| Ref | Part Number | Description |
|---|
| 1 |
112-7680-01 |
LH FORK ASM This part replaces 20-9140. Price: $614.00 |
| 1 |
140310 |
Control Th/ch 23 5 LH Flag (AYP part number) Price: Call Us |
| 2 |
17720410 |
Screw Hex Thd Cut 1/4-20 x 5/8 T Price: Call Us |
| 2 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 3 |
20-9550 |
SPRING-COMPRESSION Price: $7.70 |
| 4 |
137352 |
Muffler LT B&S 14.5 Price: Call Us |
| 4 |
20-9430-01 |
WEIGHT This part replaces 20-9430. Price: $912.11 |
| 5 |
67-1300 |
DECAL This part replaces 18-6900. Price: $29.99 |
| 6 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 7 |
323-10 |
SCREW-HH Price: $0.89 |
| 8 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 9 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 10 |
20-9040 |
DISCONTINUED Price: Call Us |
| 11 |
3217-6 |
NUT-HEX Price: $1.19 |
| 12 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 13 |
272293 |
Gasket Eng 1 313 Id Tin Plated Price: Call Us |
| 13 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 14 |
13280324 |
Nipple Pipe 3/8 Npt X 3" Price: Call Us |
| 14 |
251-253 |
BEARING Price: $22.84 |
| 15 |
13200300 |
Elbow Std 90 Degree 3/8-18 Npt Price: Call Us |
| 15 |
251-255 |
FLANGE Price: $15.34 |
| 16 |
11050600 |
Washer Lock Ext Tooth 3/8 Price: Call Us |
| 16 |
32151-44 |
RING-RETAINING Price: $2.99 |
| 17 |
20-9490 |
WASHER Price: $8.14 |
| 18 |
20-7400 |
SPACER-END Price: $11.87 |
| 19 |
20-7380-01 |
BLADE-SPIKE, PROFILED This part replaces 20-7380. Price: $36.82 |
| 20 |
20-9480 |
SPACER Price: $12.27 |
| 21 |
92-7196 |
SHAFT This part replaces 20-9470. Price: $440.72 |
| 22 |
20-9460 |
KEY-SQUARE Price: $75.81 |
| 23 |
156123 |
Shield Heat Price: Call Us |
| 23 |
20-9500 |
WASHER Price: $3.53 |
| 24 |
251-253 |
BEARING This part replaces 251-254. Price: $22.84 |
| 25 |
20-9540 |
KEY-SQUARE Price: $4.74 |
| 26 |
112-7690-01 |
HUB ASM This part replaces 20-9980. Price: $197.32 |
| 27 |
20-9530 |
WASHER-END Price: $28.36 |
| 28 |
323-7 |
SCREW-HH Price: $0.65 |
| 29 |
137180 |
Kit Spark Arrestor (Flat Scrn) Price: Call Us |
| 31 |
140280 |
Tank Fuel Front 2 00 Price: Call Us |
| 32 |
140527 |
Cap Asm Fuel W/sym Vented Price: Call Us |
| 33 |
123487X |
Clamp Hose Black Price: Call Us |
| 35 |
17490512 |
Screw Price: Call Us |
| 37 |
137040 |
Line Fuel 20" Price: Call Us |
| 40 |
124028X |
Bushing Snap Nyl Blk Fuel Line (AYP part number) Price: Call Us |
| 44 |
17490412 |
Screw Hexwsh Thdrol 1/4-20 x 3/4 Price: Call Us |
| 46 |
19091416 |
Washer 9/32 X 7/8 X 16 Ga Price: Call Us |
| 49 |
17490616 |
Screw Thdrol 3/8-16 x 1 Price: Call Us |
| 62 |
10040500 |
Washer Lock Hvy Hlcl Spr 5/16 Price: Call Us |
| 72 |
71070512 |
Screw Hexhd Cap 5/16-18 x 3/4 Price: Call Us |
| 78 |
17490620 |
Screw Thdrol 3/8-16 x 1-1/4 TYTT Price: Call Us |
| 81 |
128861 |
Nut Flange 1/4-20 Starter Nut Price: Call Us |
| 90 |
159520 |
Guard Debris 97 Price: Call Us |
| 91 |
17000612 |
Bolt Blk Fin Hex 1/4-20 Unc x 1/2 Price: Call Us |
| 92 |
19091016 |
Washer 9/32 x 5/8 x 16 Ga. Price: Call Us |
