| Ref | Part Number | Description |
|---|
| 1 |
3217-7 |
NUT-HEX Price: $0.28 |
| 1 |
HG72267 |
Kit, Housing Price: Call Us |
| 2 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 3 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 3 |
HG50641 |
STRAIGHT HEADLESS PIN Price: Call Us |
| 4 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 4 |
HG50969 |
HEX FLANGE BOLT, M8-1.25 X 60MM Price: Call Us |
| 5 |
27-4160 |
PUMP CONTROL TUBE WA Price: $213.39 |
| 5 |
HG54022 |
HOUSING, O'RING Price: Call Us |
| 6 |
23-2270 |
BUSHING-RUBBER Price: $17.07 |
| 6 |
HG70622 |
Kit, Charge Pump Price: Call Us |
| 7 |
27-5310-03 |
DISCONTINUED This part replaces 27-5310. Price: Call Us |
| 8 |
27-4340-03 |
MASKED HUB & PLUG ASM This part replaces 27-4340. Price: $139.67 |
| 8 |
HG2513030 |
BYPASS VALVE KIT Price: Call Us |
| 9 |
3245-1 |
SCREW-SET, HSH Price: $0.54 |
| 10 |
99-5677 |
TRANSMISSION ASM This part replaces 49-7910. Price: $4,071.30 |
| 10 |
HG51161 |
LIP SEAL Price: Call Us |
| 11 |
27-3270-03 |
FAN SHROUD ASM This part replaces 27-3270. Price: $49.22 |
| 11 |
HG50329 |
RETAINING RING Price: Call Us |
| 12 |
274370 |
Pump Hub Price: Call Us |
| 13 |
44-8720-03 |
DISCONTINUED This part replaces 44-8720. Price: Call Us |
| 13 |
HG2003014 |
BLOCK, SPRING Price: Call Us |
| 14 |
32152-5 |
NUT-HEX Price: $0.54 |
| 14 |
HG2003017 |
DISCONTINUED Price: Call Us |
| 15 |
115-4523 |
COUPLING-RUBBER This part replaces 44-2230. Price: $52.81 |
| 15 |
HG53998 |
Swashplate Price: Call Us |
| 16 |
125-9249 |
SPACER-COUPLER, RUBBER This part replaces 27-6600. Price: $2.15 |
| 17 |
3210-5 |
SCREW-HH Price: $0.54 |
| 18 |
62-7400 |
DECAL This part replaces 43-5120. Price: $24.54 |
| 18 |
HG2000015 |
SLOT GUIDE Price: Call Us |
| 19 |
33-2020 |
DISCONTINUED Price: Call Us |
| 19 |
HG70838 |
Kit, Shock Valve - 160 Bar (.031 Orifice) Price: Call Us |
| 20 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 20 |
HG70838 |
Kit, Shock Valve - 160 Bar (.031 Orifice) Price: Call Us |
| 21 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 21 |
HG70403 |
CHARGE RELIEF KIT Price: Call Us |
| 22 |
3210-8 |
SCREW-HH Price: $1.02 |
| 22 |
HG2513043 |
TRUNNION SEAL WITH RETAINER Price: Call Us |
| 23 |
323-38 |
SCREW-HH Price: $2.62 |
| 24 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 24 |
HG70525 |
OVERHAUL SEAL KIT Price: Call Us |
| 25 |
27-3680 |
SPACER-MOUNTING Price: $6.65 |
| 26 |
86-7220 |
GEAR-PINION This part replaces 23-4810. Price: $81.33 |
| 27 |
32120-72 |
RING-SNAP Price: $2.09 |
| 27 |
HG9005110-5600 |
Straight Thread Plug Price: Call Us |
| 28 |
27-3690 |
GASKET-TRANSMISSION Price: $8.27 |
| 29 |
27-3740 |
DISCONTINUED Price: Call Us |
| 30 |
274360 |
Washer Price: Call Us |
| 31 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 32 |
3218-5 |
NUT-JAM Price: $0.27 |
| 33 |
321-2 |
SCREW-HH Price: $2.79 |
| 34 |
3253-3 |
WASHER-LOCK Price: $0.31 |
