| Ref | Part Number | Description |
|---|
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
104-5584-0P |
PLATE-REINFORCEMENT,ROPS This part replaces 104-5584-03. Price: $36.27 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
325-33 |
SCREW-HH Price: $11.49 |
| 4 |
32128-49 |
NUT-HHF Price: $1.04 |
| 5 |
3234-38 |
SCREW-HHF Price: $3.33 |
| 6 |
130-1617 |
FRAME-FRONT Price: $3,739.99 |
| 7 |
75-1410-01 |
PLATE-ACCESS, FLOOR Price: $142.43 |
| 8 |
32128-20 |
NUT-HF Price: $0.99 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $24.99 |
| 9 |
3274-18 |
SCREW-HSH Price: $8.88 |
| 10 |
130-1659 |
ACCESS PLATE ASM Price: $92.24 |
| 11 |
75-0630 |
TREAD-FOOT, CENTER Price: $56.24 |
| 12 |
3234-7 |
SCREW-HHF Price: $1.99 |
| 15 |
93-6680 |
DECAL-DIESEL Price: $19.31 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 16 |
93-6686 |
DECAL-OIL, HYD Price: $7.01 |
| 17 |
100-6574 |
DECAL-WARNING Price: $15.80 |
| 18 |
105-9194 |
PLUG Price: $9.48 |
| 19 |
104-5516-0P |
SUPPORT-TUBE This part replaces 104-5516-01. Price: $9.23 |
| 20 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 21 |
130-1601-03 |
FRAME-REAR Price: $2,529.99 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
130-1632-03 |
BRACKET-MOUNT, ENGINE Price: $58.23 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
138-1186 |
DECAL-DANGER This part replaces 120-1686. Price: $12.87 |
| 24 |
116-4701 |
SCREW-HHF Price: $2.59 |
| 25 |
3234-24 |
SCREW-HHF Price: $3.19 |
| 25 |
581498001 |
CABLE.BATT.RED.8GA.17 Price: $7.99 |
| 26 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
99-7411 |
POINT-POWER Price: $30.69 |
| 28 |
583390701 |
CABLE.GROUND.REAR.BATTERY.8GA This part replaces 532421686. Price: $8.99 |
| 28 |
99-7416 |
CAP Price: $6.64 |
| 29 |
136-2901 |
RH ROPS ASM Price: $586.28 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
136-2900 |
LH ROPS ASM Price: $586.28 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
136-2885 |
TOP TUBE ASM Price: $820.46 |
| 32 |
114-8419 |
SCREW-HHF Price: $4.17 |
| 33 |
136-2899 |
STANDOFF Price: $49.46 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT This part replaces 532411933. Price: $8.99 |
| 34 |
114-1925 |
BUMPER-RUBBER Price: $24.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 35 |
3234-36 |
SCREW-HHF Price: $0.75 |
| 36 |
136-2890 |
SPACER Price: $22.56 |
| 37 |
136-2893 |
WASHER-PLASTIC Price: $3.94 |
| 38 |
325-17 |
SCREW-HH Price: $2.90 |
| 39 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 40 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 40 |
581023201 |
HARNESS.TEX.DASH.ELEC.REAR BAT Price: $49.99 |
| 41 |
136-2892 |
PIN ASM Price: $18.53 |
| 42 |
80-1890 |
SPACER Price: $9.06 |
| 43 |
582042802 |
Solenoids Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. Price: $19.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 582107602. Price: $24.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 71 |
501133701 |
HARNESS.CHASSIS.RRBATT.RDYSTRT Price: $59.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
| 105 |
532407568 |
REVERSE SWITCH Price: $12.99 |
