| Ref | Part Number | Description |
|---|
| 1 |
120-6272 |
HYD MOTOR ASM This part replaces 110-1717. Price: $846.73 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 2 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 4 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 6 |
117-0174-03 |
BRACKET-BULKHEAD Price: $43.53 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
32144-57 |
SCREW Price: $1.04 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
105-3048 |
WASHER-FLAT Price: $0.89 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
99-8611 |
SPACER Price: $5.71 |
| 11 |
114-8887 |
TUBE ASM Price: $100.66 |
| 12 |
2412-113 |
CLAMP-R Price: $0.75 |
| 13 |
117-0142 |
TUBE ASM Price: $136.47 |
| 14 |
340-78 |
NUT-LOCK Price: $1.63 |
| 14 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
| 15 |
117-0140 |
TUBE ASM Price: $100.52 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
56-7971 |
CLAMP-TUBE Price: $17.90 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 587016002. Price: $34.99 |
| 17 |
117-0141 |
TUBE ASM Price: $127.80 |
| 18 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
94-5780 |
SCREW-HWH Price: $7.49 |
| 20 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 21 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 586840201. Price: $7.99 |
| 22 |
3334-945 |
TIE-CABLE Price: $0.43 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 585029802. Price: $14.99 |
| 23 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 24 |
114-0633 |
HOSE-HYD Price: $149.34 |
| 25 |
117-5190 |
HOSE-HYD Price: $171.44 |
| 26 |
106-3671 |
HOSE-HYD Price: $112.38 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 27 |
117-5188 |
HOSE-HYD Price: $192.82 |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 28 |
106-3680 |
HOSE-HYD Price: $73.67 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
114-0633 |
HOSE-HYD Price: $149.34 |
| 30 |
98-4590 |
HOSE-HYD Price: $76.24 |
| 33 |
139-5996 |
HOSE GUIDE ASM-LH This part replaces 119-3921. Price: $32.43 |
| 34 |
139-5995 |
GUIDE-HOSE, RH This part replaces 119-3920. Price: $32.43 |
| 35 |
117-0177 |
TUBE ASM Price: $127.80 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $2.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $37.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 585338801. Price: $14.99 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683701. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 78 |
532057079 |
THRUST WASHER Price: $1.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
