| Ref | Part Number | Description |
|---|
| 1 |
139-2651 |
CYLINDER, HYD This part replaces 98-4605. Price: $671.34 |
| 2 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S This part replaces 580532301. Price: $39.99 |
| 3 |
93-2255 |
HYD HOSE ASM Price: $52.69 |
| 4 |
93-2256 |
HYD HOSE ASM Price: $52.48 |
| 5 |
140-5248 |
PIN-PIVOT RAM, WELDED This part replaces 10-6060. Price: $25.64 |
| 6 |
94-8198 |
PIN Price: $31.05 |
| 7 |
94-4548 |
BUMPER-RECESSED Price: $4.68 |
| 8 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 9 |
596501502 |
Keepers This part replaces 501832601. Price: $9.99 |
| 9 |
HY4486 |
NUT UNF 1/2"NYLOC EXT THIN5/16 This part replaces 283-8. Price: $1.36 |
| 10 |
94-9610 |
BUSHING-FLANGE Price: $2.37 |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $229.99 |
| 11 |
99-1455 |
DISCONTINUED Price: Call Us |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 12 |
99-1454 |
CARRIER ASM - LH Price: $443.98 |
| 13 |
98-4624-01 |
DISCONTINUED This part replaces 98-4624. Price: Call Us |
| 14 |
93-2368 |
BUSHING-FLANGE Price: $2.10 |
| 15 |
3211-2 |
SCREW-HH Price: $2.17 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA Price: $44.99 |
| 16 |
104-2078 |
SHAFT-ROLLER This part replaces 93-2363. Price: $73.88 |
| 17 |
104-2091 |
ROLLER-ANTI SCALP This part replaces 93-2362. Price: $45.52 |
| 18 |
3296-19 |
NUT-HEX Price: $0.65 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 19 |
98-2178 |
SCREW - HSFH Price: $19.88 |
| 20 |
104-7719 |
BALL JOINT ASM This part replaces 94-9647. Price: $137.95 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 21 |
98-2174 |
DISCONTINUED Price: Call Us |
| 22 |
98-2176-01 |
LIFT ARM - LH (MACH) This part replaces 98-2176. Price: $210.62 |
| 23 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 24 |
93-2254 |
HYD HOSE ASM Price: $65.17 |
| 25 |
92-8995 |
BUSHING Price: $8.90 |
| 26 |
325-6 |
SCREW-HH Price: $1.42 |
| 27 |
3218-5 |
NUT-JAM Price: $0.27 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 28 |
93-2384 |
SPACER-CARRIER Price: $9.09 |
| 29 |
137-9706 |
DECAL-WARNING This part replaces 93-8064. Price: $4.48 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
237-78 |
O-RING Price: $3.85 |
| 31 |
237-21 |
O-RING Price: $0.70 |
| 32 |
32144-44 |
SCREW-HWH, THREAD ROLL Price: $1.39 |
| 33 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 34 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 35 |
98-2199 |
DISCONTINUED Price: Call Us |
| 36 |
95-2903 |
ANGLE-BASKET SEAL Price: $16.47 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
93-2551 |
SEAL-BASKET Price: $7.89 |
| 38 |
3290-382 |
RIVET-POP Price: $1.39 |
| 39 |
325-4 |
SCREW-HH Price: $0.95 |
| 40 |
74-3730 |
SPACER-SPINDLE, REAR Price: $5.06 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 41 |
94-9648 |
BALL STUD Price: $19.68 |
| 42 |
104-7709 |
SHELL & HOUSING ASM This part replaces 98-2179. Price: $147.41 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 45 |
98-0632 |
DISCONTINUED Price: Call Us |
| 69 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532165291. Price: $8.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED Price: $3.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 94 |
581880901 |
EXHAUST.TUBE.B&S.28/31 Price: $19.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
