| Ref | Part Number | Description |
|---|
| 1 |
323-7 |
SCREW-HH Price: $0.65 |
| 1 |
98000129 |
NUT Price: Call Us |
| 2 |
161415X428 |
SHLD.SIDE.OUTER.L Price: Call Us |
| 2 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 3 |
32146-20 |
NUT-HEX Price: $3.23 |
| 3 |
8393J |
STAKE PIN TI Price: Call Us |
| 4 |
12000036 |
KLIP RING TI Price: Call Us |
| 4 |
98-8172-03 |
SUPPORT-AXLE Price: $656.24 |
| 5 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 5 |
72140506 |
BOLT Price: Call Us |
| 6 |
237-165 |
GROMMET Price: $15.70 |
| 6 |
8394J |
SPRING TI Price: Call Us |
| 7 |
8392J |
LATCH BRACKET TI Price: Call Us |
| 8 |
109230X |
SPRING CRT Price: Call Us |
| 8 |
32121-32 |
PIN-ROLL Price: $1.34 |
| 9 |
102326X428 |
SHIELD TINE Price: Call Us |
| 9 |
140-6101 |
PIN ASM-AXLE PIVOT This part replaces 98-8173-03. Price: $42.42 |
| 10 |
104085X428 |
SHIELD SIDE Price: Call Us |
| 10 |
71-4540 |
WASHER-THRUST Price: $1.97 |
| 11 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 11 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 12 |
10040500 |
LOCKWASHER Price: Call Us |
| 12 |
99-8431 |
WASHER-THRUST Price: $4.63 |
| 13 |
72110510 |
BOLT Price: Call Us |
| 13 |
99-8432 |
WASHER-THRUST Price: $4.21 |
| 14 |
124343X |
BRKT SHIELD TINE Price: Call Us |
| 15 |
161414X428 |
SHLD.SIDE.OUTER.R Price: Call Us |
| 16 |
73510400 |
NUT Price: Call Us |
| 18 |
72040410 |
BOLT Price: Call Us |
| 19 |
102701X |
GRIP CRT Price: Call Us |
| 20 |
73220600 |
NUT.HEX.3/8-16UNC Price: Call Us |
| 21 |
102156X |
SUB= 102156X500 Price: Call Us |
| 22 |
74930632 |
BOLT Price: Call Us |
| 23 |
4440J |
HINGE CRT Price: Call Us |
| 24 |
72140404 |
BOLT Price: Call Us |
| 25 |
6712 |
J VINYL CAP TI Price: Call Us 6712 J |
| 26 |
109227X |
PAD IDLER TI Price: Call Us |
