| Ref | Part Number | Description |
|---|
| 1 |
104-4620 |
SEAT This part replaces 92-1180. Price: $273.15 |
| 2 |
323-4 |
SCREW-HH Price: $1.02 |
| 2 |
532422027 |
SHAFT.ASM.CROSS.LIFT Price: $69.99 |
| 2 |
911-3179 |
ENGINE PULLEY SPACER This part replaces 711-3179. Price: $21.00 |
| 3 |
594018001 |
Levers This part replaces 532195231. Price: $17.99 |
| 3 |
703-1986A-0637 |
TORQUE BRACKET (POWDER BLACK) Not Available This part replaces 703-1986A. Price: |
| 3 |
75-4370-03 |
BRACKET-SEAT Price: $20.93 |
| 4 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 4 |
710-3030 |
SCREW 7/16-14X .750 GR5 Not Available Price: |
| 5 |
736-0407 |
Washer, Bell, .45 X 1.0 X .062 Thk Price: $3.64 |
| 5 |
92-8753 |
DISCONTINUED Price: Call Us |
| 6 |
3250-29 |
SCREW-PPH Price: $0.25 |
| 6 |
710-0151 |
Screw, Hex Cap, 3/8-24 X 2.00 Lg GR5 Price: $6.55 |
| 7 |
532411555 |
GRIP.HANDLE.LIFT.PVC.BLACK This part replaces 580962301. Price: $7.99 |
| 7 |
736-0169 |
Washer, Lock, 3/8 Price: $3.33 |
| 7 |
92-8001 |
SENSOR-SWITCH, REED Price: $86.02 |
| 8 |
75-4360-03 |
BRACKET-SUSPENSION, SEAT Price: $17.81 |
| 9 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 10 |
110-9730 |
SEAT SUSPENSION ASM This part replaces 75-3000. Price: $776.63 |
| 10 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $3.99 |
| 11 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 12 |
2412-133 |
CLAMP-R Price: $3.19 |
| 13 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 14 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 15 |
322-3 |
SCREW-HH Price: $0.79 |
| 16 |
2412-93 |
CLAMP-R Price: $1.02 |
| 88 |
532410710 |
SPRING.LIFT.ASSIST Price: $9.99 |
| 89 |
819191912 |
WASHER.CLEAR.ZINC Price: $2.99 |
| 90 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 91 |
589464807 |
Links This part replaces 532195181. Price: $14.99 |
| 97 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 98 |
581506903 |
Links This part replaces 532195270. Price: $9.99 |
| 100 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 101 |
532407003 |
LINK.ASM.LIFT.FIXE.38/42/46" Price: $11.99 |
| 116 |
594976501 |
Washers This part replaces 819151516. Price: $2.99 |
