| Ref | Part Number | Description |
|---|
| 3 |
487372 |
Muffler, Kohler Price: Call Us |
| 4 |
429214 |
Heatshield, Muffler Price: Call Us |
| 5 |
483280-02 |
Tubing, Oil Drain 1/2 x 14" Price: Call Us |
| 6 |
482510 |
Extension, Oil Drain 2.3" - Kawasaki Price: Call Us |
| 7 |
48811 |
Hose, 3/8" ID - 10-1/4" Long (Order By The Inch) Price: Call Us |
| 8 |
48136-13 |
Clamp, .69" Max. / .25" Min. Dia. Price: Call Us |
| 9 |
482266-01 |
Elbow, 90 Degree - 9/16" O-Ring x 3/8" Hose Price: Call Us |
| 10 |
04001-08 |
BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 3/4" Price: Call Us |
| 11 |
482417 |
Filter Head Assembly Price: Call Us |
| 12 |
48462-01 |
OIL FILTER, SPECIAL Price: Call Us |
| 13 |
48771-02 |
Plug, JIC 3/4-16 UNF Price: Call Us |
| 15 |
48136-05 |
Clamp, Cable 3/4" I.D. Price: Call Us |
| 16 |
48351 |
Hose Assembly, 1/2" ID (Oil Reservoir to Filter Base) Price: Call Us |
| 17 |
482483 |
Tee, 3/4" O-Ring x JIC x 1/2" Hose Price: Call Us |
| 18 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 19 |
429151 |
Bracket, Hydro Tank Price: Call Us |
| 20 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 22 |
482571 |
Bushing, 0.56" Dia. Viton Price: Call Us |
| 23 |
485590 |
Fitting, Straight Price: Call Us |
| 24 |
482574 |
Fitting, 90 Degree - 1/2" Hose Price: Call Us |
| 25 |
482753 |
Bushing Price: Call Us |
| 26 |
481507 |
Insert, Filler Neck Price: Call Us |
| 27 |
481164 |
CAP, HYDRAULIC TANK Price: Call Us |
| 29 |
487431 |
Adjustable Valve Assy. Price: Call Us |
| 30 |
487429 |
Adapter, Plug Price: Call Us |
| 31 |
487430 |
Sensor, Valve Price: Call Us |
| 32 |
487428 |
Sensor, Plug Price: Call Us |
| 33 |
487432 |
Fitting, Valve Price: Call Us |
| 34 |
487435 |
Pressure Gauge Price: Call Us |
| 35 |
487433 |
Adapter Price: Call Us |
| 36 |
487438 |
Elbow, 90 Degree O-Ring Price: Call Us |
| 37 |
487427 |
Base, Valve Price: Call Us |
| 38 |
429172 |
Mounting Brkt, Manifold Price: Call Us |
| 39 |
04017-04 |
CAP SCREW, 1/4-20 X 1/2" SERRATED FLANGE HEX Price: Call Us |
| 40 |
487281 |
Wheelmotor Price: Call Us |
| 41 |
04001-46 |
Bolt, Hex Head 3/8-16 x 2-1/4" - 61" Price: Call Us |
| 42 |
453353 |
Pivot Bearing Wlmt Price: Call Us |
| 43 |
04021-19 |
Locknut, Hex 1/2-13 Center Lock Price: Call Us |
| 44 |
48572-02 |
TUBE UNION, 3/4-16 JIC TO 7/8-14 "O" RING Price: Call Us |
| 45 |
48572-10 |
Fitting, 1/2" JIC x 5/8" O-Ring (LH Wheel Motor - Upper Port Only) Price: Call Us |
| 46 |
481203-02 |
Elbow, 1/2 JIC Female to 1/2 JIC Male Price: Call Us |
| 47 |
485602 |
Hose Assembly Price: Call Us |
| 48 |
485603 |
Hose Assembly Price: Call Us |
| 49 |
484452 |
Hose Assembly Price: Call Us |
| 50 |
487441 |
Hose Assembly Price: Call Us |
| 51 |
423279 |
Plate Weldment, Motor Backing Price: Call Us |
| 52 |
04001-190 |
Bolt, Hex Head 1/2-13 x 2-3/4" (48V & 52V - One Weight) Price: Call Us |
| 53 |
483215 |
Idler Pulley, Belt Clutch Price: Call Us |
| 54 |
482649 |
Pulley, 5.45 OD - Tapered Bore" Price: Call Us |
| 55 |
487297 |
Belt, Pump Drive Price: Call Us |
| 56 |
04063-14 |
KEY, 5 MM X 5 MM X 25 MM Price: Call Us |
| 57 |
482085 |
Hub, Tapered, 15mm Bore Price: Call Us |
| 58 |
04001-172 |
Bolt, Hex Head 1/4-20 x 1" Grade 8 Black Price: Call Us |
| 59 |
04001-22 |
Capscrew, Hex Head 3/8-16 x 2.75" Price: Call Us |
| 60 |
04043-04 |
Flatwasher, 3/8 (.391 x .938 x .105 HD) Grade 8 Price: Call Us |
| 61 |
04041-28 |
Flatwasher, 7/16-.469 x 1.75 x .25 (48, 52) Price: Call Us |
| 62 |
04102-03 |
Bolt, Hex Head 7/16-20 x 2-1/4" w/Patch (Kawasaki) Price: Call Us |
| 63 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 64 |
48224 |
BEARINGS, BALL, NEUTRAL RETURN Price: Call Us |
| 65 |
04001-77 |
Bolt, Hex Head, 3/8-16 x 3-1/2" Price: Call Us |
| 66 |
453361 |
Idler Arm Assy, Pump Drive (incl. #64) Price: Call Us |
| 67 |
04001-136 |
Bolt, Hex Head 3/8-16 x 1-1/2" Grade 8 Black Price: Call Us |
| 68 |
43683 |
Pivot, Idler Price: Call Us |
| 69 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 70 |
487363 |
Pulley, 5.45 Dia. 1.125 Bore Price: Call Us |
| 71 |
483213 |
Pulley, Idler 4-1/2" Price: Call Us |
| 72 |
04063-23 |
Key, 1/4 x 1/4 x 3-1/4” Price: Call Us |
| 73 |
487470 |
Hose Assembly Price: Call Us |
| 74 |
487471 |
Hose Assembly Price: Call Us |
| 75 |
487432 |
Fitting, Valve Price: Call Us |
| 76 |
487258 |
Cylinder, 3.00 Bore x 4.00 Stroke Price: Call Us |
| 77 |
483112 |
Spring, Transmission Drive Price: Call Us |
| 78 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 79 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 80 |
04021-02 |
Bolt, Hex Hd. 1/2-13 x 9-1/2" Price: Call Us |
| 81 |
04041-38 |
Flatwasher, 3/8-.406 x 2.25" x .1875 Price: Call Us |
| 82 |
487389 |
Pump, LH Price: Call Us |
| 83 |
487390 |
Pump, RH Price: Call Us |
| 84 |
48485-01 |
Elbow, 45 Deg. - 3/4-16 JIC Male x Male 3/4-16 O-Ring Price: Call Us |
| 85 |
482277 |
Tee Fitting, O-Ring to Barb Price: Call Us |
| 86 |
482800-02 |
Fitting, 9/16" O-Ring x 3/8" Hose Price: Call Us |
| 87 |
48572-11 |
Union, 37 Degree 9/16-18 x 7/16-20 O-Ring Price: Call Us |
