| Ref | Part Number | Description |
|---|
| 1 |
120-8086 |
FRONT FRAME ASM Price: $5,122.88 |
| 2 |
120-8007-03 |
FRAME-REAR Price: $3,094.30 |
| 2 |
532422027 |
SHAFT.ASM.CROSS.LIFT This part replaces 532195223. Price: $69.99 |
| 3 |
108-4018 |
ROPS ASM Price: $1,001.27 |
| 3 |
594018001 |
Levers This part replaces 532195231. Price: $17.99 |
| 4 |
3234-38 |
SCREW-HHF Price: $3.33 |
| 5 |
104-5584-0P |
PLATE-REINFORCEMENT,ROPS This part replaces 104-5584-03. Price: $36.27 |
| 6 |
325-20 |
SCREW-HH Price: $6.29 |
| 7 |
32128-49 |
NUT-HHF Price: $1.04 |
| 8 |
104-5516-0P |
SUPPORT-TUBE This part replaces 104-5516-01. Price: $9.23 |
| 9 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 10 |
32128-20 |
NUT-HF Price: $0.99 |
| 10 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $3.99 |
| 11 |
119-0006 |
ACCESS PLATE ASM Price: $170.08 |
| 12 |
75-1410-01 |
PLATE-ACCESS, FLOOR Price: $142.43 |
| 13 |
125-4614 |
TREAD-FOOT, CENTER Price: $65.72 |
| 14 |
3234-7 |
SCREW-HHF Price: $1.99 |
| 16 |
72-3560 |
DECAL Price: $12.52 |
| 17 |
106-6754 |
DECAL-DANGER Price: $9.57 |
| 87 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 88 |
532410710 |
SPRING.LIFT.ASSIST Price: $9.99 |
| 89 |
819191912 |
WASHER.CLEAR.ZINC Price: $2.99 |
| 90 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 91 |
589464807 |
Links This part replaces 532195181. Price: $14.99 |
| 97 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 98 |
581506903 |
Links This part replaces 532195270. Price: $9.99 |
| 100 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
