| Ref | Part Number | Description |
|---|
| 1 |
22-8330 |
PLUG Price: $64.59 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 1 |
703-2135 |
STEERING SUPPORT Not Available Price: |
| 2 |
237-42 |
O-RING Price: $2.78 |
| 2 |
747-3016 |
CLAMP Not Available Price: |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
22-8340 |
SPRING Price: $19.09 |
| 3 |
712-0237 |
Nut, Hex Center Lock, 5/16-24 Price: $4.37 |
| 4 |
22-8350 |
BALL Price: $12.28 |
| 4 |
710-1260A |
Self Tapping Screw, 5/16-18 x .75 This part replaces 710-3004. Price: $3.34 |
| 5 |
22-8370 |
SEAT-VALVE Price: $88.05 |
| 5 |
736-0242 |
Washer, Bell, .345 X .88 X .060 Thk Price: $3.75 |
| 6 |
22-8360 |
PIN Price: $43.02 |
| 6 |
912-3057 |
Hex Nut, 5/16-24 This part replaces 712-3057. Price: $5.94 |
| 7 |
712-3000 |
Nut, Hex Center Lock, 3/8-16 GR5 Price: $3.90 |
| 8 |
22-8420 |
SPOOL Price: $437.22 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $14.99 |
| 8 |
736-0169 |
Washer, Lock, 3/8 Price: $3.33 |
| 9 |
22-8500 |
O-RING Price: $18.87 |
| 9 |
703-1857 |
BRACKET-PWR STEER BOX Not Available Price: |
| 10 |
22-8380 |
RETAINER Price: $17.86 |
| 11 |
22-8410 |
SPRING Price: $17.61 |
| 11 |
710-0216 |
Bolt, 3/8 X 3/4 Type 5 This part replaces 710-3000. Price: $3.93 |
| 12 |
22-8390 |
RETAINER Price: $56.56 |
| 13 |
22-8400 |
SPACER Price: $42.41 |
| 14 |
22-8480 |
RING-SNAP Price: $49.87 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 This part replaces 532400253. Price: $7.99 |
| 25 |
585555501 |
CABLE.STARTER.8GA.17.5 This part replaces 532412895. Price: $7.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT This part replaces 532411933. Price: $8.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
532402167 |
HARNESS IGN. DASH Price: $99.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 45 |
529910801 |
AMMETER This part replaces 532425270. Price: $27.99 |
| 46 |
529910701 |
HOUR METER This part replaces 532425271. Price: $69.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 59 |
596941001 |
Outlets This part replaces 532400303. Price: $11.99 |
| 71 |
532194276 |
HARNESS-CHASSIS SUB Price: $27.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT(2 2) Price: $7.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 100 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
| 103 |
532421747 |
HARNESS.PIGTAIL.12V.OUTLET. Price: $12.99 |
