| Ref | Part Number | Description |
|---|
| 1 |
32122-14 |
SCREW-PPH Price: $1.02 |
| 1 |
545006008 |
Kit-Trigger/Lockout Price: $1.26 |
| 2 |
3272-15 |
PIN-COTTER Price: $0.47 |
| 2 |
545011912 |
Cover-Handle Price: $7.99 |
| 3 |
3-8993 |
DISCONTINUED Price: Call Us |
| 3 |
530016433 |
Screw Price: $1.99 |
| 4 |
5-2512 |
BUSHING Price: $15.80 |
| 4 |
530023877 |
Fitting-Fuel Line Price: $1.99 |
| 5 |
5-1636 |
DISCONTINUED Price: Call Us |
| 6 |
3-8991 |
DISCONTINUED Price: Call Us |
| 7 |
3-8988 |
DISCONTINUED Price: Call Us |
| 7 |
530095646 |
Assy-Fuel Pick Up Price: $2.99 |
| 8 |
5-1635 |
DISCONTINUED Price: Call Us |
| 8 |
545012112 |
Handle-Rear Price: $11.99 |
| 9 |
3217-12 |
NUT-HEX Price: $3.12 |
| 9 |
530059475 |
Spring-Rear Isolator Price: $5.99 |
| 10 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 10 |
530071945 |
Kit-Clutch Washer Price: $3.99 |
| 11 |
329649 |
Nut Price: Call Us |
| 11 |
530057905 |
Assy-Clutch Drum 3/8" Price: $14.99 |
| 12 |
3-8514 |
WASHER-THRUST Price: $1.58 |
| 12 |
530071945 |
Kit-Clutch Washer Price: $3.99 |
| 13 |
237-82 |
DISCONTINUED Price: Call Us |
| 13 |
530057907 |
Assy-Clutch Price: $6.99 |
| 14 |
3-8864 |
DISCONTINUED Price: Call Us |
| 14 |
530016419 |
Washer-Large Clutch Price: $1.99 |
| 15 |
3296-50 |
NUT-LOCK, NI Price: $2.68 |
| 15 |
530015906 |
Screw Price: $1.99 |
| 16 |
580940901 |
FUEL CAP ASSY This part replaces 530047192. Price: $3.99 |
| 17 |
3-8975 |
DISCONTINUED Price: Call Us |
| 17 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 18 |
530015922 |
Nut-"U" type speed Price: $1.99 |
| 18 |
61-3610 |
WARNING DECAL This part replaces 40-7490. Price: $16.67 |
| 19 |
5-3928 |
DISCONTINUED Price: Call Us |
| 19 |
573992801 |
KIT MODULE & FLYWHEEL This part replaces 530039231. Price: $39.99 |
| 20 |
3220-17 |
NUT-JAM, LH Price: $6.25 |
| 20 |
530057911 |
Shield-Heat Price: $2.99 |
| 21 |
5-4785 |
FRONT PUSH ROD WA Price: $112.24 |
| 21 |
530015127 |
Washer-Flywheel Price: $1.99 |
| 22 |
3217-9 |
NUT-HH Price: $0.37 |
| 22 |
530016134 |
Nut-Flywheel Price: $1.99 |
| 23 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 23 |
530021179 |
Screw-Shoulder Price: $1.99 |
| 24 |
5-1091 |
SPACER Price: $4.98 |
| 24 |
530059677 |
Starter Hub-EPS Price: $5.99 |
| 25 |
3-8992 |
DISCONTINUED Price: Call Us |
| 25 |
530021180 |
Spring-EPS Price: $1.99 |
| 26 |
3251-2 |
SCREW-PPH Price: $0.27 |
| 27 |
3-9347 |
DISCONTINUED Price: Call Us |
| 27 |
545011701 |
Housing-Fan Price: $11.99 |
| 28 |
3-9373 |
DISCONTINUED Price: Call Us |
| 28 |
545006107 |
Handle-Starter Price: Call Us |
| 29 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 29 |
530069232 |
Kit-Rope Price: $3.99 |
| 30 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 30 |
530016432 |
Screw Price: $1.99 |
