| Ref | Part Number | Description |
|---|
| 1 |
104-4620 |
SEAT Price: $273.15 |
| 2 |
138-6985-03 |
MOUNT-SEAT This part replaces 125-2900-03. Price: $355.77 |
| 3 |
125-2927 |
DECAL-SERVICE Price: $39.38 |
| 4 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 5 |
108-8657 |
HARNESS-WIRE, SEAT Price: $19.96 |
| 6 |
92-6282 |
SWITCH-SEAT Price: $31.99 |
| 7 |
9266714 |
SCREW-HWH Price: $0.80 |
| 8 |
92-7307 |
LH ARMREST ASM Price: $200.08 |
| 9 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 10 |
3274-12 |
SCREW-HSH Price: $0.81 |
| 11 |
92-8990 |
ADJUSTER-SLAVE Price: $54.82 |
| 12 |
92-8991 |
ADJUSTER (W/LATCH) Price: $73.04 |
| 13 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 15 |
48-7680 |
SCREW-HH Price: $0.61 |
| 16 |
71-9310 |
SPACER Price: $2.29 |
| 17 |
104-7048 |
CAP-HOUSING Price: $5.21 |
| 18 |
104-7050 |
TUBE-MANUAL Price: $8.76 |
| 19 |
108-6590-0P |
BRACKET-SEAT, LOWER This part replaces 108-6590-03. Price: $50.77 |
| 20 |
145-5295 |
SUSPENSION ASM This part replaces 110-8851. Price: $889.18 |
| 21 |
2412-133 |
CLAMP-R Price: $3.19 |
| 22 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 23 |
100-4928 |
BELT-SEAT Price: $280.73 |
| 24 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 25 |
3212-4 |
SCREW-HH Price: $2.73 |
| 26 |
125-8821 |
ROPS ASM Price: $2,635.36 |
| 27 |
87-3470 |
BUMPER Price: $18.89 |
| 28 |
117-0183-0P |
BRKT-BUMP, LH This part replaces 117-0183-03. Price: $20.15 |
| 29 |
117-0184-03 |
BRACKET-BUMPER, LH Price: $54.36 |
| 30 |
117-0233-03 |
BRACKET-BUMPER, RH Price: $51.03 |
| 31 |
117-0234-0P |
BRKT - BUMP, RH This part replaces 117-0234-03. Price: $19.53 |
| 32 |
3234-38 |
SCREW-HHF Price: $3.33 |
| 33 |
3274-4 |
SCREW-HSH Price: $2.17 |
