| Ref | Part Number | Description |
|---|
| 1 |
137-6110 |
TUBE ROLLER 3.0IN DIA X 24.5IN This part replaces 114-5413-03. Price: $273.64 |
| 1 |
532188249 |
DECK.WLDMNT.38"LR This part replaces 532142830. Price: $229.99 |
| 2 |
114-5403 |
SHAFT-ROLLER, FRONT Price: $82.00 |
| 2 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 3 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
532007631 |
Runner, Mower LH (AYP part number) This part replaces 532125074. Price: $11.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 5 |
532110485 |
Bearing (AYP part number) Price: $7.99 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 6 |
532128774 |
Housing, Mandrel Price: $22.99 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
532129895 |
Bearing (AYP part number) Price: $6.99 |
| 8 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $17.99 |
| 9 |
532134148 |
Blade Price: $14.99 |
| 10 |
532140296 |
Washer, Hardened (AYP part number) Price: $2.99 |
| 11 |
539990118 |
SLW 3/8 STD This part replaces 810030600. Price: $1.99 |
| 12 |
532850857 |
Bolt, Hex 3/8-24 x 1-1/4 Grade 8 (AYP part number) Price: $1.99 |
| 13 |
532174493 |
STRIPPER.MANDREL.ROUND.BLACK This part replaces 532140329. Price: $3.99 |
| 14 |
532106736 |
Shield, Deflector (AYP part number) Price: $27.99 |
| 15 |
532106735 |
Rod, Hinge (AYP part number) Price: $4.99 |
| 16 |
532137607 |
Bracket Assembly, Deflector (AYP part number) Price: $3.99 |
| 17 |
532110452 |
Pushnut (AYP part number) Price: $1.99 |
| 18 |
532123713 |
Spring, Deflector (AYP part number) Price: $3.99 |
| 19 |
819111016 |
Washer 11/32 x 5/8 x 16 Gauge (AYP part number) Price: $5.99 |
| 20 |
532105304 |
Cap, Sleeve (AYP part number) Price: $2.99 |
| 21 |
532128772 |
Runner, R.H. (AYP part number) Price: $5.99 |
| 22 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111216. Price: $2.99 |
| 23 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532138776. Price: $1.99 |
| 24 |
532124670 |
Retainer, Spring (AYP part number) Price: $5.99 |
| 25 |
874760636 |
BOLT This part replaces 874600636. Price: $2.99 |
| 26 |
819131612 |
Washer 13/32 x 1 x 12 Gauge (AYP part number) Price: $3.99 |
| 27 |
532139756 |
Link Assembly, Front (AYP part number) Price: $14.02 |
| 28 |
872110608 |
BOLT D This part replaces 872140608. Price: $3.99 |
| 29 |
532139757 |
Plate Slide Link (AYP part number) Price: $2.99 |
| 30 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 31 |
532140915 |
Clutch Rod, Primary (AYP part number) Price: $14.99 |
| 32 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 33 |
532132559 |
Arm, Suspension, Rear (AYP part number) Price: $4.99 |
| 34 |
532133604 |
Trunnion 3/8-16 (AYP part number) Price: $17.99 |
| 35 |
532132554 |
Clutch Rod, Secondary (AYP part number) Price: $11.99 |
| 36 |
819131316 |
Washer 13/32 x 13/16 x 16 Gauge (AYP part number) Price: $2.99 |
| 37 |
876020308 |
Pin, Cotter 3/32 x 1/2 (AYP part number) This part replaces 876020312. Price: $1.99 |
| 38 |
532133840 |
Idler Arm (AYP part number) Price: $4.99 |
| 39 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $1.99 |
| 40 |
532129206 |
Pulley, Mandrel (AYP part number) Price: $14.99 |
| 41 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $4.99 |
| 42 |
532121316 |
Pulley, Flat Idler (AYP part number) Price: $22.99 |
| 43 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $2.99 |
| 44 |
819131612 |
Washer 13/32 x 1 x 12 Gauge (AYP part number) Price: $3.99 |
| 45 |
873680600 |
Nut, Crownlock 3/8-16 Price: $1.99 |
| 46 |
532419271 |
V-BELT.DRIVE.MOWER.30" This part replaces 532126520. Price: $39.99 |
| 47 |
532133502 |
Spacer, Idler Arm (AYP part number) Price: $2.99 |
| 48 |
532133503 |
Stiffener, Idler Arm (AYP part number) Price: $3.99 |
| 49 |
532133551 |
Rod, Pivot (AYP part number) Price: $4.99 |
| 50 |
114-5430 |
ROLLER REBUILD KIT Price: $99.53 |
| 50 |
532131289 |
Rod, Brake, L.H. (AYP part number) Price: $11.99 |
| 51 |
532130840 |
Brake Assembly (AYP part number) Price: $8.99 |
| 52 |
539976934 |
HCS 5/16C X 3/4 This part replaces 817490512. Price: $1.99 |
| 53 |
532131288 |
Rod, Brake, R.H. (AYP part number) Price: $5.99 |
| 54 |
872110614 |
Bolt, Carriage 3/8-16 x 1-3/4 Grade 5 (AYP part number) Price: $3.99 |
| 55 |
532004921 |
Spring, Retainer (AYP part number) This part replaces 532124961. Price: $3.99 |
| 56 |
532136782 |
Adjustment Plate, Rear Link, L.H. (AYP part number) Price: $2.99 |
| 57 |
872110608 |
BOLT D This part replaces 872140608. Price: $3.99 |
| 58 |
734117201 |
WASHER This part replaces 819131212. Price: $1.99 |
| 59 |
873800500 |
Locknut, Hex, with Washer Insert 5/16-18 (AYP part number) Price: $2.99 |
| 60 |
819111112 |
Washer 11/32 x 11/16 x 12 Gauge (AYP part number) Price: $2.99 |
| 62 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $1.99 |
| 63 |
532004497 |
RETAINER M This part replaces 532124788. Price: $5.99 |
| 64 |
873680600 |
LOCKNUT This part replaces 873930600. Price: $1.99 |
| 65 |
819132016 |
Washer 13/32 x 1-1/4 x 16 Ga. (AYP part number) Price: $5.99 |
| 66 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 67 |
532135651 |
Nut Wing (AYP part number) Price: $3.99 |
| 68 |
532132803 |
Cover Asm Mulching (AYP part number) Price: $49.99 |
| 69 |
874930620 |
Bolt 3/8 - 16 x 1-1/4 (AYP part number) Price: $3.99 |
| 70 |
819162016 |
Washer 1/2 x 1-1/4 x 16 Ga. (AYP part number) Price: $3.99 |
| 71 |
819131610 |
Washer Flat 13/32 x 1 x 10 Ga. (AYP part number) Price: $3.99 |
| 72 |
532178515 |
WASHER This part replaces 532133943. Price: $2.99 |
