| Ref | Part Number | Description |
|---|
| 3 |
710-0216 |
HEX SCREW 3/8-16 X .75 This part replaces 1100068. Price: $3.93 |
| 4 |
936-0119 |
LOCK WASHER 5/16 This part replaces 1100242. Price: $4.29 |
| 5 |
736-0169 |
L-Wash. 3/8" I.D." This part replaces 1100243. Price: $3.33 |
| 7 |
714-0474 |
Cotter Pin This part replaces 1100349. Price: $4.08 |
| 8 |
914-0868 |
KEY-WOODRUFF .188X.75 This part replaces 1104436. Price: $3.50 |
| 10 |
736-3050 |
Washer, Plain (flat) 3/8, S.A.E. This part replaces 1107383. Price: $3.90 |
| 12 |
1111602 |
CAPSCR-HEXHEAD Not Available Price: |
| 13 |
710-0521 |
SCREW 3/8-16 x 3 GR8 This part replaces 1111614. Price: $4.54 |
| 14 |
1177625 |
ROLL PIN .125 x .7 Not Available Price: |
| 16 |
1185026 |
LINK-CONNE Not Available Price: |
| 17 |
1185130 |
SCREW HEX Not Available Price: |
| 19 |
1185838 |
BEARING-FL Not Available Price: |
| 20 |
1186048 |
PUSH NUT O Not Available Price: |
| 21 |
1186098 |
SCREW-CARR Not Available Price: |
| 22 |
710-0389 |
Screw, Carriage, 3/8-16 x .75 This part replaces 1186126. Price: $3.89 |
| 23 |
710-3168 |
CARRIAGE BOLT 3/8-16 x 1.00 GR5 This part replaces 1186128. Price: $3.61 |
| 24 |
712-3010 |
HEX NUT 5/16-18 This part replaces 1186230. Price: $3.89 |
| 27 |
710-04043 |
SCREW 5/16-18 This part replaces 1186329. Price: $3.96 |
| 28 |
1186332 |
SCR-HFLK 5 Not Available Price: |
| 29 |
1186345 |
SCREW Not Available Price: |
| 31 |
712-04054 |
NUT-HFLK 5/16-18 ZP This part replaces 1186391. Price: $3.95 |
| 32 |
1186393 |
NUT-HFLK 3/8-16 ZP Price: $2.63 |
| 33 |
1714782 |
BLOCK-SWIVEL NYLON Price: $22.11 |
| 35 |
720-0269 |
Clutch Grip This part replaces 1715685. Price: $4.24 |
| 37 |
1719345 |
HANDLE CRANK Not Available Price: |
| 38 |
1722501 |
CHUTE GUARD Not Available Price: |
| 39 |
1722614 |
SPROCKET Not Available Price: |
| 40 |
1722617001 |
COVER-END Not Available Price: |
| 41 |
1723643 |
ADJUSTING LEVER Not Available Price: |
| 42 |
1723776 |
SPACER-.68X.39X.46 Price: Call Us |
| 43 |
1724869099 |
HOLD-DOWN NYLON CLIP This part replaces 1724869. Price: $9.86 |
| 44 |
1724870 |
WORM GEAR (LH) Not Available Price: |
| 45 |
1724885 |
ROLL PIN Not Available Price: |
| 46 |
1726829 |
BLOCK-TENSION Not Available Price: |
| 48 |
1732499 |
NUT-TOP/LK 5/16-18 ZP Price: $3.49 |
| 49 |
712-3000 |
Hex Lock Nut, 3/8-16 This part replaces 1733398. Price: $3.90 |
| 50 |
712-3000 |
Hex Lock Nut, 3/8-16 This part replaces 1733398. Price: $3.90 |
| 51 |
1737499 |
VACUCUT GRIP Not Available Price: |
| 52 |
1983039 |
NUT-HK Not Available This part replaces 1737938. Price: |
| 53 |
1745341 |
CHAIN-DRIVE Not Available Price: |
| 54 |
1748499001 |
ASSM-BRKT Price: Call Us |
| 55 |
1750691 |
DECAL-WARNING AUGE Not Available Price: |
| 56 |
1750692 |
DECAL-WARNING CHUT Not Available Price: |
| 57 |
1750697001 |
ASSY ROTOR 38" Price: Call Us |
| 59 |
1750859001 |
SLINGER EX Not Available Price: |
| 60 |
1751060 |
DECAL-WARNING Price: Call Us |
| 63 |
1754601001 |
ASSEMBLY PLATE Not Available Price: |
| 64 |
1754602 |
SHAFT-ROTO Not Available Price: |
| 65 |
1756579 |
SEAL Not Available Price: |
| 66 |
1756723001 |
PLATE Not Available Price: |
| 67 |
1758312001 |
BLADE-SCRA Not Available Price: |
| 71 |
1768786001 |
CHUTE-DISCHARGE Price: Call Us |
| 75 |
1768824 |
SPACER-PIN Not Available Price: |
| 77 |
1768837 |
SHAFT-PINI Not Available Price: |
| 78 |
1768838 |
SUPPORT-SHAFT Not Available Price: |
| 83 |
1768782001 |
ARM-LIFT Not Available Price: |
| 84 |
1768849001 |
BRACKET-SPRING Not Available Price: |
| 87 |
1800418 |
BEARING Not Available Price: |
| 88 |
1741640 |
BEARING-BA Not Available Price: |
| 90 |
1748307 |
SHEAVE-DRIVE Not Available Price: |
| 92 |
1186348 |
SCR-HFLK 3 Not Available Price: |
| 103 |
1768881001 |
SKID SHOE Not Available Price: |
| 202 |
1768864 |
ASSM-HOUSI Not Available Price: |
| 203 |
1765817 |
ASSM-DISCH Not Available Price: |
| 204 |
1185798 |
HEX SCREW Not Available Price: |
| 205 |
1750858001 |
ASSEMBLY DEFLECTOR Not Available Price: |
| 14082 |
LEVER |
ASSEMBLY-SPRING Not Available This part replaces 14083. Price: 14082 |
