| Ref | Part Number | Description |
|---|
| 1 |
322-3 |
SCREW-HH Price: $0.79 |
| 1 |
603001202 |
O-RING, 8 X 7 Price: $6.99 |
| 2 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 2 |
603001444 |
BOLT, CYLINDER HEAD Price: $19.99 |
| 3 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 3 |
603001454 |
HOOK, ENGINE Price: $12.99 |
| 4 |
3258-19 |
SCREW Price: $0.42 |
| 4 |
603001455 |
GASKET, CYLINDER HEAD Price: $139.99 |
| 5 |
27-7100 |
AIR CLEANER ASM Price: $323.10 |
| 5 |
603001662 |
SPRING, START Price: $8.99 |
| 6 |
20-4840 |
CLAMP-MUFFLER Price: $15.06 |
| 6 |
603001705 |
BOLT, ENGINE HOOK Price: $2.99 |
| 7 |
43-3810-03 |
TUBE-CLEANER, AIR This part replaces 43-3810. Price: $89.59 |
| 7 |
603001709 |
STAY, CYLINDER HEAD Price: $12.99 |
| 8 |
27-7180 |
CAP Price: $70.51 |
| 9 |
603001206 |
PLUG, 3/32" NPT Price: $5.99 |
| 9 |
82-5590 |
HOSE-CLEANER, AIR Price: $79.73 |
| 10 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 10 |
603001450 |
GUIDE, EXHAUST VALVE Price: $14.99 |
| 11 |
3217-6 |
NUT-HEX Price: $1.19 |
| 11 |
603001451 |
GUIDE, INLET VALVE Price: $19.99 |
| 12 |
27-7160 |
DECAL-INSTALLATION Price: $19.89 |
| 12 |
603001707 |
CAP, SEALING, HEAD Price: $6.99 |
| 13 |
32128-20 |
NUT-HF Price: $0.99 |
| 14 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 15 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 16 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 17 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 18 |
80-3330 |
GASKET Price: $18.48 |
| 19 |
27-7150 |
A/C CUP ASM Price: $82.89 |
