| Ref | Part Number | Description |
|---|
| 1 |
170280 |
Mower Housing Assembly Price: Call Us |
| 1 |
62-5550 |
DECAL Price: $9.32 |
| 2 |
72140506 |
Bolt Carriage 5/16-18 x 3/4 Price: Call Us |
| 2 |
93-7996-01 |
COVER-TOWER Price: $64.83 |
| 3 |
106-5950 |
RH FENDER ASM Price: $661.25 |
| 3 |
138017 |
Bracket Asm Fr. Sway Bar Price: Call Us |
| 4 |
169970 |
Bracket Deck Sway Bar 38"/42" Price: Call Us |
| 5 |
4939M |
Retainer Spring Price: Call Us |
| 6 |
106-5951 |
LH FENDER ASM Price: $625.15 |
| 6 |
178024 |
Bar Sway Deck Price: Call Us |
| 7 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 8 |
107-1839 |
KIT-FRAME ASM, RM5000 This part replaces 100-3870. Price: $3,818.37 |
| 8 |
850857 |
Bolt 3/8-24 x 1.25 Grade 8 Price: Call Us |
| 9 |
10030600 |
Washer, Lock 3/8 Price: Call Us |
| 10 |
140296 |
Washer, Hardened Price: Call Us |
| 10 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 11 |
138497 |
Blade Mower Price: Call Us |
| 11 |
98-4572 |
BRACKET-CLAMP, HOSE Price: $33.62 |
| 12 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 13 |
75-1390-01 |
COVER-ACCESS, FRONT Price: $78.27 |
| 14 |
128774 |
Housing, Mandrel, Vented Price: Call Us |
| 14 |
75-1410-01 |
PLATE-ACCESS, FLOOR Price: $142.43 |
| 15 |
110485X |
Bearing, Ball, Mandrel Price: Call Us |
| 15 |
3234-7 |
SCREW-HHF Price: $1.99 |
| 16 |
174493 |
Stripper, Vented Mower Deck Price: Call Us |
| 16 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 17 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 18 |
322-4 |
SCREW-HH Price: $0.35 |
| 19 |
132827 |
Bolt, Shoulder Price: Call Us |
| 19 |
94-1410 |
HOLDER-CAN, BEVERAGE Price: $5.81 |
| 20 |
93-3626 |
BRACKET-HOSE Price: $23.80 |
| 21 |
104-0026 |
TOOLBOX Price: $160.81 |
| 21 |
73680500 |
Nut Price: Call Us |
| 22 |
104-1476 |
RING-RUBBER Price: $18.49 |
| 23 |
137607 |
Bracket, Mower Deflector Price: Call Us |
| 23 |
75-0630 |
TREAD-FOOT, CENTER Price: $56.24 |
| 24 |
104-1496 |
HINGE-PIN Price: $13.22 |
| 24 |
105304X |
Cap, Sleeve Price: Call Us |
| 25 |
104-1497 |
HINGE-RECEIVER Price: $13.90 |
| 25 |
123713X |
Spring, Torsion, Deflector Price: Call Us |
| 26 |
110452X |
Nut, Push Price: Call Us |
| 27 |
106736X428 |
Shield, Deflector Price: Call Us |
| 27 |
74-5950 |
LATCH-SWELL Price: $21.28 |
| 28 |
104-9294 |
DECAL-WARNING Price: $44.98 |
| 28 |
104-9295 |
DECAL-WARNING, CE Price: $47.20 |
| 28 |
19111016 |
Washer 11/32 x 5/8 x 16 Gauge Price: Call Us |
| 29 |
104-1489-03 |
COVER-TOOLBOX Price: $87.10 |
| 29 |
106735X |
Rod, Hinge Price: Call Us |
| 30 |
104-1434 |
DECAL-SERVICE, BLANK Price: $11.05 |
| 30 |
105-7515 |
DECAL-SERVICE Price: $48.13 |
| 30 |
173984 |
Screw Thdrol. Price: Call Us |
| 31 |
129963 |
Washer, Spacer Price: Call Us |
| 31 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 32 |
153532 |
Pulley, Mandrel Price: Call Us |
| 33 |
178342 |
Nut, Toplock Price: Call Us |
| 33 |
94-5626 |
FLEXIBLE DRAW LATCH ASM Price: $42.59 |
| 36 |
131494 |
Pulley, Idler, Flat Price: Call Us |
| 40 |
73680600 |
Nut, Crownlock 3/8-16 Unc Price: Call Us |
| 45 |
4497H |
Retainer Price: Call Us |
| 53 |
130840 |
Brake Assembly Price: Call Us |
| 54 |
133943 |
Washer, Hardened Price: Call Us |
| 55 |
133840 |
Idler Arm Assembly Price: Call Us |
| 56 |
165723 |
Spacer, Retainer Price: Call Us |
| 67 |
106932X |
Knob Price: Call Us |
| 68 |
144200 |
V-Belt, 42" Mower Price: Call Us |
| 69 |
76020312 |
Pin, Cotter 3/32 x 3/4 Price: Call Us |
| 86 |
7631J |
Runner, LH Price: Call Us |
| 87 |
128772 |
Runner, RH Price: Call Us |
| 88 |
19111216 |
Washer 11/32 x 3/4 x 16 Ga Price: Call Us |
| 89 |
19131612 |
Washer 13/32 x 1 x 12 Ga. Price: Call Us |
| 107 |
133502 |
Spacer Retainer Price: Call Us |
| 108 |
133503 |
Stiffener, Idler Arm Price: Call Us |
| 109 |
74760640 |
Bolt, Hex Hd 3/8-16 x 2-1/2 Price: Call Us |
| 110 |
142587 |
Upstop Deck Front 38" Price: Call Us |
| 113 |
17060512 |
Screw 5/16-1/ x 3/4 Price: Call Us |
| 122 |
131289 |
Rod, Brake LH Price: Call Us |
| 123 |
169971 |
Rod, Brake RH Price: Call Us |
| 146 |
165891 |
Bolt Carriage Idler Price: Call Us |
| 148 |
169022 |
Spring Return Idler Price: Call Us |
| 149 |
165898 |
Retainer Spring Yellow Price: Call Us |
| 150 |
19091216 |
Washer 9/32 x 3/4 x 16 Ga. Price: Call Us |
| 151 |
169670 |
Bracket Clutch Cable Price: Call Us |
| 152 |
172758 |
Clutch Cable 38"/46" Price: Call Us |
| 153 |
169674 |
Washer Flat 3/8" Type B Price: Call Us |
| 154 |
169675 |
Spring Retainer Price: Call Us |
| 155 |
169671 |
Spring Retention LVR CLTCH CAB Price: Call Us |
| 156 |
169672 |
Spacer Clutch Cable Price: Call Us |
| 157 |
169669 |
Rod Clutch Cable 3/8" Price: Call Us |
| 158 |
17720408 |
Screw Hex Thd Cut 1/4-20 x 1/2 Price: Call Us |
