 |
506576401 |
RETAINER Price: $4.99 |
| 506594601 |
506594601 |
Center Panel Price: $85.78 |
| 506597401 |
506597401 |
BOLT Price: $5.99 |
| 506597501 |
506597501 |
WASHER Price: $6.99 |
| 506664501 |
506664501 |
BELT GUIDE Price: $19.99 |
| 506670801 |
506670801 |
CONNECTOR Price: $6.99 |
| 506671901 |
506671901 |
SPRING Price: $22.99 |
| 506673301 |
506673301 |
FUEL CAP Price: $27.99 |
| 506769601 |
506769601 |
FUEL TANK Price: $64.99 |
| 506769701 |
506769703 |
BRACKET This part replaces 506769701. Price: $24.77 |
| 506769801 |
506769803 |
BRACKET This part replaces 506769801. Price: $24.77 |
| 506775601 |
535482201 |
PULLEY This part replaces 506775601. Price: $64.99 |
| 506775701 |
506775701 |
WASHER Price: $4.99 |
| 506776401 |
506776401 |
BELT GUIDE Price: $59.99 |
| 506819201 |
506819201 |
WHEEL AXLE Price: $50.38 |
| 506862101 |
506862101 |
NUT Price: $7.99 |
| 506892001 |
506892001 |
NUT Price: $7.99 |
| 506913701 |
506913701 |
Cover Price: $59.94 |
| 506913801 |
506913801 |
COVER Price: $44.99 |
| 506913901 |
506969501 |
COVER This part replaces 506913901. Price: $19.99 |
| 506917604 |
506917604 |
CHASSIS Price: $773.99 |
| 506939001 |
535482401 |
PULLEY This part replaces 506939001. Price: $69.99 |
| 506946702 |
506946702 |
HOSE Price: $24.02 |
| 506946801 |
506946801 |
Clip Price: $2.46 |
| 506954901 |
589538601 |
BELT This part replaces 506954901. Price: $27.99 |
| 506965701 |
506965701 |
Plug Price: $4.33 |
| 531005014 |
589530501 |
BELT This part replaces 531005014. Price: $37.99 |
| 531005017 |
589530601 |
BELT This part replaces 531005017. Price: $54.99 |
| 721618301 |
721618301 |
Split Pin Price: $1.99 |
| 725236461 |
725236461 |
SCREW Price: $2.99 |
| 725237051 |
725237071 |
SCREW This part replaces 725237051. Price: $3.99 |
| 725244951 |
725244951 |
BOLT - M8X16 Price: $2.99 |
| 729532971 |
729532971 |
Screw Price: $1.80 |
| 729541401 |
729541401 |
SCREW Price: $3.99 |
| 731232051 |
731232001 |
Nut This part replaces 731232051. Price: $3.99 |
| 732211601 |
732211601 |
LOCKNUT M6 Price: $4.99 |
| 732211801 |
732211801 |
LOCKNUT M8 Price: $3.99 |
| 734115301 |
734115301 |
Washer Price: $0.34 |
| 734115601 |
734181251 |
WASHER This part replaces 734115601. Price: $0.99 |
| 734116401 |
734116401 |
WASHER BRB 8.4X17 Price: $5.99 |
| 734116441 |
734116441 |
SPACER Price: $3.99 |
| 735313810 |
735313810 |
RETAINING RING Price: $2.99 |
| 735583501 |
735583501 |
CLIP Price: $12.99 |
| 738210404 |
738210404 |
BALL BEARING 6004-2RS1 Price: $9.99 |
