| Ref | Part Number | Description |
|---|
| 1 |
137-6126 |
LONG REAR ROLLER ASM (3IN DIA)(32IN) This part replaces 112-8961. Price: $536.38 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
532137352 |
MUFFLER.LT.BRIGGS.14HP.IC/OHV Price: $29.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 6 |
3230-26 |
SCREW-CARR Price: $3.99 |
| 7 |
117-0990 |
PLASTIC WIEHLE ROLLER ASM Price: $553.30 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
584911601 |
KEEPER.BELT.ENGINE Price: $2.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 11 |
323-14 |
SCREW-HH Price: $1.34 |
| 12 |
120-0404 |
BRACKET-HIGH HOC (LH) Price: $71.73 |
| 12 |
120-0405 |
BRACKET-HIGH HOC (RH) Price: $71.73 |
| 12 |
586729001 |
PULLEY.ENGINE Price: $24.99 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 15 |
140-5522 |
SCREW-HHF 5/8, PATCH This part replaces 133-7571. Price: $2.46 |
| 15 |
586365801 |
FUEL.TANK.ASM.1.5GAL.CARB Price: $229.99 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 17 |
133-7570 |
NUT-FLANGE, NI Price: $0.45 |
| 18 |
532430219 |
CAP ASM.FUEL.2.25"FRT.CARB Price: $39.99 |
| 20 |
583045801 |
CNTRL.TH/CK.PADDL.20_2.BLK.#37 This part replaces 532170545. Price: $24.99 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 28 |
532401137 |
LINE.FUEL.20"FRONT.EMI Price: $9.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 69 |
532272293 |
Gasket Eng 1 313 Id Tin Plated (AYP part number) This part replaces 532165291. Price: $7.99 |
| 79 |
532192334 |
SCREW.SOCKET HD.5/16-1 Price: $2.99 |
| 85 |
501606501 |
Speed Clip This part replaces 532173937. Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 109 |
532414114 |
CANNISTER, CARBON Price: $32.99 |
| 111 |
532448562 |
KIT.PURGE.LINE.55" This part replaces 532414119. Price: $14.99 |
| 114 |
532414116 |
CRADLE.CANISTER.CARBON Price: $19.99 |
