| Ref | Part Number | Description |
|---|
| 1 |
532186093 |
WHEEL.STEERING.LEGND2.GRY This part replaces 532193943. Price: $89.99 |
| 1 |
67-3770 |
DISCONTINUED Price: Call Us |
| 1 |
710-3019 |
BOLT-PIVOT 3/4-10 x 5.0 GR5 W Not Available Price: |
| 2 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 2 |
67-3760 |
LOCK PLATE Price: $21.29 |
| 2 |
759-3270 |
FRONT AXLE Not Available Price: |
| 3 |
67-3740 |
NIPPLE Price: $62.56 |
| 3 |
937-3000 |
Grease Fitting This part replaces 7373000. Price: $4.04 |
| 4 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 4 |
67-3480 |
O-RING Price: $2.47 |
| 4 |
923-3000 |
JOINT-BALL-3/8-24 This part replaces 723-3000. Price: $18.68 |
| 5 |
538691001 |
SPINDLE.WLDMT.RH.16IN.TEX.X431 This part replaces 532197936. Price: $19.99 |
| 5 |
711-3018 |
TIE ROD Not Available Price: |
| 5 |
87-3490 |
Spring Price: Call Us |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
703-0083-0637 |
KNUCKLE ASM-LH POWDER BLACNLAUD Not Available This part replaces 703-0083. Price: |
| 6 |
93-3465 |
GASKET-DELIVERY V. This part replaces 42-8240. Price: $8.09 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
67-3500 |
SUB-ASSEMBLY VALVE Price: $99.95 |
| 7 |
703-0085-0637 |
KNUCKLE ASSEMBLY (RH) (POWDER BLACK) This part replaces 703-0085. Price: $135.18 |
| 8 |
75-4970 |
ELEMENT - SUB-ASSY Price: $224.06 |
| 8 |
750-3002 |
SPACER-KNUCKLE-S Not Available Price: |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
67-3460 |
SUB-ASM PUMP HOUSING Price: $618.09 |
| 9 |
710-3020 |
BOLT-HEX 1/2-20X5.25 LG GR5 Not Available Price: |
| 10 |
67-3520 |
SUB-ASSEMBLY SLEEVE Price: $47.39 |
| 11 |
67-3530 |
SEAT Price: $4.36 |
| 12 |
67-3540 |
SPRING Price: $12.47 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
67-3550 |
DISCONTINUED Price: Call Us |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
67-3650 |
DISCONTINUED Price: Call Us |
| 15 |
67-3700 |
DISCONTINUED Price: Call Us |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532194746. Price: $34.99 |
| 16 |
87-9810 |
FOAM-TANK, OVERFLOW Price: $2.65 |
| 17 |
67-3790 |
DISCONTINUED Price: Call Us |
| 18 |
67-3800 |
BRACKET Price: $27.34 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
67-3780 |
RACK ASSEMBLY Price: $154.27 |
| 20 |
70-3910 |
WASHER This part replaces 67-3750. Price: $3.15 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 21 |
67-3740 |
NIPPLE Price: $62.56 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 22 |
67-3730 |
DISCONTINUED Price: Call Us |
| 23 |
67-3720 |
DISCONTINUED Price: Call Us |
| 24 |
67-3710 |
AIR BLEED SCREW Price: $6.38 |
| 25 |
67-3970 |
NUT Price: $28.82 |
| 26 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 26 |
67-3980 |
GASKET Price: $3.19 |
| 27 |
67-3960 |
NOZZLE ASSEMBLY Price: $167.76 |
| 28 |
67-3950 |
PIECE Price: $19.92 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
93-3502 |
PIN-PRESSURE This part replaces 67-3940. Price: $3.22 |
| 30 |
67-3930 |
SPRING Price: $12.66 |
| 31 |
67-3840 |
WASHER 1.30 Price: $4.16 |
| 31 |
67-3910 |
WASHER 1.65 Price: $2.91 |
| 31 |
93-3491 |
WASHER-T=1.25 This part replaces 67-3830. Price: $8.80 |
| 32 |
75-5000 |
BODY SUB-ASSY Price: $147.67 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532197636 |
SPACER.BRACE.AXLE (2 2) Price: $5.99 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $37.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
