| Ref | Part Number | Description |
|---|
| 1 |
76-4240 |
DISCONTINUED Price: Call Us |
| 2 |
3274-87 |
SCREW-HSFH Price: $1.09 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 3 |
74-3640 |
DISC-MIDDLE Price: $195.30 |
| 4 |
106-1021 |
DISC-ACTUATING This part replaces 74-3630. Price: $320.62 |
| 5 |
3234-30 |
SCREW-HHF Price: $0.41 |
| 6 |
76-8300-03 |
COVER-HOUSING, AXLE This part replaces 76-8300. Price: $14.53 |
| 7 |
32128-50 |
NUT-FLANGE Price: $1.78 |
| 8 |
2412-102 |
CLAMP-R Price: $6.85 |
| 9 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 9 |
596501502 |
Keepers This part replaces 584908001. Price: $9.99 |
| 10 |
32128-23 |
NUT-HF Price: $1.51 |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $229.99 |
| 11 |
84-1620-03 |
PLATE-SUPPORT, AXLE This part replaces 84-1620. Price: $19.85 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 12 |
88-1560 |
AXLE HSG *B Price: $1,118.53 |
| 13 |
92-9708 |
COLLAR-BEARING Price: $30.60 |
| 14 |
92-9705 |
BEARING Price: $69.99 |
| 15 |
532422804 |
TANK FUEL Price: $149.99 |
| 15 |
92-9707 |
DISCONTINUED Price: Call Us |
| 16 |
32121-88 |
COIL PIN Price: $7.79 |
| 17 |
92-9713 |
DISCONTINUED Price: Call Us |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 Price: $14.99 |
| 18 |
86-5900 |
TIRE (26X12-12) 8-PLY Price: $229.98 |
| 19 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 20 |
23-7270 |
NUT-LUG Price: $10.37 |
| 20 |
586219601 |
CONTROL.THROTTLE/CHOKE.PRO.45 Price: $54.99 |
| 21 |
104-0161 |
RIM This part replaces 217-124. Price: $404.23 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
242-34 |
STUD-DRIVE Price: $11.61 |
| 23 |
92-9706 |
SPACER-AXLE, FLANGED Price: $89.64 |
| 24 |
112-8446 |
SEAL-V RING This part replaces 92-9712. Price: $4.26 |
| 25 |
84-1590 |
U-BOLT, FRONT AXLE Price: $23.41 |
| 26 |
325-15 |
SCREW-HH Price: $3.19 |
| 27 |
86-5430 |
DISCONTINUED Price: Call Us |
| 28 |
325-4 |
SCREW-HH Price: $0.95 |
| 28 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 29 |
240-3 |
GROMMET-RUBBER Price: $17.44 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
125-1984 |
SPACER This part replaces 69-9000. Price: $0.68 |
| 31 |
69-9010 |
WASHER Price: $1.83 |
| 32 |
237-65 |
O-RING Price: $2.50 |
| 33 |
92-6571 |
TUBE ASSY - REEL RETURN Price: $91.58 |
| 34 |
325-5 |
SCREW-HH Price: $1.20 |
| 35 |
74-6420 |
DISCONTINUED Price: Call Us |
| 36 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
92-6572 |
TUBE ASSY - REEL Price: $84.24 |
| 38 |
76-6010 |
SPACER Price: $18.94 |
| 39 |
69-9940 |
NUT-HJ Price: $2.09 |
| 40 |
92-7775 |
DISCONTINUED Price: Call Us |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 41 |
92-7774 |
STUD Price: $47.95 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 42 |
92-7776 |
SPRING-EXTENSION Price: $13.09 |
| 43 |
92-7777 |
DISCONTINUED Price: Call Us |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK Price: $22.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 116 |
539132624 |
KNOB - SHIFT Price: $6.99 |
| 117 |
532420828 |
VALVE FUEL RESERVE Price: $27.99 |
