| Ref | Part Number | Description |
|---|
| 1 |
133-2935 |
HYDRAULIC MOTOR ASM This part replaces 120-6264. Price: $1,293.20 |
| 2 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 3 |
121-5631 |
HUB ASM This part replaces 120-6255. Price: $156.48 |
| 4 |
136-7963 |
TIRE ASM This part replaces 117-5194. Price: $455.76 |
| 5 |
340-17 |
FITTING-ELBOW, 90 DEG Price: $42.29 |
| 6 |
108-7632 |
TUBE ASM Price: $192.57 |
| 7 |
108-7633 |
TUBE ASM Price: $191.74 |
| 8 |
321-4 |
SCREW-HH Price: $0.99 |
| 9 |
2412-134 |
CLAMP-R Price: $5.79 |
| 10 |
59-7410 |
FITTING-DIAGNOSTIC Price: $36.39 |
| 11 |
354-79 |
CAP-DUST Price: $7.81 |
| 12 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 13 |
325-12 |
SCREW-HH Price: $2.27 |
| 14 |
147-3594 |
ADAPTER-BRAKE This part replaces 120-6253-03. Price: $47.56 |
| 15 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
133-2934 |
HYDRAULIC MOTOR ASM This part replaces 120-6265. Price: $1,293.20 |
| 17 |
117-3290 |
NUT-HEX Price: $32.02 |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 18 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 19 |
114-8864 |
DRUM-BRAKE Price: $248.55 |
| 20 |
127-2741 |
SHIELD-WHEEL, FRONT This part replaces 110-0950. Price: $9.99 |
| 21 |
127-2742 |
SHIELD-WHEEL, REAR This part replaces 110-0951. Price: $8.07 |
| 22 |
127-2742 |
SHIELD-WHEEL, REAR This part replaces 110-8878. Price: $8.07 |
| 23 |
283-62 |
PIN-CLEVIS Price: $0.61 |
| 24 |
139-5952 |
LH BRAKE ASM This part replaces 120-6261. Price: $449.41 |
| 25 |
139-5951 |
RH BRAKE ASM This part replaces 120-6260. Price: $449.41 |
| 26 |
323-4 |
SCREW-HH Price: $1.02 |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 27 |
120-6267 |
CLIP-SPRING, LH Price: $6.99 |
| 28 |
322-7 |
SCREW-HH Price: $0.89 |
| 29 |
3256-67 |
WASHER Price: $0.49 |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 30 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 31 |
117-5198 |
KEY-SQUARE Price: $11.44 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 35 |
590605902 |
ROD ROD.PARKINGBRAKE.GT.HUSQ/P Price: $7.99 |
| 36 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 37 |
120-6266 |
CLIP-SPRING, RH Price: $6.99 |
| 37 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 38 |
87-4020 |
SPRING-EXTENSION Price: $17.01 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 69 |
583404901 |
HAIRPIN.SOFT.ZINC.059X1.125 This part replaces 532423303. Price: $2.99 |
| 70 |
532439661 |
CONSOLE.ASM.RH.GT.FC.HUSQ Price: $79.99 |
| 73 |
596136501 |
Bolts This part replaces 874490540. Price: $3.99 |
| 74 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 99 |
582404501 |
ARM.PIVOTING.TCRD.GEN2.5.BAGGE Price: $5.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
593861001 |
Rods This part replaces 532448275. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532413430 |
KEEPER.CENTER SPAN.1.688 Price: $5.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 587653701. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
587402001 |
BRKT.42.FCS.CLUTCH.ANTIROTATIO Price: $5.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 587031401. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 210 |
532197860 |
ROCKER.ASM.PEDAL.CONTR Price: $44.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532416863 |
PEDAL.FORWARD.HUSQVARNA.DEALER Price: $32.99 |
| 215 |
586606502 |
PEDAL.COVER.REVERSE.CRD.X428BK Price: $17.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 227 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 231 |
532407287 |
IDLER.V-GROOVE.1.688.OFFSET Price: $19.99 |
| 284 |
532417693 |
NUT.U-CHNL.1/4-20.550DP.350PNL Price: $3.99 |
| 307 |
874180412 |
SCREW.MACHINE.CR.1/4-20 Price: $3.99 |
| 325 |
586431203 |
BRACKET TORQUE STRAP This part replaces 586431202. Price: $4.99 |
| 326 |
586001103 |
BRACKET TORQUE STRAP This part replaces 586001102. Price: $5.99 |
| 334 |
585882202 |
SWAY.ROD.BRACKET.K46.X431 Price: $11.99 |
| 336 |
587259602 |
Bolts This part replaces 587259601. Price: $3.99 |
