| Ref | Part Number | Description |
|---|
| 1 |
9600 |
SEAL-PINION SHAFT PT/85030/00 Price: Call Us |
| 2 |
718-04007 |
Front Bearing Cap This part replaces 1114. Price: $16.60 |
| 3 |
9701 |
SCR-HH 1/4-20X.75 G5 ZP Price: Call Us |
| 4 |
9910 |
WASHER-LK .25 ZP Price: Call Us |
| 5 |
GW-1124-2099 |
BEARING COVER GASKET This part replaces 1124-2. Price: $3.98 |
| 6 |
941-0107 |
Bearing, Tapered Roller (with race) This part replaces 1714. Price: $41.81 |
| 7 |
9780 |
SCR-HH 1/4-20X.625 Price: Call Us |
| 8 |
1902 |
KIT-DRIVESHAFT HORSE Price: Call Us |
| 9 |
736-04306 |
Washer, Flat, 1.50 x 1.75 x .005 This part replaces 1224-3. Price: $3.85 |
| 9 |
736-04308 |
Washer, Flat, 1.50 x 1.75 x .010 This part replaces 1224-1. Price: $3.85 |
| 9 |
742-05107-4046 |
BLADE:46":SIDE:HOP 532-405380 This part replaces 12242. Price: $28.06 |
| 10 |
718-04406 |
Rear Bearing Cover This part replaces 1115. Price: $44.01 |
| 11 |
GW-9911 |
LOCKWASHER- Hi-collar, 1/4" This part replaces 9911. Price: $5.23 |
| 12 |
9773 |
SCR-HFLK 1/4-20X.875 Price: Call Us |
| 12A |
GW-9719 |
SCR-HXSKT 1/4-20X1.0 This part replaces 9719. Price: $4.53 |
| 13 |
GW-9301 |
Key, 3/16 sq. x 1 This part replaces 9301. Price: $3.46 |
| 14 |
738-04448 |
PIN This part replaces 1442. Price: $7.14 |
| 15 |
1568 |
SHAFT-ECCENTRIC HORSE TLR Price: Call Us |
| 16 |
GW-1441 |
SPRING - eccentric shaft This part replaces 1441. Price: $3.61 |
| 17 |
736-04079 |
Support Washer This part replaces 1440. Price: $4.13 |
| 18 |
9611 |
SEAL-OIL ECCENTRIC Price: Call Us |
| 19 |
GW-9911 |
LOCKWASHER- Hi-collar, 1/4" This part replaces 9911. Price: $5.23 |
| 21 |
9609 |
SEAL-OIL WHEELSHAFT Price: Call Us |
| 22 |
736-04257 |
Flat Washer, 1.375 x 1.015 x .005 This part replaces 1166-5. Price: $3.48 |
| 22 |
736-04258 |
Washer, 1.375 x 1.015 x .01 This part replaces 1166-4. Price: $3.48 |
| 22 |
736-04259 |
Washer, 1.375 x 1.015 x .015 This part replaces 1166-3. Price: $5.94 |
| 22 |
736-04260 |
Washer, 1.375 x 1.015 x .03 This part replaces 1166-2. Price: $5.94 |
| 22 |
736-04309 |
Washer, 1.375 x 1.015 x .062 This part replaces 1166-1. Price: $3.85 |
| 23 |
716-04104 |
Retaining Ring This part replaces 9511. Price: $3.85 |
| 23A |
9501 |
RING-RETAINING 5100-100 Price: Call Us |
| 24 |
941-04300 |
Bushing, 1.25 x 1 x .005 x 1.5 This part replaces 1086. Price: $15.25 |
| 25 |
GW-1878 |
SHAFT - wheel, 15-5/8" This part replaces 1878. Price: $201.61 |
| 25A |
1235A |
KIT-WHEELSHAFT Price: Call Us |
| 25B |
1879 |
KIT-WHEELSHAFT Price: Call Us |
| 25C |
1025 |
KIT-WHEELSHAFT Price: Call Us |
| 26 |
GW-1232 |
GEAR- fast speed, wheel drive This part replaces 1232. Price: $135.63 |
| 26A |
1005 |
GEAR-SPUR-50 TEETH-MACH Price: Call Us |
| 27 |
GW-1237 |
DOG CLUTCH - wheel drive. Clutch drives either slow or fast wheel drive gears according to wheel speed shift lever gear selection This part replaces 1237. Price: $142.70 |
| 28 |
GW-1112 |
PIN - clutch guide, 1/4" diameter This part replaces 1112. Price: $4.06 |
| 29 |
GW-1223 |
GEAR- slow speed, wheel drive This part replaces 1223. Price: $196.25 |
| 29A |
1004 |
GEAR-SPUR 60 TEETH-MACH Price: Call Us |
| 30 |
714-04014 |
Hi-Pro Key, .250 x 1.8125 This part replaces 9357. Price: $18.36 |
| 30A |
714-04059 |
Key, .25 x 1.062 This part replaces 9305. Price: $5.94 |
| 31 |
1094 |
PIN-.375 X .72 Price: Call Us |
| 32 |
1016 |
CLUTCH FORK Price: Call Us |
