| Ref | Part Number | Description |
|---|
| 1 |
114-0352-0P |
PLATE - BRIDGE, NO 23 This part replaces 114-0352-01. Price: $37.90 |
| 2 |
136-3492 |
NO 2 LIFT ARM ASM This part replaces 114-0382-03. Price: $371.83 |
| 3 |
136-3493 |
NO 3 LIFT ARM ASM This part replaces 114-0383-03. Price: $322.38 |
| 4 |
325-5 |
SCREW-HH Price: $1.20 |
| 5 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 6 |
327-7 |
SCREW-HH Price: $5.69 |
| 7 |
99-5107 |
NUT-LOCK Price: $1.77 |
| 8 |
325-7 |
SCREW-HH Price: $1.53 |
| 9 |
117-0208 |
SHAFT-PIVOT, LIFTARM Price: $96.42 |
| 10 |
105-7560 |
SHAFT-CU PIVOT Price: $73.74 |
| 11 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 12 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 13 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 14 |
323-6 |
SCREW-HH Price: $0.66 |
| 16 |
136-3515 |
CARRIER FRAME ASM This part replaces 108-7384-03. Price: $370.25 |
| 17 |
32121-122 |
PIN-ROLL Price: $2.93 |
| 18 |
136-3568 |
PIN-FLAG (MACH) This part replaces 117-0132. Price: $14.65 |
| 19 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 20 |
322-3 |
SCREW-HH Price: $0.79 |
| 21 |
117-0118 |
PIVOT ASM Price: $85.03 |
| 22 |
323-11 |
SCREW-HH Price: $1.08 |
| 23 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 24 |
99-7667 |
WASHER-FLAT Price: $4.80 |
| 25 |
127-2613-03 |
GUARD-FOOT, LH Price: $52.42 |
| 26 |
127-2614-03 |
GUARD-FOOT, RH Price: $52.42 |
