| Ref | Part Number | Description |
|---|
| 1 |
140-5567 |
SHAFT ASM, GROOMER This part replaces 125-3478. Price: $404.92 |
| 1 |
532851509 |
Control Bar (AYP part number) Price: $3.33 |
| 2 |
140-5582 |
BLADE-GR GROOMER, HELIX (0.015") This part replaces 127-6124. Price: $3.07 |
| 2 |
532125338 |
UPPER HANDLE This part replaces 532125306. Price: $17.99 |
| 3 |
140-5616 |
SPACER-SS This part replaces 70-1350. Price: $2.60 |
| 3 |
532157081 |
HANDLE.LOWER.BLACK This part replaces 532125160. Price: $54.99 |
| 4 |
532194788 |
GUIDE.ROPE.STD.BLK.ZIN This part replaces 532132001. Price: $3.99 |
| 5 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 6 |
532183724 |
KNOB.HANDLE.KIT.SERVICE This part replaces 532131959. Price: $6.99 |
| 7 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $3.99 |
| 8 |
874250434 |
Machine Screw 1/4-20 x 2-1/8 (AYP part number) This part replaces 532085692. Price: $2.99 |
| 9 |
532700417 |
Throttle Control This part replaces 532132536. Price: $12.99 |
| 10 |
532085723 |
Washer (AYP part number) Price: $2.99 |
| 11 |
532851671 |
Engine Zone Control Cable (AYP part number) Price: $11.99 |
| 12 |
532801722 |
Drive Control Price: Call Us |
| 13 |
532750029 |
Pan Head Manchine Screw #10-24 x 2 (AYP part number) Price: $3.99 |
| 14 |
532128638 |
Wing Nut (AYP part number) Price: $3.99 |
| 15 |
532051793 |
Hairpin Cotter (AYP part number) Price: $3.99 |
| 16 |
532074189 |
Locknut, #10-24 (AYP part number) Price: $2.42 |
| 17 |
532077553 |
Cable Guide (AYP part number) Price: $3.33 |
| 18 |
532088092 |
Cable Guide (AYP part number) Price: $8.35 |
| 19 |
532125313 |
Back Plate (AYP part number) Price: Call Us |
| 20 |
532125312 |
Side Baffle (AYP part number) Price: $9.41 |
| 21 |
532189009 |
SKIRT.20RD/SD.FO/VE.BO WHEELS This part replaces 532136233. Price: $11.99 |
| 22 |
532085768 |
Self-Tapping Screw #10-24 x 3/4 (AYP part number) Price: $2.38 |
| 23 |
532048138 |
Rear Door Assembly Kit (AYP part number) Price: $79.99 |
| 24 |
873680600 |
LOCKNUT This part replaces 532751592. Price: $1.99 |
| 25 |
532125305 |
Handle Bracket Assembly (Left) (AYP part number) Price: $3.33 |
| 26 |
532125193 |
Handle Bracket Assembly (Right) (AYP part number) Price: $3.33 |
| 27 |
532055187 |
Screw 5/16-18 x 3/4 (AYP part number) Price: $3.99 |
| 28 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 532063124. Price: $2.99 |
| 29 |
532139901 |
Wheel Adjusting Bracket (AYP part number) This part replaces 532850955. Price: $5.99 |
| 30 |
532084920 |
Spacer (AYP part number) Price: $1.99 |
| 31 |
532851552 |
Self-Tapping Screw #10-24 x 5/8 (AYP part number) Price: $2.99 |
| 32 |
532125168 |
Selector Spring (AYP part number) Price: $2.99 |
| 33 |
532087877 |
Selector Knob (AYP part number) Price: $2.99 |
| 34 |
532187930 |
ARM.ASM.AXLE. This part replaces 532125172. Price: $9.99 |
| 35 |
532062335 |
Belleville Washer (AYP part number) Price: $6.99 |
| 36 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532084921. Price: $3.99 |
| 37 |
532850957 |
Wheel & Tire Assembly 8.0 x 1-3/4 (AYP part number) Price: $119.99 |
| 38 |
532052160 |
Washer (AYP part number) Price: $3.99 |
| 39 |
532085179 |
Retainer Clip (AYP part number) Price: $3.99 |
| 40 |
532077400 |
Hubcap (AYP part number) Price: $3.99 |
| 41 |
532088652 |
Hinge Screw (AYP part number) Price: $3.99 |
| 42 |
532053998 |
Flat Washer (AYP part number) Price: $3.71 |
| 43 |
532054583 |
Hex Tapping Screw 1/4-20 x 1/2 (AYP part number) Price: $3.99 |
| 44 |
872070505 |
Hex Head Bolt 5/16-18 x 5/8 (AYP part number) Price: Call Us |
| 45 |
532850999 |
Hex Head Thread Rolling Screw 3/8-16x1 (AYP part number) Price: $3.99 |
| 46 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $4.99 |
| 47 |
532750346 |
Bracket Cover (AYP part number) This part replaces 532088615. Price: $2.42 |
| 48 |
532850988 |
Engine Spacer (AYP part number) Price: $5.99 |
| 49 |
532850988 |
Spacer (AYP part number) This part replaces 532850987. Price: $5.99 |
| 50 |
539976978 |
NUT 1/4-20 NYLOC This part replaces 532063601. Price: $1.99 |
| 51 |
532135311 |
Front Baffle (AYP part number) Price: Call Us |
| 53 |
532851084 |
Hex Head Bolt 3/8-24 x 1-3/8 Grd. 8 Price: $2.99 |
| 54 |
539990118 |
SLW 3/8 STD This part replaces 532850263. Price: $1.99 |
| 55 |
532851074 |
Hardened Washer (AYP part number) Price: $2.99 |
| 57 |
581547901 |
ADAPTOR.BLADE.7/8 This part replaces 532851514. Price: $11.99 |
| 65 |
532083816 |
Screw #10 x 5/8 (AYP part number) Price: $3.99 |
| 67 |
532128013 |
Grass Bag (AYP part number) Price: Call Us |
| 68 |
532750532 |
Catcher Frame (AYP part number) Price: $45.63 |
| 72 |
532128415 |
Pop Rivet (AYP part number) Price: $2.99 |