| 33 |
1027A |
SHAFT-ECC WITH O RING Price: Call Us |
| 34 |
1041 |
PIN-.5X4.0 FORK # Price: Call Us |
| 35 |
9603 |
RING-O .625 X .438 Price: Call Us |
| 36 |
1029 |
LEVER-ECC. #1029 Price: Call Us |
| 37 |
GW-1060A |
PLUG-PINION BRG W/ Not Available This part replaces 1060A. Price: |
| 38 |
715-0121 |
Spirol Pin, 1/4 x 2.0 This part replaces 9309. Price: $5.95 |
| 39 |
GW-9604 |
O-RING - retaining plug This part replaces 9604. Price: $4.62 |
| 40 |
736-04310 |
Flat Washer, 1/234 x 1.015 x .062 This part replaces 1132-2. Price: $3.95 |
| 40 |
736-04386 |
Washer, 1.00 x 1.50 x .03, SS This part replaces 1132-1. Price: $6.01 |
| 40 |
GW-1132-3 |
Washer, Flat, 1.015 x 1.234 x.010 This part replaces 1132-3. Price: $5.95 |
| 41 |
GW-9404 |
BEARING - ball, pinion shaft This part replaces 9404. Price: $24.30 |
| 42 |
736-0272 |
FLAT WASHER .510 x .995 This part replaces 1126. Price: $4.37 |
| 43 |
GW-1233 |
GEAR- fast speed pinion (drives fast speed wheel gear) This part replaces 1233. Price: $125.18 |
| 43A |
1056 |
GEAR-SPLINE-16 TEETH-MACH Price: $8.22 |
| 44 |
1221 |
GEAR-WORM 36 TEETH MACH Price: Call Us |
| 44A |
1057 |
GEAR-WORM-30 TEETH-MACH Price: Call Us |
| 45 |
716-04119 |
External Retaining Ring, 1.387 ID This part replaces 9502. Price: $12.96 |
| 46 |
GW-1222 |
STEM PINION - slow speed gear and shaft (drives slow speed wheel gear) This part replaces 1222. Price: $122.90 |
| 46A |
1055 |
GEAR-SPLINE 6 TEETH MACHINE Price: Call Us |
| 47 |
9616 |
SEAL-OIL TILLERSHAFT Price: Call Us |
| 48 |
N/A |
TAPERED, BEARING & CUP |
| 50 |
N/A |
WORM GEAR |
| 50A |
11527 |
KIT-TILLER GEAR & BRGS Price: Call Us |
| 51 |
GW-1026A |
SHAFT-tiller tine Includes #1104 key(Ref. #7); TILLER TINE SHAFT ASSEMBLY This part replaces 1026A. Price: $175.96 |
| 52 |
GW-1104 |
Key-Woodruff, 1/4 x 1-1/4 This part replaces 1104. Price: $8.32 |
| 53 |
GW-1129-1099 |
TILLER COVER GASKET This part replaces 1129-1. Price: $7.81 |
| 53 |
GW-1129-2099 |
TILLER COVER GASKET This part replaces 1129-2. Price: $7.81 |
| 54 |
1872 |
COVER-W/SCRS(TLR) (9780) Price: Call Us |
| 55 |
GW-9300 |
KEY-3/16" square x 5/8" Connects fast speed pinion gear to bronze worn gear This part replaces 9300. Price: $3.22 |
| 56 |
9718 |
SCR-HXSKT 1/4-20X.625 Price: Call Us |
| 57 |
GW-1123 |
GASKET- transmission cover This part replaces 1123. Price: $7.44 |
| 58 |
1003 |
ASSM-COVER W/BOLT-HORSE Price: Call Us |
| 59 |
1251 |
SPRING .78 X 2.125 Price: Call Us |
| 59A |
1496 |
SPRING-REV PLUNGER ZP Price: Call Us |
| 60 |
GW-1035 |
PLUNGER -neutral (REMOVE WITH CARE) This part replaces 1035. Price: $33.23 |
| 61 |
9831 |
NUT-HFLK 3/8-16 ZP Price: Call Us |
| 62 |
9558 |
BOLT-HH 3/8-16X1.5 FTH ZP Price: Call Us |
| 63 |
9751 |
SCR-HH 5/16-18X1.0 G5 ZP Price: Call Us |
| 64 |
9801 |
NUT-HEX 5/16-18 ZP Price: Call Us |
| 65 |
737-04202 |
Pipe Plug This part replaces 9727. Price: $6.01 |
| 66 |
9713 |
BOLT-HH 3/8-16X1.5 FTH ZP Price: Call Us |
| 67 |
9913 |
WASHER-LK .375 @ DEPL Price: $1.89 |
| 68 |
737-04202 |
Pipe Plug This part replaces 9727. Price: $6.01 |
| 68A |
1105620 |
PLUG-SQ HEAD 1/4-18 NPT This part replaces 9726. Price: $3.66 |
| 69 |
915-0246 |
Pin, Spring, 3/16 x 1.25 Not Available This part replaces 9307. Price: |
| 70 |
GW-9122 |
PLUG - red plastic, thread protector This part replaces 9122. Price: $8.93 |
| 71 |
N/A |
TRANSMISSION CASE, HOUSING & TUBE ASSEMBLY |
