| Ref | Part Number | Description |
|---|
| 1 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 2 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 3 |
47-3880-03 |
CONTROL LINKAGE ASM This part replaces 47-3880. Price: $260.93 |
| 4 |
47-3620 |
BLOCK-PIVOT, LEVER Price: $54.93 |
| 5 |
32153-3 |
NUT-HEX, SIDE DEFORM Price: $5.59 |
| 6 |
47-3680-01 |
UPPER CONTROL TOWER ASM This part replaces 47-3680. Price: $528.76 |
| 7 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 8 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 9 |
47-3380-01 |
CONTROL TOWER ASM This part replaces 47-3380. Price: $407.03 |
| 10 |
3217-8 |
NUT-HEX Price: $1.34 |
| 11 |
47-3630 |
ROD-LINKAGE, CONTROL Price: $104.04 |
| 12 |
327-6 |
SCREW-HH Price: $12.99 |
| 13 |
32128-23 |
NUT-HF Price: $1.51 |
| 14 |
325-6 |
SCREW-HH Price: $1.42 |
| 15 |
55-7380-01 |
TONGUE ASM This part replaces 55-7380. Price: $2,297.13 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
322-6 |
SCREW-HH Price: $0.45 |
| 17 |
26-8250-01 |
PIN-ARM, LIFT This part replaces 26-8250. Price: $99.04 |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 18 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 19 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 20 |
47-3250-01 |
NO. 2 AND 3 LIFT ARM ASM This part replaces 47-3250. Price: $779.92 |
| 21 |
26-8160-01 |
SUPPORT-ARM, LIFT This part replaces 26-8160. Price: $1,410.43 |
| 22 |
3296-24 |
NUT-HEX Price: $4.44 |
| 23 |
T0000-3423 |
JACK-SIDEWIND This part replaces 60-8900. Price: $134.35 |
| 24 |
47-3460 |
U-BOLT Price: $29.53 |
| 25 |
327-23 |
SCREW-HH Price: $3.60 |
| 26 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 27 |
131-4381-01 |
HITCH-CLEVIS This part replaces 47-3550. Price: $161.64 |
| 28 |
13-6200 |
PIN-HITCH, POINTED Price: $40.83 |
| 29 |
49-8180 |
DISCONTINUED Price: $15.10 |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 30 |
353-819 |
COUPLER-BODY Price: $156.66 |
| 31 |
353-820 |
COUPLER-TIP Price: $84.94 |
| 32 |
52-5990 |
HYD HOSE Price: $381.48 |
| 33 |
52-5991 |
HYD HOSE Price: $322.07 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 34 |
47-3810 |
LEVER-VALVE Price: $60.07 |
| 35 |
137-6138 |
DECAL-OPERATION This part replaces 47-5600. Price: $57.30 |
| 35 |
590605902 |
ROD ROD.PARKINGBRAKE.GT.HUSQ/P Price: $7.99 |
| 36 |
47-3820-03 |
COVER-COLUMN This part replaces 47-3820. Price: $79.97 |
| 37 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 37 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 38 |
47-3770 |
DECAL-MANUAL, OWNER Price: $25.33 |
| 39 |
3-0631 |
BALL-GRIP Price: $10.76 |
| 40 |
47-3450 |
PIVOT PIN Price: $54.81 |
| 41 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532008883. Price: $4.99 |
| 49 |
596136201 |
Bolts Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 56 |
592855201 |
Belts Price: $27.99 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 69 |
583404901 |
HAIRPIN.SOFT.ZINC.059X1.125 This part replaces 532423303. Price: $2.99 |
| 73 |
596136501 |
Bolts Price: $3.99 |
| 92 |
595305701 |
Screws Price: $3.99 |
| 99 |
582404501 |
ARM.PIVOTING.TCRD.GEN2.5.BAGGE Price: $5.99 |
| 116 |
596135701 |
GSPW Nuts Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws Price: $2.99 |
| 153 |
532004497 |
RETAINER M Price: $4.99 |
| 159 |
596029501 |
Pins Price: $2.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
593861001 |
Rods Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532413430 |
KEEPER.CENTER SPAN.1.688 Price: $5.99 |
| 177 |
587225301 |
PIN COTTER;LOCKING;BOWTIE;1IN Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 587653701. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
585658602 |
Stop Price: $4.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH Price: $4.99 |
| 207 |
587031402 |
Latch Price: $5.99 |
| 208 |
596564101 |
Gears Price: $4.99 |
| 209 |
590527802 |
ROD ROD.CRUISECONTROL.GT.HUSQ/ Price: $6.99 |
| 210 |
532400980 |
ROCKER.ASM.PEDAL.CONTR Price: $32.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX Price: $6.99 |
| 215 |
586606502 |
PEDAL.COVER.REVERSE.CRD.X428BK Price: $17.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 223 |
598662601 |
BOLTS Price: $1.99 |
| 227 |
596135901 |
Bolts Price: $1.99 |
| 231 |
532407287 |
IDLER.V-GROOVE.1.688.OFFSET Price: $19.99 |
| 325 |
586431203 |
BRACKET TORQUE STRAP This part replaces 586431202. Price: $4.99 |
| 326 |
586001103 |
BRACKET TORQUE STRAP This part replaces 586001102. Price: $5.99 |
| 334 |
585882202 |
SWAY.ROD.BRACKET.K46.X431 Price: $11.99 |
| 336 |
587259602 |
Bolts Price: $3.99 |
