| Ref | Part Number | Description |
|---|
| 1 |
04001-59 |
SERR. FLG. HEX HEAD CAPSCREW, 5/16-18 X 3/4 Price: Call Us |
| 2 |
04019-02 |
NUT, 1/4-20 SERRATED FLANGE HEX HEAD Price: Call Us |
| 3 |
485831 |
Spring, Brake Return Price: Call Us |
| 4 |
462465 |
Brake Link Assembly Price: Call Us |
| 5 |
04001-54 |
Bolt, Hex Head 3/8-16 x 3" - 52" Price: Call Us |
| 6 |
43805 |
Spacer Price: Call Us |
| 7 |
48796 |
Bearing, Self Aligning - 5/8 I.D. Price: Call Us |
| 8 |
04117-02 |
Nut, Flange Elastic Stop Nut, 3/8-16 Price: Call Us |
| 9 |
452342 |
Brake Bellcrank Weldment Price: Call Us |
| 10 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 11 |
04020-26 |
Nut, 3/8-24 UNF-2B LH Thread Price: Call Us |
| 11 |
48544 |
Rod End, 3/8-24 LH Thread Female Price: Call Us |
| 11 |
485740 |
Brake Rod Assembly Price: Call Us |
| 12 |
48343-04 |
Clevis, Traction Control Price: Call Us |
| 13 |
04020-25 |
Nut, 3/8-24 UNF R.H. Thread Price: Call Us |
| 14 |
04069-01 |
Pin, Rue Cotter 3/8" Diameter Price: Call Us |
| 15 |
04064-02 |
Pin, Clevis 3/8-16 x 1-1/16" Price: Call Us |
| 16 |
452327 |
Brake Pedal Weldment Price: Call Us |
| 17 |
04001-194 |
Bolt, Hex Head 1/2-13 x 4-1/4" Price: Call Us |
| 18 |
04040-13 |
Flat Washer, 1/2 (.562 x 1.375 x .109) Price: Call Us |
| 19 |
423279 |
Plate Weldment, Motor Backing Price: Call Us |
| 20 |
483453-03 |
Bearing, Plastic Price: Call Us |
| 21 |
43872 |
Sleeve, Brake Pivot Price: Call Us |
| 22 |
04021-07 |
HEX LOCKNUT, ELASTIC STOP, 1/2-13 Price: Call Us |
| 23 |
426992 |
Switch Mounting Bracket, Brake Price: Call Us |
| 24 |
43602 |
Spacer, Pump Dampener Price: Call Us |
| 25 |
481638 |
Switch, Interlock, Normally Open Price: Call Us |
| 26 |
04003-02 |
Serr. Fl. Hex Head CPSCR, 1/4-20 x 3/4" Price: Call Us |
| 27 |
04001-54 |
Bolt, Hex Head 3/8-16 x 3" - 52" Price: Call Us |
| 28 |
04009-10 |
Bolt, Shoulder 1/2 x 3/8-16 x 2-3/4" Price: Call Us |
| 29 |
462808 |
Wheel Hub w/Disc Price: Call Us |
| 30 |
485595 |
Brake Caliper Price: Call Us |
| 31 |
04040-05 |
Flatwasher, 3/8 (.406 x .812 x .065) Price: Call Us |
| 32 |
04021-18 |
Nut, Elastic Stop 3/8-16, grade 8 black Price: Call Us |
| 33 |
484535 |
Spring, Brake Price: Call Us |
| 34 |
483453-23 |
Bearing Price: Call Us |
| 35 |
462452 |
Swivel Assembly, Brake Price: Call Us |
| 36 |
04061-02 |
Pin, Cotter 3/32 x .75" Price: Call Us |
| 37 |
04001-190 |
Bolt, Hex Head 1/2-13 x 2-3/4" (48V & 52V - One Weight) Price: Call Us |
| 38 |
04021-05 |
Bolt, Hex Head 3/8-16 x 1" Ser. Flg. Price: Call Us |
| 39 |
426983 |
Mounting Bracket, Brakes Price: Call Us |
| 40 |
04001-08 |
BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 3/4" Price: Call Us |
| 41 |
04021-19 |
Locknut, Hex 1/2-13 Center Lock Price: Call Us |
| 42 |
04001-12 |
Bolt, Hex Head 5/16-18 x 1-1/2" - Front Price: Call Us |
| 43 |
04021-08 |
HEX, NUT, ELASTIC STOP LOCK, 1/4-20 Price: Call Us |
| 44 |
04050-01 |
RETAINING RING, 5/8" EXTERNAL "E" Price: Call Us |
| 45 |
482102 |
Grip, Brake Handle Price: Call Us |
| 46 |
462820 |
Lever w/Grip, Parking Brake Price: Call Us |
| 47 |
04028-02 |
Wheel Nut, 1/2-20 x 13/16 Price: Call Us |
| 48 |
481659 |
Rim W/Valve Stem (48" & 52") Price: Call Us |
| 48 |
484104 |
Tire 24 x 9.5-12 (48" & 52" Deck) Price: Call Us |
| 48 |
484105 |
Wheel Assy 24 x 9.5-12 (52" Deck) Price: Call Us |
