| Ref | Part Number | Description |
|---|
| 1 |
111-9940 |
STEERING CYLINDER ASM This part replaces 92-4724. Price: $274.42 |
| 1 |
532126470 |
CLIP,INSULATOR Price: $3.99 |
| 2 |
237-78 |
O-RING Price: $3.85 |
| 2 |
532122018 |
BRKT CLUTCH Price: $2.38 |
| 3 |
237-80 |
O-RING Price: $6.10 |
| 3 |
596437001 |
Screws This part replaces 874780408. Price: $2.99 |
| 4 |
340-54 |
ELBOW-45 DEG Price: $40.72 |
| 4 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 5 |
340-14 |
FITTING-HYD, 45 DEG Price: $42.29 |
| 5 |
532145187 |
CLUTCH LEVER This part replaces 532123417. Price: $5.69 |
| 6 |
237-65 |
O-RING Price: $2.50 |
| 6 |
532106451 |
BOLT, SHOULDER LT Price: $2.99 |
| 7 |
532123491 |
CLUTCH ARM ASS'Y Price: $6.49 |
| 7 |
94-8271 |
TRACTION HOSE ASM Price: $127.83 |
| 8 |
106-6895-03 |
BALL JOINT ASM This part replaces 69-9810. Price: $258.08 |
| 8 |
874760636 |
BOLT Price: $4.99 |
| 9 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 9 |
532121930 |
BELLCRANK,LIFT Price: $11.99 |
| 10 |
237-22 |
O-RING Price: $2.43 |
| 10 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 11 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 11 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 12 |
115-8015 |
CYLINDER-HYDRAULIC This part replaces 92-6057. Price: $905.66 |
| 12 |
532122027 |
GRIP HANDLE Price: $5.72 |
| 13 |
32136-13 |
NUT-SHH Price: $2.85 |
| 13 |
532122741 |
LIFT HANDLE ASS'Y Price: $13.31 |
| 14 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 14 |
532123496 |
SPRING COMPRESSIO Price: $2.99 |
| 15 |
48-6640 |
BEARING Price: $10.04 |
| 15 |
596134901 |
GSPH This part replaces 819131212. Price: $2.99 |
| 16 |
48-6660 |
WASHER Price: $5.22 |
| 16 |
532004921 |
COTTER PIN Price: $4.99 |
| 17 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 17 |
532123654 |
LINK FRT LIFT Price: $28.99 |
| 18 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 18 |
532142028 |
TRUNNION.ADJUSTABLE.3/8-16 This part replaces 532007078. Price: $3.99 |
| 19 |
69-8890 |
CAP-SPINDLE Price: $13.32 |
| 19 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 20 |
32151-10 |
RING-RETAINING Price: $0.81 |
| 20 |
874760644 |
BOLT Price: $3.99 |
| 21 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 21 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 22 |
532121929 |
BRKT,MOWER HGT Price: $2.38 |
| 22 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 23 |
596029601 |
Pins This part replaces 876020416. Price: $1.99 |
| 23 |
92-4755-03 |
REAR AXLE ASM This part replaces 92-4755. Price: $1,618.24 |
| 24 |
596040101 |
Washers This part replaces 819171616. Price: $2.99 |
| 24 |
86-6560 |
WASHER-THRUST Price: $29.68 |
| 25 |
532121933 |
TUBE SPACER Price: $4.28 |
| 25 |
92-4779-03 |
LH MOTOR HOUSING ASM This part replaces 92-4779. Price: $969.47 |
| 26 |
532141470 |
LIFT ROD This part replaces 532121934. Price: $14.65 |
| 26 |
92-4749-03 |
HUB-WHEEL This part replaces 92-4749. Price: $96.67 |
| 27 |
532121466 |
KNOB Price: $3.99 |
| 27 |
69-9880 |
TIRE (23X10.5-12) 6-PLY Price: $189.93 |
| 28 |
217-116 |
WHEEL Price: $258.19 |
| 28 |
596917601 |
Pins This part replaces 876020312. Price: $1.99 |
| 29 |
532123671 |
LINK,MOWER LIFT Price: $8.99 |
| 29 |
83-2720 |
BOLT-LUG Price: $3.69 |
| 30 |
99-3139 |
NUT This part replaces 11-5800. Price: $16.11 |
| 31 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 32 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 33 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 34 |
110-6141-03 |
RH TIE ROD END ASM This part replaces 2116-4. Price: $148.18 |
| 35 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 36 |
2412-7 |
CLAMP ASM Price: $23.32 |
| 37 |
324-9 |
SCREW-HH Price: $1.76 |
| 38 |
110-9719-03 |
TIE ROD ASM This part replaces 82-9260. Price: $380.21 |
| 39 |
32146-7 |
NUT-LOCK, INSERT Price: Call Us |
| 40 |
32136-2 |
NUT-SHH Price: $3.55 |
| 41 |
11-5790 |
KEY-SQUARE Price: $17.50 |
| 42 |
3274-5 |
SCREW-HSH Price: $4.00 |
| 43 |
58-6520 |
DECAL-GREASE Price: $2.57 |
| 44 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 45 |
82-9210 |
SHAFT-PIVOT Price: $187.73 |
| 46 |
60-3670 |
PIN Price: $12.56 |
| 47 |
92-5664 |
HOSE ASM Price: $276.42 |
| 48 |
94-8272 |
TRACTION HOSE ASM Price: $114.06 |
