| Ref | Part Number | Description |
|---|
| 1 |
07200613 |
HEX BELT, BB Price: $81.95 |
| 2 |
06500726 |
NUT,NYL-FLG .38-16 GF ZCC This part replaces 06545500. Price: $1.45 |
| 3 |
04365153 |
BRAKET, SPRING MOUNT Price: $14.95 |
| 4 |
06500910 |
NUT-JAM .375-16 G2 ZCC This part replaces 06535900. Price: $0.95 |
| 5 |
07001604 |
BOLT, .38-16X6.00 .62 DIA EYE Price: $6.45 |
| 6 |
08300505 |
SPRING, EXTENSION Price: $23.95 |
| 7 |
05901813 |
BLT, HEX .38-16X2.75 G8 ZCC This part replaces 05963000. Price: $1.45 |
| 8 |
04530500 |
RETAINER, SHEAVE Price: $7.95 |
| 9 |
06500907 |
NUT-LK-TOP-FLG .500-13 GF ZCC This part replaces 06543600. Price: $1.45 |
| 10 |
00450100 |
CAP, IDLER BEARING SEALING Price: $13.45 |
| 11 |
07300527 |
SHV, .50"ID X 6.00"OD V-IDLER Price: $47.95 |
| 12 |
04355200 |
SPACER, .516 X 1.5 X .2894 Price: $30.95 |
| 13 |
07316700 |
IDLER-FLAT-PLY 6.75X.510 Price: $57.45 |
| 14 |
06401012 |
WSHR,FLT .563X1.375X.109 ZCC This part replaces 06442000. Price: $2.45 |
| 15 |
04352151 |
ARM, IDLER PIVOT (RD) Price: $45.45 |
| 16 |
01581700 |
BSHG, SPCR .502X.997X2.03 PM Price: $5.95 |
| 17 |
05501234 |
BSHG, 1.00X1.125X1.937 This part replaces 05500123. Price: $9.95 |
| 18 |
06400829 |
WSHR-FLT .640X1.75X.250 Price: $3.95 |
| 19 |
07200611 |
V-BELT, HB-WRAPPED Price: $91.95 |
| 20 |
04297400 |
SPACER, .516 X 1.5 X 1.345 Price: $30.95 |
| 21 |
06500810 |
NUT,NYL-FLG .50-13 GF ZCC This part replaces 06500010. Price: $1.45 |
| 22 |
07000034 |
BLT,SHLDR EP .38-16X.30 HEX YZ Price: $3.45 |
| 23 |
04352600 |
SPACER,.516 X 1.5 X .924 Price: $30.95 |
| 24 |
05901640 |
BLT,HEX .38-16X2.25 G5 ZCC This part replaces 05962900. Price: $3.95 |
| 25 |
04348151 |
WLDMT, IDLER ARM (60"RD) Price: $70.45 |
| 26 |
04385453 |
BRKT, IDLER MOUNT Price: $35.95 |
| 27 |
04358000 |
SPACER,.516 X 1.5 X 1.517 Price: $8.80 |
| 28 |
07000027 |
NUT, COUPLING .31-18 X 3.00 Price: $22.95 |
| 29 |
04367453 |
BRKT, SPRG MOUNT (LH) Price: $29.45 |
| 30 |
05901505 |
BOLT, .5-13X7.00 GR5 HHFTH CLZ Price: Call Us |
| 31 |
04367200 |
TRUNNION,SPRG ADJUST .50-13 Price: $71.45 |
| 32 |
05717100 |
RG-RTNG-EXT .500X.050 (SNAP) Price: $2.45 |
| 33 |
04367553 |
ARM, SPRING TENSIONER Price: $71.45 |
| 34 |
06200325 |
BLT, RHSN .50-13X1.25 G5 ZCC This part replaces 06224700. Price: $5.95 |
| 35 |
06200313 |
BLT, RHSN .38-16X1.00 G5 ZCC This part replaces 06223600. Price: $2.45 |
| 36 |
06200425 |
BTL,RHSN .313-18 X 0.75 G5 ZCC LT This part replaces 06200002. Price: $3.95 |
| 37 |
06200317 |
BLT, RHSN .50-13X3.50 G5 ZCC This part replaces 06225000. Price: $5.45 |
| 38 |
06200327 |
BLT, RHSN .50-13X2.75 G5 ZCC This part replaces 06225700. Price: $8.95 |
| 39 |
05901712 |
BLT, HEX .50-13X2.50 G5 ZCC This part replaces 05966600. Price: $3.45 |
| 41 |
06611200 |
KEY, SQ .25X.25X1.00 RC 40-50 Price: $2.95 |
| 42 |
59211500 |
KIT-07328867 PULLEY REPLACEMNT This part replaces 07328867. Price: $81.95 |
| 43 |
59211600 |
KIT-07328967 PULLEY REPLACEMNT This part replaces 07328967. Price: $74.45 |
| 44 |
07329167 |
PULLEY, DBL-1"IDX6.75"&4.25"OD Price: $76.45 |
| 45 |
06500911 |
NUT-JAM .500-13 G2 ZCC This part replaces 06529300. Price: $1.45 |
| 46 |
07533600 |
BUMPER, RUBBER Price: $10.95 |
| 47 |
06500914 |
NUT-LK-CTR-JAM .375-16 GB ZCC This part replaces 06537200. Price: $0.95 |
| 48 |
06500735 |
NUT- SPNLK-FLG .38-16 G5 ZCC This part replaces 06534900. Price: $1.45 |
