Handle & Controls - Type 1-2
Parts (63)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 530027569 | Handle-Starter Price: $1.99 |
| 1 | 94-9959 | BARREL ASM Price: $290.19 |
| 2 | 530036677 | Handle-Upper Price: $8.99 |
| 2 | 94-8142 | HYD CYLINDER ASM This part replaces 94-9960. Price: $802.19 |
| 3 | 530069421 | Kit-Rope Price: $2.99 |
| 3 | 94-8142 | HYD CYLINDER ASM This part replaces 94-9961. Price: $802.19 |
| 4 | 530036985 | Eyelet-Handle Price: $1.99 |
| 4 | 94-8142 | HYD CYLINDER ASM This part replaces 94-9962. Price: $802.19 |
| 5 | 32152-10 | LOCKNUT Price: $0.81 |
| 5 | 530015241 | Screw Price: $1.99 |
| 6 | 530036674 | Assy-Throttle Cable Price: $11.99 |
| 6 | 94-9963 | RING-RETAINING Price: $40.71 |
| 7 | 530015768 | Locknut Price: $1.99 |
| 8 | 530036673 | Trigger-Throttle Price: Call Us |
| 9 | 530036982 | Spring-Throttle Price: $1.99 |
| 10 | 530015999 | Bolt-Shoulder Tube Price: $1.99 |
| 11 | 530095103 | Tube-Lower Handle Price: $11.99 |
| 12 | 530036983 | Coupling-Handle Price: $2.99 |
| 13 | 530036981 | Spring-Isolator Price: $1.99 |
| 14 | 530015774 | Screw Price: $1.99 |
| 15 | 530036984 | Spring-Handle Price: $2.99 |
| 16 | 530036676 | Handle-Lower Price: $6.99 |
| 17 | 503210719 | Screw Price: $1.99 |
| 18 | 530095104 | Tube-Upper Handle Price: $11.99 |
| 19 | 530015768 | Locknut Price: $1.99 |
| 20 | 530015982 | Clamp-Cable Price: $0.99 |
| 21 | 530095663 | Wheel-Rear Price: $5.99 |
| 22 | 530095629 | Shield-Front Blade Price: $7.99 |
| 23 | 530015843 | Screw Price: $1.99 |
| 24 | 530016281 | Washer-Belleville Price: $1.99 |
| 25 | 530016032 | Nut Price: $1.99 |
| 26 | 530036935 | Plug-Dust Price: Call Us |
| 27 | 530015770 | Screw Price: Call Us |
| 28 | 530037625 | Retainer Ring-Flat Price: $0.99 |
| 29 | 530095070 | Shaft-Output Price: $14.99 |
| 30 | 530016042 | Washer-Thrust Price: $1.99 |
| 31 | 530038308 | Retainer-Fuel Line Price: $1.99 |
| 32 | 530015886 | Screw Price: $1.99 |
| 33 | 530015774 | Screw Price: $1.99 |
| 34 | 530015922 | Nut-Speed Price: $1.99 |
| 35 | 530019199 | Gasket-Tube Price: $1.99 |
| 36 | 530015997 | Pin-Axle Price: $1.99 |
| 37 | 530016002 | Bridge-Pin Price: $1.99 |
| 38 | 530015768 | Locknut Price: $1.99 |
| 39 | 530038301 | Cover-Axle Price: $5.99 |
| 40 | 530016063 | Nut-Swing Arm Price: $1.99 |
| 42 | 530053792 | Assy-Lever Adjustment Price: $4.99 |
| 43 | 530054071 | Foot-Skid Price: $4.99 |
| 44 | 530053501 | Arm-Swing Price: $2.99 |
| 45 | 530015814 | Screw Price: $1.49 |
| 46 | 530038299 | Housing-Fan Price: $14.36 |
| 47 | 530016386 | Screw Price: $5.99 |
| 48 | 530015940 | Screw Price: $1.99 |
| 49 | 530015814 | Screw Price: $1.49 |
| 50 | 530053544 | Plate-Back Price: $2.99 |
| 51 | 530053626 | Assy-Gear Box Price: $78.99 |
| 52 | 530016040 | Washer-Bolt Adjust Price: $1.99 |
| 53 | 530016280 | Washer-Wave Price: $1.99 |
| 54 | 530016275 | Bolt-Shoulder Price: $1.99 |
| 55 | 530036934 | Assy-Bearing Holder Price: $40.99 |
| 56 | 530015814 | Screw Price: $1.49 |
| 57 | 530095086 | Blade Price: $4.99 |
| 58 | 530071258 | Kit-Gear Set Price: $14.99 |
