| Ref | Part Number | Description |
|---|
| 1 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 1 |
581127901 |
COVER CONSOLE_ASM_HUSQVARNA Price: $44.99 |
| 2 |
532194189 |
SCREW.HWH.13-16-5.8.BZP Price: $4.99 |
| 2 |
94-8197 |
TUBE-PIVOT Price: $19.37 |
| 3 |
33113-030 |
SCREW-HH Price: $0.54 |
| 3 |
581928701 |
CLIP PANEL ERGO 30603 Price: $4.99 |
| 4 |
140-6248 |
DAMPER This part replaces 76-8870. Price: $159.54 |
| 4 |
586723501 |
LIGHT ASM.HUSQVARNA.RH Price: $69.99 |
| 5 |
586723601 |
LIGHT ASM.HUSQVARNA.LH Price: $69.99 |
| 5 |
94-1312 |
SPACER-PIVOT Price: $6.97 |
| 6 |
584290201 |
RP HARNESS.WIRE.LIGHT & GRIP Price: $12.99 |
| 6 |
94-3488-03 |
LEVER-PUMP This part replaces 94-3488. Price: $48.64 |
| 7 |
88-7200 |
WASHER-FLAT Price: $2.51 |
| 8 |
3210-6 |
SCREW-HH Price: $1.76 |
| 9 |
94-9603 |
CABLE SUPPORT Price: $151.76 |
| 10 |
94-9609 |
BUSHING-STRAIGHT Price: $6.08 |
| 11 |
94-4527 |
ARM-NEUTRAL Price: $145.11 |
| 12 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 13 |
93-2111 |
STUD-TRACTION Price: $20.29 |
| 14 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 15 |
75-5470 |
SPACER-BEARING Price: $3.06 |
| 16 |
251-259 |
BEARING-BALL Price: $13.67 |
| 17 |
94-1369 |
SPRING-EXTENSION Price: $12.72 |
| 18 |
18-6380 |
PIN-ADJUSTMENT, STEERING Price: $12.89 |
| 19 |
94-3491 |
BRACKET - SPRING Price: $16.24 |
| 20 |
323-4 |
SCREW-HH Price: $1.02 |
| 21 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 22 |
33114-025 |
SCREW-HH Price: $0.70 |
| 23 |
33114-030 |
SCREW-HH Price: $0.50 |
| 24 |
33114-020 |
SCREW-HH Price: $0.28 |
| 25 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 26 |
2411-34 |
JOINT-BALL Price: $29.99 |
| 27 |
3296-13 |
NUT-LOCK, NI Price: $0.34 |
| 28 |
93-9051 |
DECAL-BOLT, ECCENTRIC Price: $16.37 |
| 29 |
107-2550 |
CABLE-CONTROL, TRACTION This part replaces 93-2099. Price: $194.40 |
| 31 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 32 |
3220-2 |
NUT-JAM Price: $0.50 |
| 33 |
33115-035 |
SCREW-HH Price: $1.15 |
| 34 |
94-3486 |
PLATE Price: $107.60 |
| 35 |
63-9750 |
MOUNT Price: $18.92 |
| 36 |
2844 |
WASHER Price: $2.69 |
| 37 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 38 |
3220-1 |
NUT-JAM Price: $0.99 |
