| Ref | Part Number | Description |
|---|
| 1 |
532188249 |
DECK.SVC.38"LR 142830 This part replaces 532142830. Price: $249.99 |
| 2 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 3 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 4 |
532007631 |
RUNNER LH This part replaces 532125074. Price: $14.99 |
| 5 |
532110485 |
BEARING Price: $11.99 |
| 6 |
532128774 |
HOUSING.MANDREL.VENTED (MACHD) Price: $29.99 |
| 7 |
532129895 |
BEARING.BALL.#6204.(MANDREL) Price: $9.99 |
| 9 |
532134148 |
BLADE 38" V MULCH Price: $22.99 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 11 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 12 |
532850857 |
BLADE BOLT Price: $3.99 |
| 13 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532140329. Price: $6.99 |
| 14 |
532106736 |
SHIELD.DEFLECTOR.MOWER.38.BL Price: $36.99 |
| 15 |
532106735 |
ROD-HINGE T Price: $8.99 |
| 16 |
531155201 |
SERVICE KIT BRACKET BRACKET This part replaces 532137607. Price: $2.99 |
| 17 |
532110452 |
NUT PUSH M Price: $2.99 |
| 18 |
532123713 |
SPRING TORSION Price: $6.99 |
| 19 |
819111016 |
Washer 11/32 x 5/8 x 16 Gauge Price: $5.99 |
| 20 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 21 |
532128772 |
RUNNER.RH.38 Price: $6.99 |
| 22 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 23 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532138776. Price: $3.99 |
| 24 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 25 |
874760636 |
BOLT This part replaces 874600636. Price: $4.99 |
| 26 |
596140201 |
Washers This part replaces 819131612. Price: $2.99 |
| 27 |
532139756 |
LINK LIFT Price: $14.02 |
| 28 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 29 |
532139757 |
PLATE SLIDE LINK Price: $2.99 |
| 30 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 31 |
532140915 |
ROD.CLUTCH.PRIMARY Price: $13.99 |
| 32 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 33 |
532132559 |
ARM REAR SUSPENSION Price: $4.99 |
| 34 |
532133604 |
TRUNNION Price: $17.99 |
| 35 |
532132554 |
CLUTCH ROD Price: $11.99 |
| 36 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 37 |
596917601 |
Pins This part replaces 876020312. Price: $1.99 |
| 38 |
531164901 |
SERVICE.KIT IDLER ARM This part replaces 532133840. Price: $11.99 |
| 39 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $3.99 |
| 40 |
532173435 |
MANDREL.PULLEY.38.BRIGHT.ZINC This part replaces 532129206. Price: $19.99 |
| 41 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $7.99 |
| 42 |
532121316 |
PULLEY.IDLER.FLAT.MOWER.BLK.PT Price: $44.99 |
| 43 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 44 |
596140201 |
Washers This part replaces 819131612. Price: $2.99 |
| 45 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 46 |
532419271 |
V-BELT.DRIVE.MOWER.30" This part replaces 532126520. Price: $49.99 |
| 47 |
532133502 |
SPACER.IDLER.ARM Price: $4.99 |
| 48 |
531150801 |
SERVICE KIT STIFFENER STIFFENE This part replaces 532133503. Price: $6.99 |
| 49 |
532133551 |
PIVOT ROD Price: $6.99 |
| 50 |
532131289 |
BRAKE ROD LH Price: $12.99 |
| 51 |
531165101 |
SERVICE KIT BRAKE ASSEMBLY BRA This part replaces 532130840. Price: $6.99 |
| 52 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 53 |
532131288 |
BRAKE ROD RH Price: $6.99 |
| 54 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 55 |
532004921 |
COTTER PIN This part replaces 532124961. Price: $4.99 |
| 56 |
532136782 |
ADJUSTMENT PLATE Price: $2.99 |
| 57 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 58 |
596134901 |
GSPH This part replaces 819131212. Price: $2.99 |
| 59 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 60 |
819111112 |
WASHER Price: $3.99 |
| 62 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $2.99 |
| 63 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 64 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 65 |
596134901 |
GSPH This part replaces 819132016. Price: $2.99 |
| 66 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 67 |
532135651 |
WING NUT Price: $3.99 |
| 68 |
532132803 |
COVER.MULCHING.38" (2 2) Price: $54.99 |
| 69 |
874930620 |
Bolt 3/8 - 16 x 1-1/4 Price: $3.99 |
| 70 |
819162016 |
WASHER Price: $3.99 |
| 71 |
819131610 |
WASHER PM Price: $4.99 |
| 72 |
532178515 |
WASHER This part replaces 532133943. Price: $5.99 |