| 31 |
3217-26 |
NUT-HEX Price: $0.25 |
| 31 |
545008013 |
Kit-Starter Spring This part replaces 530042095. Price: $3.99 |
| 32 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 32 |
530016080 |
Screw Price: $1.99 |
| 33 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 33 |
530057868 |
Baffle Price: $5.99 |
| 34 |
321-2 |
SCREW-HH Price: $2.79 |
| 34 |
530058786 |
Assy-Oil Vent Price: $2.99 |
| 35 |
2710-20 |
LINK-OFFSET Price: $10.06 |
| 35 |
530057236 |
Assy-Oil Cap w/ret. Price: $5.99 |
| 36 |
5-3887 |
DISCONTINUED Price: Call Us |
| 36 |
530057880 |
Handguard Price: $27.99 |
| 37 |
28-1220 |
SPROCKET ASM *R Price: $503.87 |
| 37 |
530016416 |
Spring-Handguard Price: $1.99 |
| 38 |
3296-42 |
NUT-LOCK, NI This part replaces 32146-17. Price: $0.28 |
| 39 |
42-3320 |
DISCONTINUED Price: Call Us |
| 39 |
530071893 |
Kit-Chainbrake Price: $17.99 |
| 40 |
5-1895 |
REEL DRIVE PAD Price: $33.67 |
| 40 |
530016432 |
Screw Price: $1.99 |
| 41 |
256-161 |
DISCONTINUED Price: Call Us |
| 41 |
530016133 |
Bolt-Bar Price: $1.99 |
| 42 |
256-205 |
DISCONTINUED Price: Call Us |
| 42 |
530057910 |
Plate-Bar Price: $1.99 |
| 43 |
321-14 |
SCREW-HH Price: $0.55 |
| 43 |
530015917 |
Nut-Bar Price: $0.99 |
| 44 |
42-3310 |
DISCONTINUED Price: Call Us |
| 45 |
42-3300 |
DISCONTINUED Price: Call Us |
| 46 |
40-7150 |
DISCONTINUED Price: Call Us |
| 46 |
530015826 |
Pin-Bar Adjust Price: $1.99 |
| 47 |
3-8786 |
DISCONTINUED Price: Call Us |
| 47 |
530038593 |
Retainer-Bar Adjust Price: $0.99 |
| 48 |
3217-6 |
NUT-HEX Price: $1.19 |
| 48 |
581562301 |
P/PP CHN 18" 62DL 3/8 .050 This part replaces 952051338. Price: $19.99 |
| 49 |
32534 |
Lockwasher Price: Call Us |
| 49 |
952044418 |
Accy-18" Bar Price: $30.95 |
| 50 |
321-4 |
SCREW-HH Price: $0.99 |
| 50 |
530016432 |
Screw Price: $1.99 |
| 51 |
40-7170 |
DISCONTINUED Price: Call Us |
| 51 |
530016443 |
Screw Price: $1.99 |
| 52 |
5-1937 |
DISCONTINUED Price: Call Us |
| 52 |
530059480 |
Assy-Rear Iso. Spring Price: $3.99 |
| 53 |
530015906 |
Screw Price: $1.99 |
| 54 |
3272-22 |
PIN-COTTER Price: $0.61 |
| 54 |
530059479 |
Assy-Front Iso. Spring Price: $6.99 |
| 55 |
3-8664 |
WASHER-THRUST Price: $5.69 |
| 55 |
530057878 |
Handle-Front Price: $14.99 |
| 56 |
3-8863 |
DISCONTINUED Price: Call Us |
| 56 |
530016432 |
Screw Price: $1.99 |
| 58 |
3220-7 |
NUT-JAM Price: $4.09 |
| 58 |
530057924 |
Assy-Oil Pick Up Price: $2.99 |
| 59 |
5-1627 |
DISCONTINUED Price: Call Us |
| 60 |
3-8955 |
DISCONTINUED Price: Call Us |
| 60 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 61 |
5-3877 |
DISCONTINUED Price: Call Us |
| 61 |
581071401 |
OIL PUMP ASSY SAS This part replaces 530057931. Price: $5.99 |
| 62 |
3-9038 |
DISCONTINUED Price: Call Us |
| 63 |
5-0746 |
DISCONTINUED Price: Call Us |
