| Ref | Part Number | Description |
|---|
| 1 |
09267300 |
PIN, PIVOT/TRUNNION Price: $6.45 |
| 2 |
06500826 |
NUT,LK-CTR .31-18 GA ZCC This part replaces 06529800. Price: $1.45 |
| 3 |
08873000 |
PTO LINK ROD, PRO-150 Price: $30.95 |
| 4 |
08328500 |
SG-COMP .142 X .710 X 2.00 Price: $18.45 |
| 5 |
06401013 |
WSHR-FLT .406X.812X.065 ZCC This part replaces 06436200. Price: $0.95 |
| 6 |
06500917 |
NUT-STD .375-16 G2 ZCC This part replaces 06529400. Price: $0.95 |
| 7 |
09267600 |
WMT, BRAKE CROSS SHAFT Price: $24.95 |
| 8 |
05517400 |
BSHG-FLG .630X1.000X.625 NY Price: $6.45 |
| 9 |
09267700 |
SLIDE, INTERLOCKING BRAKE Price: $20.45 |
| 10 |
05534100 |
BUSHING, FLANGED (WITH HOLE) Price: $36.95 |
| 11 |
05709200 |
RG-RTNG-EXT .625X.050 Price: $2.45 |
| 12 |
05518400 |
BSHG-FLG .762X1.0X.580X1.48 NY Price: $4.45 |
| 13 |
05503100 |
BSHG-FLG.500X.750X.750X1.000BR Price: $8.95 |
| 14 |
05500900 |
BSHG-SLV .750X1.000X.750 Price: $8.95 |
| 15 |
06608700 |
KEY-WDRF .19X.75 HRD #9 Price: $0.95 |
| 16 |
09267900 |
WMT, BRAKE ARM Price: $133.45 |
| 17 |
05709200 |
RG-RTNG-EXT .625X.050 Price: $2.45 |
| 18 |
09268000 |
WMT, MECHANICAL BRAKE Price: $148.45 |
| 20 |
00277400 |
WMT, BRAKE ACTUATING This part replaces 09269300. Price: $76.95 |
| 21 |
06608400 |
KEY-WDRF .13X.63 HRD#5 Price: $2.45 |
| 22 |
05901803 |
BLT, HEX .31-18X1.25 G5 ZCC This part replaces 05947500. Price: $2.45 |
| 23 |
05717100 |
RG-RTNG-EXT .500X.050 (SNAP) Price: $2.45 |
| 24 |
07505200 |
KNOB-STEERING LOCK Price: $19.95 |
| 25 |
09268400 |
LINKAGE, BRAKE ACTUATING Price: $26.95 |
| 26 |
09275900 |
INTERLOCK, SAFETY SWITCH Price: $15.45 |
| 27 |
09200600 |
PAD SET, DISK BRAKE Price: $46.95 |
| 28 |
06500904 |
NUT-LK-TOP-FLG .312-18 GF ZCC This part replaces 06543100. Price: $0.95 |
| 29 |
09268300 |
LINKAGE, BRAKE ACTUATING Price: $26.95 |
| 30 |
08314100 |
SG-TENS .063X.44X1.56 Price: $5.45 |
| 31 |
06401112 |
WSHR, FLT .505X1.00X.062 ZCC This part replaces 06439200. Price: $0.95 |
| 32 |
09268100 |
WMT, PARKING BRAKE HUB Price: $132.95 |
| 33 |
07012600 |
FTG-LUBE .25-28X.256 YWZC Price: $3.45 |
| 34 |
05901704 |
BLT-HEX .31-18X.75 G5 ZCC This part replaces 05947000. Price: $1.45 |
| 35 |
06500904 |
NUT-LK-TOP-FLG .312-18 GF ZCC This part replaces 06543100. Price: $0.95 |
