| Ref | Part Number | Description |
|---|
| 1 |
104-7201 |
NUT-HF Price: $0.69 |
| 1 |
539105024 |
OIL TANK Price: $249.99 |
| 2 |
119-1403-03 |
PEDAL-BRAKE Price: $112.59 |
| 3 |
5-0652 |
SPACER This part replaces 26-4840. Price: $5.35 |
| 3 |
539101165 |
FILTER HEAD Price: $37.99 |
| 4 |
115-8060 |
CLEVIS-DOUBLE Price: $15.64 |
| 4 |
539101202 |
HYDRAULIC CAP Price: $19.99 |
| 5 |
115-8059 |
YOKE-CABLE Price: $11.28 |
| 5 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 6 |
283-14 |
PIN-CLEVIS Price: $2.92 |
| 6 |
596564801 |
Washers This part replaces 539990052. Price: $1.99 |
| 7 |
117-3214 |
CABLE-BRAKE Price: $119.83 |
| 7 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 8 |
119-1407 |
PEDAL-PARK Price: $24.62 |
| 8 |
539101237 |
FITTING, STRAIGHT F6400-8-8-0 Price: $7.99 |
| 9 |
539102396 |
FITTING Price: $11.99 |
| 9 |
99-7140 |
SPRING-TORSION Price: $21.98 |
| 10 |
323-12 |
SCREW-HH Price: $1.14 |
| 10 |
539113782 |
HYDRAULIC FITTING Price: $5.99 |
| 11 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 11 |
539101238 |
ELBOW, F6801-6-6-0 90 DEGREE Price: $12.99 |
| 12 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 12 |
539106067 |
RUBBER HYDRAULIC HOSE (1) Price: $37.99 |
| 13 |
119-1406 |
DETENT-BRAKE Price: $36.40 |
| 13 |
539130386 |
T-ASM, RETURN Price: $89.99 |
| 14 |
119-1405 |
ROD-BRAKE PAWL Price: $24.23 |
| 14 |
539104722 |
HOSE 7" Price: $19.99 |
| 15 |
119-1414 |
PIN-COTTER, LOCKING Price: $0.54 |
| 15 |
539104723 |
T ASM Price: $34.99 |
| 16 |
119-1415 |
PIN-COTTER, LOCKING Price: $0.22 |
| 16 |
539105168 |
NUT 9/16-18 JIC CAP Price: $2.99 |
| 17 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 17 |
539132143 |
HG_PUMP, 10CC W/FAN RIGHT This part replaces 539114834. Price: $1,599.99 |
| 18 |
125-8775 |
BUSHING-FLANGE Price: $1.09 |
| 18 |
539132142 |
HG_PUMP, 10CC W/FAN LEFT This part replaces 539114864. Price: $1,599.99 |
| 19 |
3290-221 |
WASHER-SPRING Price: $3.12 |
| 19 |
539103114 |
O-RING Price: $2.99 |
| 20 |
119-1388 |
PIN-BRAKE Price: $39.02 |
| 20 |
539103115 |
O RING Price: $2.99 |
| 21 |
323-6 |
SCREW-HH Price: $0.66 |
| 21 |
539103117 |
O RING Price: $2.99 |
| 22 |
115-5300 |
PROXIMITY SWITCH ASM Price: $137.95 |
| 22 |
539103118 |
O RING Price: $2.99 |
| 23 |
52-2891 |
BUSHING-FLANGED, NYLON Price: $3.19 |
| 23 |
539103119 |
O RING Price: $3.99 |
| 24 |
323-7 |
SCREW-HH Price: $0.65 |
| 24 |
539106933 |
OIL FILTER BRKT Price: $22.99 |
