| Ref | Part Number | Description |
|---|
| 3 |
TCA16240 |
FITTING, OIL DRAIN # Price: $26.20 |
| 5 |
06200203 |
BLT-RDHDSQSHNK M8-1.25X50 8.8 This part replaces 05900123. Price: $2.95 |
| 6 |
05900116 |
CAP SCREW, ENG MNTING M8 X 1.2 Price: $2.95 |
| 7 |
06500817 |
NUT,NYL M8-1.25 G8.8 ZCC This part replaces 06541700. Price: $1.45 |
| 8 |
06300119 |
WSHR-LK-REG .312X.078 ZCC This part replaces 06308600. Price: $0.95 |
| 9 |
D18427 |
CABLE, CHOKE 31.0" Price: $41.95 |
| 10 |
TCA15051 |
CABLE, THROTLE 48.0" Price: $19.95 |
| 13 |
06522900 |
NUT-HEX .375-24 YWZC Price: $1.25 |
| 16 |
06400327 |
WASHER, HELICAL SPRING Price: Call Us |
| 17 |
06538600 |
NUT-HEX M8-1.25 YWZC Price: $1.95 |
| 18 |
05901628 |
BLT, HEX M8-1.25X20 G8.8 ZCC This part replaces 05973300. Price: $1.45 |
| 20 |
06100008 |
SCREW, FLANGED METRIC M6 X 60( Price: Call Us |
| 22 |
M146270 |
Spacer, Reverse Pedal Assembly Price: Call Us |
| 23 |
06500725 |
NUT,NYL-FLG M8-1.25 G8.8 ZCC This part replaces 06542300. Price: $3.45 |
