| Ref | Part Number | Description |
|---|
| 1 |
05244B |
Housing, Bearing Not Available Price: |
| 2 |
05845C |
Housing, Bearing Price: $16.90 |
| 3 |
918-04515 |
Worm Gear Box Ass’y (w/o grease Fitting) This part replaces 618-04515. Price: $644.97 |
| 4 |
918-0281A |
Bracket Assembly, Auger Brake This part replaces 618-0281A. Price: $60.14 |
| 5 |
684-0090B |
IMPELLER ASSEMBLY Not Available Price: |
| 7 |
684-04151 |
SPIRAL ASSEMBLY (LH) Not Available Price: |
| 8 |
684-04152 |
Spiral Ass’y, RH Price: $190.39 |
| 9 |
710-1245B |
Screw, Hex Cap Lock, 5/16-24 x .875 Gr8 Price: $7.21 |
| 10 |
710-0389 |
Screw, Carriage, 3/8-16 x .75 Price: $3.89 |
| 11 |
710-0451 |
Screw, Carr, 5/16-18 x .75 Price: $3.53 |
| 12 |
710-0459A |
Screw, Hex Cap, 3/8-24 x 1.5 Price: $6.50 |
| 13 |
710-0376 |
Screw, Hex Cap, 5/16-18 x 1.0 Gr5 Price: $3.66 |
| 14 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 15 |
726-04012 |
Nut, Push Price: $6.20 |
| 16 |
710-3008 |
SCREW 5/16-18 x .75 GR5 Price: $3.76 |
| 17 |
710-03168 |
Screw, Carr,3/8-16 x 1.0 Price: Call Us |
| 18 |
710-04606A |
Screw w/Stud, 5/16-18 x .4300 This part replaces 710-04606. Price: $6.41 |
| 19 |
911-0677 |
Ferrule This part replaces 711-0677. Price: $15.59 |
| 20 |
712-0116 |
Nut, Hex Lock, 3/8-24 Price: $3.95 |
| 21 |
712-04063 |
Nut, Flnge Lk, 5/16-18 Price: $3.56 |
| 22 |
712-04065 |
Nut, Flg Lk, 3/8-16 Price: $3.68 |
| 23 |
748-04067A |
Adapter, Pulley w/Pins Price: $23.10 |
| 24 |
714-0104 |
Pin, Internal Cotter Price: $3.90 |
| 25 |
714-0135 |
Key, Woodruff, 1/4 x 3/4 Price: $4.05 |
| 26 |
714-04040 |
Pin, Bowtie Cotter Price: $1.28 |
| 27 |
715-0118 |
Pin, Spirol, 5/16 x 1.75 Price: $10.94 |
| 28 |
731-1696B |
Adapter, Chute, 6" Price: $80.08 |
| 29 |
731-05163 |
Spacer, 1.0 x 1.5 x 1.0Lg Price: $6.28 |
| 30 |
736-0159 |
Washer, Flat, .349 x .879 .063 Price: $3.71 |
| 31 |
731-11421 |
Cleanout Tool Mount This part replaces 731-2635. Price: $9.83 |
| 32 |
931-2643 |
Chute Cleanout Tool This part replaces 731-2643. Price: $16.68 |
| 33 |
732-0858 |
Spring, Extension Price: $23.03 |
| 34 |
736-0174 |
Washer, Wave, .625 x .885 x .015 Price: $5.94 |
| 35 |
736-0505 |
Washer, Flat, .34 x 1.5 x .15 HT Price: $5.65 |
| 36 |
950-04020 |
Spacer, 1.004 x 1.375 x .25 This part replaces 750-04020. Price: $10.75 |
| 37 |
936-3008 |
Flat Washer, .344 x .750 x .120 This part replaces 736-3008. Price: $6.24 |
| 38 |
736-3046A |
Washer, 1.01 x 1.86 x .06 Price: $7.77 |
| 39 |
738-0281 |
Screw, Shoulder, .625 x .17 Price: $9.16 |
| 40 |
738-04155 |
Pin, Shear, .25 x 1.75 Price: $1.60 |
| 41 |
738-04159 |
SPIRAL AXLE 44.12 Not Available Price: |
| 42 |
941-0170 |
Bearing, Flange w/Flats This part replaces 741-0192. Price: $17.84 |
| 43 |
941-04024 |
Bearing, Self Aligning This part replaces 741-04024. Price: $56.93 |
| 44 |
741-0494 |
Bushing, Flange, Price: $3.64 |
| 45 |
747-0980A |
AUGER IDLER ROD Not Available Price: |
| 46 |
749-1117 |
SUPPORT TUBE Not Available Price: |
| 47 |
954-0222A |
V Belt,1/2 x 44 This part replaces 754-0222A. Price: $37.46 |
| 48 |
756-0178 |
Pulley, Flat Idler, 2.75 OD Price: $17.64 |
| 49 |
756-04244A |
Pulley, Auger Drive, 10.0 Price: $53.21 |
| 50 |
784-0385D |
Bracket, Auger Idler This part replaces 784-0385B. Price: $26.17 |
| 51 |
790-00264A-0637 |
Bracket, Gear Box Support This part replaces 790-00264A. Price: $17.52 |
| 52 |
790-00280 |
Plate, Shave, — 45" Price: $49.68 |
| 53 |
784-5697 |
Shoe, Skid Price: $39.82 |
| 54 |
921-0146 |
Oil Seal This part replaces 721-0146. Price: $11.10 |
| 55 |
918-0246 |
GEAR HOUSING ASSEMBLY (RH) Not Available This part replaces 618-0246. Price: |
| 56 |
918-0247 |
Gear Housing Half LH This part replaces 618-0247. Price: $91.27 |
| 57 |
710-1260A |
Scr, LD, 5/16-18 x .750 Price: $3.34 |
| 58 |
711-04714 |
Shf, Drive, Auger Price: $58.83 |
| 59 |
741-0670 |
Flange Bearing Price: $11.48 |
| 60 |
716-0111 |
Ext, Ret, Ring Price: $5.78 |
| 61 |
917-1425 |
Gear, Worm, LH This part replaces 717-1425. Price: $156.25 |
| 62 |
921-0145 |
Seal, Oil This part replaces 721-0145. Price: $8.51 |
| 63 |
736-0266 |
FLAT WASHER Not Available Price: |
| 64 |
736-0291 |
Wash, Flat, .88 ID x .38 OD Price: $10.76 |
| 65 |
738-0275 |
Shf, Gear, Worm Price: $98.40 |
| 66 |
741-0184 |
Bearing, Thrust Price: $14.74 |
| 67 |
941-0217 |
Sleeve This part replaces 741-0217. Price: $16.47 |
| 68 |
721-0325 |
Plug Price: $3.82 |
| 69 |
917-0299 |
Gear, Worm This part replaces 717-0299. Price: $109.34 |
| 70 |
714-0126 |
Key, Hi Pro, 3/16 x 3/4 Price: $4.05 |
| 71 |
710-0276 |
Screw, Carriage, 5/16-18 x 1.0 Price: $3.68 |
| 72 |
941-0475 |
BUSHING .380 ID This part replaces 741-0475. Price: $3.74 |
