| Ref | Part Number | Description |
|---|
| 1 |
3219-3 |
NUT-HEX Price: $0.34 |
| 1 |
463098 |
Upper Handle Wlmt. W/Decals Price: Call Us |
| 2 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 2 |
42675 |
QUADRANT, SPEED CONTROL Price: Call Us |
| 3 |
04062-02 |
HAIR PIN, .08 DIAMETER X 1-3/16" Price: Call Us |
| 3 |
5-1468-01 |
PNEU. WHEEL HUB This part replaces 5-1468. Price: $101.29 |
| 4 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 4 |
45282 |
LEVER, SPEED ADJUSTMENT Price: Call Us |
| 5 |
43086 |
BUSHING, SPEED ADJUSTMENT LEVER Price: Call Us |
| 5 |
5-1470 |
SCREW-HH Price: $0.61 |
| 6 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 6 |
3217-6 |
NUT-HEX Price: $1.19 |
| 7 |
12-9460 |
DISC HALF Price: $73.84 |
| 7 |
48493-01 |
BALL PLUNGER Price: Call Us |
| 8 |
12-9390 |
TIRE (16X4-12) 4 PLY SEMI-PNEUMATIC Price: $77.30 |
| 8 |
48092 |
KNOB, SPEED ADJUSTMENT LEVER Price: Call Us |
| 9 |
04014-01 |
CAPSCREW, 1/4-20 X .75 FLAT HD. HEX SOCKET Price: Call Us |
| 9 |
322-2 |
SCREW-HH Price: $0.69 |
| 10 |
04021-08 |
HEX, NUT, ELASTIC STOP LOCK, 1/4-20 Price: Call Us |
| 11 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 12 |
04003-43 |
Bolt, Carriage #10-24 x 1/2" Price: Call Us |
| 13 |
48946 |
Throttle Control (15KA & 17KA) Price: Call Us |
| 14 |
04021-26 |
Nut, Elastic Stop #10-24 Price: Call Us |
| 15 |
483142 |
Bushing Price: Call Us |
| 16 |
451917 |
Operator Presence Lever, RH Price: Call Us |
| 17 |
485833 |
Switch, PTO - 10 Amp Price: Call Us |
| 18 |
487329 |
Wire Harness, Electric Start Price: Call Us |
| 19 |
48798 |
KEY SWITCH(INCLUDES MOUNTING HARDWARE) Price: Call Us |
| 20 |
461242 |
Neutral Latch-RH 461241 Neutral Latch-LH Price: Call Us |
| 21 |
48717 |
SWITCH, NEUTRAL INTERLOCK Price: Call Us |
| 22 |
483161 |
Plug, Handle Bar Price: Call Us |
| 23 |
04032-01 |
Socket Head Capscrew #8-32 x 1/2" Price: Call Us |
| 24 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 (35BV & 37BV-EFI) Price: Call Us |
| 25 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 26 |
04001-17 |
Bolt, Hex Head 5/16-18 x 2-1/2" (x3) (35BV & 37BV-EFI) Price: Call Us |
| 27 |
04001-53 |
Bolt, Hex Head 5/16-18 x 2-1/2" (35BV & 37BV-EFI) Price: Call Us |
| 28 |
483160 |
Lever, Steering Control Price: Call Us |
| 29 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 30 |
44141 |
Rod, Steering Control Price: Call Us |
| 31 |
483040 |
Spring, Operator Presence Price: Call Us |
| 32 |
04017-27 |
Capscrew, 3/8-16 x 1.0" Serrated Flange Hex Hd Price: Call Us |
| 33 |
483470 |
Spring Price: Call Us |
| 34 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 35 |
44142 |
Rod Speed Control Price: Call Us |
| 36 |
43887 |
SPEED CONTROL ARM Price: Call Us |
| 37 |
04012-0 |
Setscrew, 1/4-28 x .25" Price: Call Us |
| 38 |
46335 |
CAM, SPEED CONTROL(INCLUDES SETSCREW) Price: Call Us |
| 39 |
43166 |
JACKSHAFT, SPEED CONTROL(FOR 16" DECK) Price: Call Us |
| 40 |
04063-13 |
KEY, 1/8 X 1/2, WOODRUFF # 3 Price: Call Us |
| 41 |
04060-06 |
Roll Pin, Spring 3/16 x 3/4" Price: Call Us |
| 42 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 43 |
48223 |
FLANGE, JACKSHAFT BEARING Price: Call Us |
| 44 |
04017-17 |
Cpscrw, 5/16-18 x 1"Serrated Flange Hex Head Price: Call Us |
| 45 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 46 |
422795 |
Plate, Side Price: Call Us |
| 47 |
43536 |
Support, Neutral Support Price: Call Us |
| 48 |
48409 |
BEARING, SPEED CONTROL BELLCRANK Price: Call Us |
| 49 |
04001-69 |
BOLT, HEX HD., 5/16-18 X 1-3/4 FULL THREAD Price: Call Us |
| 50 |
48494-02 |
SPRING, IDLER TENSION Price: Call Us |
| 51 |
43522 |
Spacer, Side Plate Price: Call Us |
| 52 |
04041-08 |
Flatwasher, 3/4 (.766 x 1.250 x .060) Price: Call Us |
