| Ref | Part Number | Description |
|---|
| 1 |
110-4100 |
HOSE-FUEL This part replaces 23-2140. Price: $28.86 |
| 1 |
532439818 |
DECK SVC 48" 4GWB 197216X431 This part replaces 532403582. Price: $599.99 |
| 2 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 3 |
32128-44 |
NUT Price: $2.69 |
| 4 |
110-9662 |
HOSE-FUEL This part replaces 51-0670. Price: $31.52 |
| 5 |
132-8621 |
BATTERY CORROSIVE This part replaces 83-9000. Price: $292.68 |
| 6 |
532197248 |
COVER.MANDREL.LH.48"(2 2) Price: $19.99 |
| 6 |
93-6775 |
CABLE-BATTERY, POS Price: $111.66 |
| 7 |
587452401 |
COVER.RH.MANDREL This part replaces 532199102. Price: $17.99 |
| 7 |
94-5980 |
CABLE-BATTERY, NEG This part replaces 83-9210. Price: $92.64 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 532174365. Price: $6.99 |
| 8 |
56-2520 |
FITTING-SHUT OFF, FUEL Price: $31.19 |
| 9 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 10 |
56-2230 |
HOSE-FUEL Price: $3.66 |
| 11 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 12 |
596274401 |
Rods This part replaces 532400337. Price: $9.99 |
| 12 |
83-8720 |
TANK-FUEL Price: $576.65 |
| 13 |
597023501 |
MANDRELS This part replaces 532187291. Price: $24.99 |
| 13 |
75-4703 |
HOSE Price: $16.06 |
| 14 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 15 |
63-8410 |
WASHER Price: $1.76 |
| 16 |
323-5 |
SCREW-HH Price: $0.41 |
| 16 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 17 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 17 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 18 |
83-9240 |
BRACKET-BATTERY Price: $32.49 |
| 19 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 20 |
531167501 |
SERVICE KIT BAFFLE BAFFLE This part replaces 532174378. Price: $12.99 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $4.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
532180655 |
DEFLECTOR.ASM.BLACK.48" This part replaces 532181707. Price: $39.99 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532173435 |
MANDREL.PULLEY.38.BRIGHT.ZINC This part replaces 532153532. Price: $19.99 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 39 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH This part replaces 532197380. Price: $37.99 |
| 43 |
531169301 |
SERVICE KIT ARM.IDLER This part replaces 532196065. Price: $9.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
593773401 |
Belts- 197242 This part replaces 532197242. Price: $54.99 |
| 48 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 50 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 52 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 54 |
596564004 |
SCREW TT 3/8-16X2.31 UNC This part replaces 817490636. Price: $1.99 |
| 97 |
532178515 |
WASHER Price: $5.99 |
| 98 |
547878302 |
SPRING BELT TENSIONER BLACK This part replaces 532196105. Price: $5.99 |
| 113 |
596435701 |
Bolts This part replaces 872110508. Price: $2.99 |
| 114 |
532197451 |
ROD.TENSION.RELIEF.TEX (2 2) Price: $14.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 120 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 122 |
532187557 |
BUSHING.RELIEF.TENSION Price: $7.99 |
| 185 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 187 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 188 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 189 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 190 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 194 |
874490736 |
BOLT.HEX.WASHER.HEAD.7/16-24X This part replaces 872140716. Price: $9.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
