| Ref | Part Number | Description |
|---|
| 1 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 2 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 2 |
531171101 |
SERVICE KIT AXLE HALF ASM This part replaces 532418168. Price: $59.99 |
| 3 |
131-4293 |
PIN PIVOT This part replaces 84-1350. Price: $27.48 |
| 4 |
53-6380 |
WASHER-FLAT Price: $8.62 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 5 |
3274-80 |
SCREW-HH Price: $1.76 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 6 |
106-1007 |
PIVOT ARM KIT This part replaces 84-0800. Price: $473.97 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
3218-18 |
NUT-JAM Price: $0.57 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
60-9870 |
SCREW-HH Price: $13.81 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
86-2070 |
NUT Price: $17.70 |
| 10 |
86-2080-01 |
JOINT-BALL This part replaces 86-2080. Price: $115.96 |
| 11 |
86-1440 |
WASHER-FLAT Price: $2.10 |
| 12 |
3220-6 |
NUT-JAM Price: $1.25 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
86-2560-03 |
SPRING-COMP This part replaces 86-2560. Price: $48.73 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
86-2650 |
SPRING-SUPPORT Price: $181.88 |
| 15 |
3272-9 |
PIN-COTTER Price: $0.20 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
32151-73 |
RING-CLIP Price: $2.59 |
| 16 |
587738903 |
KIT.SRVC.STEERINGSHAFT.3HISHFT This part replaces 585869202. Price: $44.99 |
| 17 |
86-2150 |
LOCK Price: $117.80 |
| 18 |
86-2090 |
BUSHING Price: $2.17 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
86-2120 |
ROLLER-LOCK Price: $25.12 |
| 20 |
283-61 |
PIN-YOKE This part replaces 86-2140. Price: $1.56 |
| 20 |
532441425 |
STEERING.BOOT.HUSQ.LT Price: $7.99 |
| 21 |
138-8239 |
PIN-CLEVIS This part replaces 86-2130. Price: $4.34 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 585029802. Price: $14.99 |
| 22 |
86-2180 |
BUSHING-FLANGE Price: $0.61 |
| 23 |
72-3790 |
DISCONTINUED Price: Call Us |
| 24 |
86-2680 |
MICRO SWITCH Price: $103.81 |
| 25 |
86-2680 |
MICRO SWITCH This part replaces 92-0631. Price: $103.81 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 26 |
92-0630 |
DISCONTINUED Price: Call Us |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 27 |
92-0628 |
DISCONTINUED Price: Call Us |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 33 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 45 |
596040001 |
Washers This part replaces 819113812. Price: $6.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
| 71 |
532190752 |
SHAFT.EXTEN.STRG.SPLINE Price: $11.99 |
| 72 |
596039701 |
Bolts This part replaces 532428982. Price: $3.99 |
| 74 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683701. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
