| Ref | Part Number | Description |
|---|
| 1 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 1 |
539101220 |
CABLE, THROTTLE (17 KAW.) Price: $24.99 |
| 2 |
250-1 |
DISCONTINUED Price: Call Us |
| 2 |
539105804 |
CLUTCH Price: $219.99 |
| 3 |
2412-109 |
CLIP-J Price: $3.82 |
| 3 |
539130394 |
FUEL CAP, GENERIC This part replaces 539106188. Price: $27.99 |
| 4 |
237-100 |
GROMMET Price: $9.73 |
| 4 |
539105630 |
FUEL TANK Price: $201.99 |
| 5 |
104-5232 |
CLIP-WIRE This part replaces 60-0930. Price: $3.13 |
| 5 |
539102650 |
HOSE BARB 90 DEGREE Price: $4.99 |
| 6 |
539912222 |
HOSE CLAMP Price: $2.99 |
| 7 |
539932956 |
GAS LINE 10" Price: $6.99 |
| 7 |
82-9760 |
WIRE HARNESS - GAUGES Price: $202.94 |
| 8 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 8 |
539916325 |
FUEL VALVE Price: $9.99 |
| 9 |
539101202 |
HYDRAULIC CAP Price: $19.99 |
| 9 |
82-9790 |
HARNESS Price: $69.81 |
| 10 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 10 |
82-9810 |
DISCONTINUED Price: Call Us |
| 11 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 12 |
539990761 |
NUT 1/4C CENTER LOCK Price: $2.99 |
| 12 |
82-9940 |
HARNESS Price: $22.70 |
| 13 |
539102502 |
STUD, 5/16C Price: $8.99 |
| 14 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 14 |
82-9800 |
DISCONTINUED Price: Call Us |
| 15 |
539102845 |
SPRING Price: $2.99 |
| 15 |
58-3850 |
CABLE Price: $80.83 |
| 16 |
539105985 |
OIL TANK BLK Price: $131.99 |
| 16 |
58-3840 |
DISCONTINUED Price: Call Us |
| 17 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 17 |
92-5685 |
DISCONTINUED Price: Call Us |
| 18 |
539105826 |
BOLT - 5/16 X 7 Price: $3.99 |
| 18 |
82-9750 |
HARNESS Price: $24.36 |
| 19 |
539105942 |
BATTERY STRAP Price: $29.99 |
| 20 |
579411601 |
BATTERY, 12 V 300 AMP DRY This part replaces 539102463. Price: $129.99 |
| 21 |
2412-131 |
R-CLAMP-CABLE Price: $5.02 |
| 21 |
539990134 |
SCREW 3/8C X 3/4 HEX CAP Price: $3.99 |
| 22 |
539105943 |
BATTERY TRAY Price: $33.99 |
| 23 |
539105590 |
TANK SUPPORT Price: $279.99 |
| 24 |
539105913 |
PUMP ARM WELDMENT Price: $59.99 |
| 24 |
86-6400 |
DIODE F/W ENGINE Price: $130.34 |
| 25 |
2412-74 |
R-CLAMP Price: $2.37 |
| 25 |
539104547 |
LOWER BELT SHIELD Price: $37.99 |
| 26 |
37-2690 |
CAPACITOR Price: $155.98 |
| 26 |
539132147 |
HG_PUMP, 10CC W/O FAN OR RTN This part replaces 539104529. Price: $1,099.99 |
| 27 |
38-2860 |
RESISTOR- 5 OHM Price: $71.95 |
| 27 |
539101224 |
SPRING Price: $19.99 |
| 28 |
539101165 |
FILTER HEAD Price: $37.99 |
| 29 |
539102606 |
HYDRAULIC OIL FILTER Price: $22.99 |
| 30 |
539105806 |
SPACER Price: $22.99 |
| 31 |
539106446 |
STRUT SHAFT Price: $199.99 |
| 32 |
539105641 |
FRONT SPACER Price: $14.99 |
| 33 |
539101177 |
KEY 5 MM SQ X 25 MM Price: $4.99 |
| 34 |
539102228 |
PULLEY Price: $42.99 |
| 35 |
539919078 |
IDLER PULLEY Price: $27.99 |
| 36 |
539101228 |
TRANSMISSION BELT Price: $37.99 |
| 37 |
539105577 |
STRUT WELDMENT Price: $179.99 |
| 38 |
539101109 |
HUB.WHEEL.ZTR Price: $84.99 |
| 39 |
587653903 |
Nuts This part replaces 539101173. Price: $3.99 |
| 40 |
539103527 |
WHEEL MOTOR Price: $649.99 |
| 41 |
539106491 |
MOTOR MOUNT Price: $36.99 |
| 42 |
539990622 |
HCS 1/2C X 1 1/4 SERRATED HEAD Price: $3.99 |
| 43 |
539101332 |
HCS 1/2C X 2 3/4 Price: $4.99 |
| 44 |
539990297 |
COTTER PIN Price: $2.99 |
| 45 |
539102717 |
SCREW 5/16C X 5/8 SQ HEAD Price: $2.99 |
| 46 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 47 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 48 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 49 |
596564404 |
Bolts This part replaces 539990629. Price: $2.99 |
| 50 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 51 |
596583601 |
Bolts This part replaces 539990646. Price: $2.99 |
| 52 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 53 |
539106492 |
HEX SCREW 3/8-20 X 2.75 Price: $2.99 |
| 54 |
596582501 |
Bolts This part replaces 539990072. Price: $2.99 |
| 55 |
596564801 |
Washers This part replaces 539990052. Price: $1.99 |
| 57 |
539106572 |
REAR DECK Price: $34.99 |
| 58 |
539105535 |
TIRE.TURF.SAVER.18X7.5-8 Price: $169.99 |
| 58 |
539105805 |
TIRE/WHEEL ASSY Price: $159.99 |
| 58 |
539912234 |
VALVE STEM TR-412 Price: $3.99 |
| 59 |
539102223 |
CLEVIS PIN Price: $0.61 |
| 60 |
596436201 |
Nuts This part replaces 539102234. Price: $1.99 |
| 61 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 62 |
539101714 |
SOLENOID Price: $22.99 |
| 64 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 65 |
539102758 |
CABLE-NEGATIVE Price: $12.99 |
| 66 |
586108201 |
CABLE BATTERY POS RZ This part replaces 539103306. Price: $8.99 |
| 67 |
539102759 |
INSULATOR Price: $3.99 |
| 68 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 69 |
874780528 |
SCREW This part replaces 539990669. Price: $4.99 |
| 70 |
539101995 |
KEY 1/4 SQ X 1 1/8 Price: $2.99 |
| 71 |
539105610 |
PULLEY Price: $37.99 |
| 72 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 73 |
539991120 |
BOLT 7/16F X 2 1/2 Price: $5.99 |
| 74 |
539103251 |
CLUTCH TIE DOWN Price: $34.99 |
| 75 |
539923515 |
SPACER Price: $4.99 |
| 76 |
539916159 |
SPRING-TRANS Price: $5.99 |
| 77 |
595901401 |
Bolts This part replaces 539100145. Price: $2.99 |
| 78 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
