Hydraulic Lift Arm Group
Parts (55)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 114-2714 | LEVER-BRAKE This part replaces 100-3002-03. Price: $62.42 |
| 1 | 74760524 | BOLT.HEX.5/16-1.5 Price: Call Us |
| 1 | DD-T2610-37303 | CYLINDER-LIFT ARM Not Available Price: |
| 2 | 3230-1 | BOLT-CARR This part replaces 3230-20. Price: $1.49 |
| 2 | 74610652 | BOLT.3/8-24X3.75 Price: Call Us |
| 2 | DD-04810-00120 | O-RING Not Available Price: |
| 3 | 104-8300 | NUT-HF, NI Price: $0.39 |
| 3 | 19131311 | WASHER Price: Call Us |
| 3 | DD-T2610-37362 | BOLT-HEX SOCKET Not Available Price: |
| 4 | 10040600 | Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 4 | 3296-29 | NUT-LOCK, NI Price: $2.09 |
| 4 | DD-04717-01200 | SEAL WASHER Not Available Price: |
| 5 | 100-3000-03 | RH BRAKE ARM ASM Price: $158.89 |
| 5 | 7810H | GRIPCO NUT Price: Call Us |
| 5 | DD-T2610-37352 | BOLT-HEX SOCKET Not Available Price: |
| 6 | 93-4849 | BEARING-BLOCK, PILLOW Price: $24.13 |
| 6 | DD-04717-01400 | SEAL WASHER Not Available Price: |
| 7 | 1949J | SUB= 1949J500 Price: Call Us |
| 7 | 32151-83 | RING-SNAP Price: $0.34 |
| 7 | DD-T2610-37312 | PISTON-LIFT ARM CY Not Available Price: |
| 8 | 110519X | BRACKET.ENG.LH. Price: Call Us |
| 8 | 93-5475-03 | BRAKE LATCH ASM Price: $132.94 |
| 8 | DD-04810-00800 | O-ring Price: $3.19 |
| 9 | 100-2997-03 | LH BRAKE ARM ASM Price: $166.55 |
| 9 | 10040500 | LOCKWASHER Price: Call Us |
| 9 | DD-T2610-37331 | Ring, Backup Price: $23.55 |
| 10 | 32121-15 | PIN-ROLL Price: $1.60 |
| 10 | 73220500 | NUT.HEX.5/16-18 Price: Call Us |
| 10 | DD-T2610-37322 | LIFT ROD ARM PISTO Not Available Price: |
| 11 | 100-5540 | STRAP-BRAKE Price: $32.46 |
| 11 | 74760544 | SUB= 74780544 Price: Call Us |
| 11 | DD-T2610-37442 | ARM-HYD LIFT CYL Not Available Price: |
| 12 | 126669X | SUB= 532126669 Price: Call Us |
| 12 | 283-61 | PIN-YOKE Price: $1.56 |
| 12 | DD-T2610-37421 | PIN-HYDRAULIC ARM Not Available Price: |
| 13 | 19171616 | WASHER Price: Call Us |
| 13 | 93-5262 | SPRING-EXTENSION Price: $10.21 |
| 13 | DD-T2610-37453 | SCREW-LOCK SET Not Available Price: |
| 14 | 3272-6 | PIN-COTTER Price: $0.25 |
| 14 | 9173R | SPLIT SPACER RT Price: Call Us |
| 14 | DD-05411-00850 | SPRING PIN Not Available Price: |
| 15 | 73510500 | NUT Price: Call Us |
| 15 | DD-T2610-37434 | SHAFT-HYD ARM Not Available Price: |
| 16 | 19091412 | WASHER Price: Call Us |
| 16 | 93-5568 | ARM-LOCK Price: $17.77 |
| 16 | DD-09500-45609 | OIL SEAL Not Available Price: |
| 17 | 19092016 | WASHER Price: Call Us |
| 17 | 322-6 | SCREW-HH Price: $0.45 |
| 17 | DD-T2610-37461 | WASHER-LIFT SHAFT Not Available Price: |
| 18 | 10040400 | LOCKWASHER Price: Call Us |
| 18 | 322-4 | SCREW-HH Price: $0.35 |
| 18 | DD-T2610-37202 | LIFT ARM ASSEMBLY Not Available Price: |
| 19 | 105-4553-03 | LH PEDAL ASM Price: $71.10 |
| 20 | 93-8743 | FOOTPAD-TURN This part replaces 27-7570. Price: $27.95 |
| 22 | 105-4554-03 | RH PEDAL ASM Price: $71.10 |
