| Ref | Part Number | Description |
|---|
| 1 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 1 |
631339 |
SHAFT & LEV Price: Call Us |
| 2 |
26-1840 |
PULLEY-IDLER Price: $42.68 |
| 2 |
631045 |
RET SPRING Price: Call Us |
| 3 |
631367 |
SHUTTER Price: Call Us |
| 4 |
650506 |
SCREW Price: $0.87 |
| 4 |
95-3090 |
CENTER SPINDLE ASM Price: $535.51 |
| 5 |
630766 |
SPRING Price: $1.25 |
| 6 |
3231-29 |
SCREW-CARR Price: $0.68 |
| 6 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 7 |
26-1860 |
SPACER-IDLER PULLEY Price: $4.75 |
| 7E |
631318 |
SHAFT & LEV Price: Call Us |
| 8 |
32128-21 |
NUT-HF Price: $0.39 |
| 9 |
3231-27 |
SCREW-CARR Price: $0.54 |
| 9 |
630736 |
SHUTTER Price: $2.19 |
| 10 |
26-1870-03 |
MOUNT-IDLER Price: $74.13 |
| 10 |
631562 |
ADJ SCREW Price: $3.74 |
| 11 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 11 |
630738 |
SPRING Price: $1.25 |
| 11A |
631192 |
SPRING Price: Call Us |
| 12 |
26-1850 |
STUD-IDLER Price: $32.97 |
| 12 |
630739 |
WASHER Price: $1.25 |
| 12A |
631191 |
WASHER Price: $1.20 |
| 13 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 13 |
630740 |
O RING Price: $1.49 |
| 13A |
631190 |
O RING Price: Call Us |
| 14 |
21-0890 |
V-BELT Price: $32.90 |
| 14 |
631189 |
ADJ SCREW Price: Call Us |
| 15 |
138-6408 |
SPINDLE ASM. R.H. This part replaces 95-3095. Price: $535.51 |
| 15 |
632554 |
WELCH PLUG This part replaces 630746. Price: $1.17 |
| 16 |
630953 |
PUMP ELEMENT Price: $6.03 |
| 17 |
138-6410 |
SPINDLE ASM L.H. This part replaces 95-3089. Price: $553.19 |
| 17 |
632554 |
WELCH PLUG This part replaces 630746. Price: $1.17 |
| 18 |
631049 |
SPRING Price: $1.20 |
| 19 |
630742 |
GASKET Price: $1.25 |
| 20 |
630932A |
INLET NEEDLE Price: $4.39 |
| 21 |
51-1530-01 |
HINGE BRACKET ASM Price: $34.21 |
| 21 |
630750A |
GASKET This part replaces 630750. Price: $3.00 |
| 22 |
32128-23 |
NUT-HF Price: $1.51 |
| 22 |
630978 |
DIAPHRAGM Price: $4.49 |
| 23 |
630751 |
COVER Price: $8.60 |
| 24 |
650545 |
SCREW Price: $1.20 |
| 25 |
106-6753 |
DECAL-DANGER, CE Price: $8.07 |
| 25 |
631201 |
CHECK VALVE Price: $15.40 |
| 26 |
119-8025 |
DEFLECTOR ASM This part replaces 51-1470-01. Price: $402.00 |
| 26B |
631395 |
FUEL FITTING Price: Call Us |
| 27 |
51-1550 |
SPRING Price: $11.35 |
| 27 |
631293 |
SPRING Price: Call Us |
| 28 |
650569 |
SCREW Price: Call Us |
| 29 |
26-1820 |
CAPSCREW Price: $37.35 |
| 29 |
630955 |
RETAINER--NLA Price: Call Us |
| 30 |
26-1990 |
WASHER-BELLEVILLE Price: $16.49 |
| 30 |
650545 |
SCREW Price: $1.20 |
| 31 |
29-5530-03 |
BLADE-STANDARD, 25 INCH, LH Price: $40.07 |
| 33 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 35 |
325-17 |
SCREW-HH Price: $2.90 |
| 36 |
26-1880 |
SPACER-IDLER MOUNT Price: $13.91 |
| 37 |
323-12 |
SCREW-HH Price: $1.14 |
| 39 |
32128-25 |
NUT-HF Price: $3.19 |
| 40 |
36-1740 |
ROLLER-DECK Price: $37.03 |
| 41 |
68-6840 |
SHAFT-ROLLER Price: $64.07 |
| 42 |
68-6710 |
ROLLER Price: $59.98 |
| 43 |
62-4480 |
ROD-ROLLER Price: $18.99 |
