| Ref | Part Number | Description |
|---|
| 1 |
125-7003 |
STARTER Price: $761.46 |
| 1 |
532071673 |
PLUNGER CAP Price: $4.99 |
| 2 |
125-7004 |
SWITCH ASM Price: $310.64 |
| 2 |
532123436 |
ROD,PARK BRAKE Price: $4.99 |
| 3 |
125-7112 |
ARMATURE ASM Price: $1,004.37 |
| 3 |
532123437 |
BRKT,PARK BRAKE Price: $4.46 |
| 4 |
125-7252 |
BEARING-BALL Price: $30.58 |
| 4 |
532008156 |
FOOT PEDAL COVER Price: $2.64 |
| 5 |
125-7249 |
BEARING, BALL Price: $74.15 |
| 5 |
532122504 |
BRKT,CLU PEDAL LH Price: $3.08 |
| 6 |
125-7113 |
FIELD COIL ASM Price: $188.98 |
| 6 |
596917601 |
Pins This part replaces 876020312. Price: $1.99 |
| 7 |
125-7114 |
BRUSH Price: $7.85 |
| 7 |
819131016 |
WASHER Price: $2.99 |
| 8 |
125-7163 |
SCREW Price: $4.64 |
| 8 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 9 |
125-7115 |
COVER Price: $48.60 |
| 9 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 10 |
125-7116 |
BRUSH HOLDER ASM Price: $59.41 |
| 10 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 11 |
125-7114 |
BRUSH Price: $7.85 |
| 11 |
532123543 |
ROD,FRT BRAKE Price: $8.38 |
| 12 |
125-7036 |
SPRING Price: $8.92 |
| 12 |
532139933 |
CLUTCH/BRAKE PEDAL ASSY Price: $21.38 |
| 13 |
125-7164 |
CASE-GEAR Price: $148.50 |
| 13 |
532123394 |
ROD,CLUTCH Price: $7.99 |
| 14 |
125-7005 |
HOUSING Price: Call Us |
| 14 |
532121978 |
BRKT,LIFT SHAFT Price: $2.38 |
| 15 |
125-7165 |
LEVER SET Price: $12.41 |
| 15 |
532133332 |
ARM, BRAKE ASMBLY Price: $6.71 |
| 16 |
819251816 |
WASHER T Price: $4.99 |
| 17 |
812000034 |
Ring, Klip Truarc #5304-75 Price: $2.99 |
| 18 |
125-7037 |
DUST COVER ASM Price: $32.44 |
| 18 |
532151332 |
SPRING, BRAKE ROD Price: $4.99 |
| 19 |
125-7117 |
BOLT-THROUGH Price: $18.16 |
| 19 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 20 |
125-7166 |
PINION ASM Price: $520.47 |
| 20 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 21 |
125-7250 |
CLUTCH ASM Price: $223.38 |
| 21 |
532144413 |
ROD Price: $12.18 |
| 22 |
125-7251 |
BEARING-BALL Price: $113.29 |
| 22 |
532144585 |
TRUNNION, LEFT Price: $8.99 |
| 23 |
125-7253 |
BEARING-BALL Price: $30.58 |
| 24 |
125-7167 |
SHAFT Price: $105.30 |
| 24 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 25 |
125-7168 |
STOPPER SET Price: $14.88 |
| 26 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 27 |
532127369 |
LINK.MOWER.REAR Price: $9.99 |
| 28 |
532140776 |
REAR MOWER LIFT ASSY Price: $40.26 |
| 29 |
125-7210 |
BOLT Price: $2.32 |
| 29 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 30 |
125-7211 |
BOLT Price: $3.48 |
| 30 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 31 |
125-7169 |
COVER Price: $7.32 |
| 31 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $2.99 |
| 34 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
