| Ref | Part Number | Description |
|---|
| 1 |
120-2244 |
HOURMETER This part replaces 66-2950. Price: $48.06 |
| 1 |
98000129 |
NUT Price: Call Us |
| 2 |
100-8072 |
SWITCH Price: $94.07 |
| 2 |
104086X419 |
SHIELD.SD.OUT.LH Price: Call Us |
| 3 |
8393J |
STAKE PIN TI Price: Call Us |
| 3 |
98-9339 |
GAUGE-FUEL Price: $115.28 |
| 4 |
106-6751 |
CONTROL PANEL ASM Price: $424.05 |
| 4 |
12000036 |
KLIP RING TI Price: Call Us |
| 5 |
2412-74 |
R-CLAMP Price: $2.37 |
| 5 |
72110508 |
BOLT CRT Price: Call Us |
| 6 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 6 |
8394J |
SPRING TI Price: Call Us |
| 7 |
105-0788-03 |
BRACKET-PIVOT Price: $41.98 |
| 7 |
8392J |
LATCH BRACKET TI Price: Call Us |
| 8 |
109230X |
SPRING CRT Price: Call Us |
| 8 |
99-7411 |
POINT-POWER Price: $30.69 |
| 9 |
102326X419 |
SHLD TINE Price: Call Us |
| 9 |
99-7416 |
CAP Price: $6.64 |
| 10 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 10 |
72140506 |
BOLT Price: Call Us |
| 11 |
340-3 |
FITTING-STRAIGHT Price: $10.42 |
| 11 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 12 |
10040500 |
LOCKWASHER Price: Call Us |
| 12 |
323-8 |
SCREW-HH Price: $1.20 |
| 13 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 13 |
72110510 |
BOLT Price: Call Us |
| 14 |
105-4563 |
CONTROL VALVE ASM Price: $1,596.17 |
| 14 |
124343X |
BRKT SHIELD TINE Price: Call Us |
| 15 |
104101X419 |
SHIELD.SD.OUT.RH Price: Call Us |
| 15 |
105-0789-03 |
BRACKET-VALVE Price: $54.86 |
| 16 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 16 |
73220400 |
SUB= 50675 Price: Call Us |
| 17 |
10040400 |
LOCKWASHER Price: Call Us |
| 17 |
104-0788 |
VALVE ASM Price: $1,267.41 |
| 18 |
104-2231-03 |
PLATE-VALVE Price: $23.42 |
| 18 |
72040410 |
BOLT Price: Call Us |
| 19 |
102701X |
GRIP CRT Price: Call Us |
| 19 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 20 |
322-3 |
SCREW-HH Price: $0.79 |
| 20 |
73220600 |
NUT.HEX.3/8-16UNC Price: Call Us |
| 21 |
102156X |
SUB= 102156X500 Price: Call Us |
| 21 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 22 |
321-5 |
SCREW-HH Price: $0.22 |
| 22 |
74930632 |
BOLT Price: Call Us |
| 23 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 23 |
4440J |
HINGE CRT Price: Call Us |
| 24 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 24 |
72140404 |
BOLT Price: Call Us |
| 25 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 25 |
6712 |
J VINYL CAP TI Price: Call Us 6712 J |
| 26 |
100-3123 |
LH LEVER ASM Price: $66.45 |
| 26 |
109227X |
PAD IDLER TI Price: Call Us |
| 27 |
102695X419 |
SUB= 102695X366 Price: Call Us |
| 27 |
69-9140 |
LINK-LEVER, VALVE Price: $15.42 |
| 28 |
100-3122 |
CENTER LEVER ASM Price: $66.45 |
| 28 |
120588X |
PIN HINGE Price: Call Us |
| 29 |
3272-1 |
PIN-COTTER Price: $0.25 |
| 30 |
100-3121 |
RH LEVER ASM Price: $66.45 |
| 31 |
62-6660 |
SPACER Price: $0.79 |
| 32 |
233-42 |
KNOB Price: $12.88 |
| 33 |
323-38 |
SCREW-HH Price: $2.62 |
| 34 |
321-11 |
SCREW-HH Price: $0.36 |
| 35 |
93-5270 |
SWITCH-PTO Price: $201.01 |
| 36 |
2412-126 |
R-CLAMP Price: $2.51 |
| 37 |
104-2541 |
SWITCH ASM This part replaces 88-9830. Price: $36.70 |
| 38 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 39 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 40 |
80-9330 |
AUDIO ALARM ASM Price: $137.61 |
| 41 |
95-8999 |
SWITCH Price: $42.14 |
| 42 |
99-7420 |
PLUG-HOLE Price: $7.64 |
| 43 |
86-5480 |
NIPPLE-TEST Price: $48.77 |
| 44 |
354-79 |
CAP-DUST Price: $7.81 |
| 45 |
323-6 |
SCREW-HH Price: $0.66 |
| 46 |
99-8970 |
KEY-LATCH, HOOD Price: $15.13 |
| 47 |
98-9321 |
RING-KEY Price: $1.80 |
