| Ref | Part Number | Description |
|---|
| 2 |
9462 |
Battery Cap (yellow) Price: Call Us |
| 2A |
9248 |
Battery Cap (white) Price: Call Us |
| 3 |
9009 |
Vent Tube Price: Call Us |
| 4 |
1475 |
Shield, Vent Tube (hard plastic) Price: Call Us |
| 5 |
9224 |
Clamp Price: Call Us |
| 10 |
777S30648 |
Label, Ignition Switch This part replaces 1904548. Price: $4.25 |
| 11 |
925-0201 |
Key This part replaces 96520. Price: $8.70 |
| 12 |
96509 |
BATTERY CABLE Not Available Price: |
| 13 |
GW-96510 |
Cable (solenoid to starter motor) This part replaces 96510. Price: $10.43 |
| 15 |
GW-97020 |
BOOT-BATTERY CABLE Not Available This part replaces 97020. Price: |
| 17 |
1918831001 |
Battery Bracket Price: Call Us |
| 18 |
1186073 |
Round Hd. Screw, Square Neck, 1/4-20 x 1-1/4 Price: $2.67 |
| 20 |
736-0607 |
External L-Washer 5/16 This part replaces 1177548. Price: $3.66 |
| 21 |
1186389 |
Hex Locknut, 1/4-20 Price: $3.05 |
| 22 |
936-0119 |
LOCK WASHER 5/16 This part replaces 1100242. Price: $4.29 |
| 23 |
912-3057 |
NUT-5/16X 24 This part replaces 1186211. Price: $5.94 |
| 24 |
GW-9853 |
Sems Nut This part replaces 9853. Price: $6.01 |
| 25 |
N/A |
Lockwasher, #10 (not available from factory) |
| 26 |
N/A |
Hex Nut, #10-24 (not available from factory) |
| 27 |
1901894 |
WIRE ASSEMBLY-RECHARGI Not Available Price: |
| 29 |
GW-9265 |
TIE-TWIST LOCK Not Available This part replaces 9265. Price: |
| 31 |
1901202 |
Cable (ground wire to starter motor bracket) Price: $30.69 |
| 32 |
1917262 |
ASSM-WIRE SWITCH S Not Available Price: |
