| Ref | Part Number | Description |
|---|
| 1 |
32120-8 |
RING-SNAP Price: $1.76 |
| 2 |
532188665 |
Muffler Price: Call Us |
| 2 |
72-3750 |
BEARING-ROLLER Price: $180.02 |
| 3 |
323-56 |
SCREW-HH Price: $2.18 |
| 4 |
67-9080 |
HOUSING-MOTOR Price: $1,756.34 |
| 5 |
48-1800 |
CYLINDER BLOCK KIT Price: $1,923.22 |
| 6 |
25-2650 |
PLUG-VALVE, CHECK Price: $89.01 |
| 7 |
237-86 |
O-RING Price: $5.47 |
| 8 |
25-2640 |
SPRING-VALVE Price: $4.22 |
| 9 |
25-2490 |
BALL Price: $14.47 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
67-9100 |
GASKET Price: $15.83 |
| 11 |
583389701 |
KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99 |
| 11 |
99-5689 |
CHECK VALVE KIT This part replaces 25-3180. Price: $83.29 |
| 12 |
285-17 |
PLUG-PIPE Price: $2.59 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
237-22 |
O-RING Price: $2.43 |
| 14 |
25-2630 |
RING-BACK UP Price: $3.55 |
| 15 |
532400021 |
TANK.FUEL.SIDE-FILL.3.NON-EPA Price: $99.99 |
| 15 |
88-8220 |
VALVE-BY PASS Price: $189.03 |
| 16 |
25-2610 |
SPRING-VALVE Price: $29.42 |
| 17 |
25-2410 |
VALVE ASM Price: $514.54 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532194267. Price: $14.99 |
| 18 |
76-1900 |
O-RING Price: $3.64 |
| 19 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 20 |
119-2895 |
SPLINED SHAFT KIT This part replaces 67-8020. Price: $1,116.09 |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 21 |
3257-32 |
KEY-WOODRUFF Price: $2.52 |
| 21 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 22 |
117-2700 |
HOUSING KIT This part replaces 54-7890. Price: $2,321.28 |
| 23 |
252-82 |
BEARING-NEEDLE Price: $51.31 |
| 24 |
25-3210 |
SEAL-LIP Price: $23.14 |
| 25 |
25-2510 |
WASHER-FLAT Price: $2.41 |
| 26 |
25-2580 |
SHAFT-TRUNNION Price: $215.33 |
| 27 |
32151-46 |
RING-RETAINING Price: $8.38 |
| 28 |
25-2460 |
PLUG-HH Price: $37.38 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
25-2470 |
PACK-SHIM Price: $47.36 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
25-2570 |
SPRING-VALVE Price: $12.67 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 31 |
83-7260 |
CONE-RELIEF, CHARGE Price: $50.57 |
| 32 |
353-551 |
PLUG-HH Price: $18.48 |
| 33 |
237-80 |
O-RING Price: $6.10 |
| 34 |
25-2550 |
DISCONTINUED-SEE PB#945 Price: Call Us |
| 35 |
67-8050 |
BEARING-NEEDLE Price: $54.10 |
| 36 |
93-4133 |
SEAL-LIP Price: $37.43 |
| 37 |
322-4 |
SCREW-HH Price: $0.35 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
25-2680 |
GEROTOR ASM Price: $651.02 |
| 39 |
25-2530 |
PIN-STRAIGHT, HEADLESS Price: $21.24 |
| 40 |
25-3190 |
DISCONTINUED-SEE PB#945 Price: Call Us |
| 41 |
237-95 |
O-RING Price: $11.97 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 42 |
67-9090 |
PLUG Price: $41.68 |
| 43 |
25-2500 |
SHAFT-TRUNNION Price: $191.66 |
| 44 |
25-2480 |
SPRING-VALVE Price: $4.93 |
| 45 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 46 |
251-8 |
BEARING-BALL Price: $30.06 |
| 47 |
32151-75 |
RING-RETAINING This part replaces 32120-11. Price: $2.51 |
| 48 |
25-2450 |
PLATE-SWASH, VARIABLE Price: $896.81 |
| 49 |
32121-91 |
PIN-SPRING Price: $0.81 |
| 50 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 51 |
25-2440 |
PLATE-VALVE, PUMP Price: $491.90 |
| 52 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 53 |
110-6341 |
BEARING-ROLLER This part replaces 46-8400. Price: $41.33 |
| 54 |
93-4132 |
O-RING Price: $6.84 |
| 55 |
92-8918 |
SECTION-CENTER Price: $1,338.76 |
| 57 |
25-2390 |
PLATE-VALVE, MOTOR Price: $832.97 |
| 58 |
46-8410 |
SHAFT-MOTOR Price: $968.23 |
| 59 |
25-2400 |
GASKET Price: $19.26 |
| 60 |
93-0312 |
WASHER-HARDENED Price: $0.78 |
| 61 |
75-0170 |
PLUG-THREAD, STRAIGHT Price: $18.20 |
| 62 |
92-8777 |
O-RING Price: $3.02 |
| 69 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