| 53 |
04063-07 |
KEY, WOODRUFF #9, 3/16 X 3/4" Price: Call Us |
| 54 |
04001-59 |
SERR. FLG. HEX HEAD CAPSCREW, 5/16-18 X 3/4 Price: Call Us |
| 55 |
04001-19 |
Bolt, Hex Head, 3/8-16 x 1 Gr. 5 Price: Call Us |
| 56 |
43415 |
B ushing, Brake Price: Call Us |
| 57 |
04050-02 |
RETAINING RING, 3/4" EXTERNAL "E" Price: Call Us |
| 58 |
48224 |
BEARINGS, BALL, NEUTRAL RETURN Price: Call Us |
| 59 |
46747 |
Cam, Neutral (incl. grease ftng.) Price: Call Us |
| 60 |
48114-05 |
Greese Fitting, Straight 1/4 - 28 Price: Call Us |
| 61 |
04050-01 |
RETAINING RING, 5/8" EXTERNAL "E" Price: Call Us |
| 62 |
04001-09 |
Bolt, Heax Head 5/16-18 x 1" (48V / 52V) Price: Call Us |
| 63 |
483414 |
Lever, Speed Control Price: Call Us |
| 64 |
04017-05 |
Bolt, Serrated Flange Hex Head 1/4 x 20 x 3/4" Price: Call Us |
| 65 |
482431 |
Linkage Assembly Price: Call Us |
| 66 |
04041-07 |
Flatwasher, 3/8" Special (.391 x .938 x .105) Price: Call Us |
| 67 |
462287 |
Engine Deck (16" Wide) with Decals - Small Frame Price: Call Us |
| 68 |
04001-10 |
Bolt, 5/16 - 18 x 1 - 1/4" Hex Head Price: Call Us |
| 69 |
482314 |
Choke Control Price: Call Us |
| 70 |
04001-152 |
Bolt, Hex Head 3/8-16 x 4-1/4" Price: Call Us |
| 71 |
42413 |
BRACKET, FUSE HOLDER Price: Call Us |
| 72 |
43520 |
Swivel Joint, Steering Rod Price: Call Us |
| 73 |
48100-06 |
Bushing, oil lube - 3/4 ID x 1.0 Price: Call Us |
| 74 |
48298 |
FUSE, 20 AMP BLADE TYPE AUTOMOTIVE Price: Call Us |
| 75 |
04021-01 |
HEX NUT, ELASTIC STOP LOCK # 10-32 Price: Call Us |
| 76 |
04010-03 |
Screw, #10-32 x 1.5" Phillips - 21KAE Price: Call Us |
| 77 |
04030-02 |
Lockwasher, 1/4†Spring Price: Call Us |
| 78 |
43032 |
SWIVEL JOINT, SPEED CONTROL ROD Price: Call Us |
| 79 |
44143 |
Rod, Brake Lever Price: Call Us |
| 80 |
04001-45 |
Capscrew, Hex Head 3/8-16 x 2.0" Price: Call Us |
| 81 |
48464 |
Rod End, 3/8-24 RH Thread Female Price: Call Us |
| 82 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 83 |
04010-12 |
Screw, Hex-Slotted Washer Head #10 32 x 3/4" Price: Call Us |
| 84 |
04001-01 |
BOLT, HEX HEAD, 1/4-20 X 3/4 GR.5 Price: Call Us |
| 85 |
43286 |
Spacer, Idler Price: Call Us |
| 86 |
462746 |
Parking Brake Lever w/Grip & Grease Fitting Price: Call Us |
| 87 |
487327 |
Switch, Safety Price: Call Us |
| 88 |
04020-14 |
HEX NUT, 3/8-24 R.H. THREAD Price: Call Us |
| 89 |
423876 |
Mounting Bracket, Wrench Price: Call Us |
| 90 |
423875 |
Wrench Price: Call Us |
| 91 |
48342 |
GRIP, PARKING BRAKE Price: Call Us |
| 92 |
421203 |
CLAMP PLATE, PUMP CONTROL Price: Call Us |
| 93 |
04062-01 |
COTTER PIN, HAIR - 0.94 X 1.62 Price: Call Us |
| 94 |
44126 |
Rod, Brake Lower Price: Call Us |
| 95 |
422273 |
Plate, Coupler Price: Call Us |
| 96 |
451113 |
Shaft, Pump Control Price: Call Us |
| 97 |
481879 |
Spring, Tracking Adjustment Price: Call Us |
| 98 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 99 |
48829 |
BLOCK, PUMP CONTROL Price: Call Us |
| 100 |
461964 |
Control, LH (inc. bush. & decal) Price: Call Us |
| 101 |
481545 |
Switch, Interlock (see below) Price: Call Us |
| 102 |
44144 |
Rod, Offset Price: Call Us |
| 103 |
422373 |
Plate, Threaded Price: Call Us |
| 104 |
462069 |
Key, Assembly w/Fob Price: Call Us |
| 43155 |
JACKSHAFT, |
SPEED CONTROL(FOR 20" DECK) Price: Call Us 43155 |
| 451915 |
Operator |
Presence Lever, LH Price: Call Us 451915 |
| 451916 |
Handle, |
Oper. Presence-LH Price: Call Us 451916 |
| 461241 |
Neutral |
Latch Assembly, LH Price: Call Us 461241 |
| 461965 |
Control, |
RH (inc. bush. & decal) Price: Call Us 461965 |
| 462288 |
Engine |
Deck (20" Wide) with Decals - Large Frame Price: Call Us 462288 |
| 463099 |
Upper |
Handle Wlmt. W/Decals Price: Call Us 463099 |
