| Ref | Part Number | Description |
|---|
| 1 |
120-4155 |
PANEL ASM Price: $321.47 |
| 1 |
579841401 |
KITS.CHASSIS.STAMPED.SERVICE This part replaces 532174619. Price: $379.99 |
| 2 |
108-7604 |
COVER-LH Price: $55.56 |
| 2 |
532176554 |
DRAWBAR, 12GA Price: $37.99 |
| 3 |
108-7605 |
COVER-RH Price: $55.56 |
| 4 |
32144-112 |
SCREW-HWH Price: $0.99 |
| 5 |
3250-22 |
SCREW-PPH Price: $4.09 |
| 6 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 7 |
115-8849-03 |
PLATE-COVER Price: $23.24 |
| 8 |
3234-21 |
SCREW-HHF Price: $2.19 |
| 9 |
532187937 |
DASH, STEALTH This part replaces 532189025. Price: $49.99 |
| 10 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 10 |
94-2413 |
NUT-U Price: $1.79 |
| 11 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 11 |
532167203 |
PANEL DASH LH Price: $19.99 |
| 12 |
125-4646-03 |
PANEL-CONTROL Price: $92.78 |
| 13 |
532178298 |
PANEL DASH RH Price: $19.99 |
| 14 |
108-7602 |
REST-ARM Price: $158.43 |
| 14 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 15 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 16 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 17 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 18 |
121-5159 |
IGNITION SWITCH ASM Price: $84.21 |
| 20 |
532162026 |
PLATE BATTERY Price: $6.99 |
| 21 |
120-6310 |
LCD DISPLAY ASM Price: $584.72 |
| 26 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 27 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 28 |
532182873 |
GRILLE.STEALTH P/L.YTGT.GREY Price: $169.99 |
| 28 |
99-7420 |
PLUG-HOLE Price: $7.64 |
| 29 |
532188212 |
LIGHTBOX.ASM.STV.DL.INC.HUSQ Price: $89.99 |
| 29 |
95-8999 |
SWITCH Price: $42.14 |
| 30 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 30 |
532192814 |
FENDER.W/CUPHOLDER.ORANGE This part replaces 532191815. Price: $219.99 |
| 31 |
161-8355 |
CUP HOLDER ASM This part replaces 117-2378. Price: $12.36 |
| 31 |
532139976 |
BRACKET.SUPPORT.FENDER Price: $14.99 |
| 32 |
107069 |
CLIP Price: $1.79 |
| 33 |
99-7411 |
POINT-POWER Price: $30.69 |
| 34 |
99-7416 |
CAP Price: $6.64 |
| 35 |
93-9999 |
SWITCH-PTO Price: $42.99 |
| 36 |
110-0542 |
SPACER-FLANGE Price: $4.94 |
| 37 |
100-1535 |
SWITCH Price: $84.91 |
| 37 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 38 |
32144-18 |
SCREW-HWH Price: $1.80 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR Price: $9.99 |
| 54 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 Price: $3.99 |
| 58 |
532189875 |
NEEDS DESCRIPTION Price: Call Us |
| 59 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 60 |
872140606 |
Bolt - Rd. Hd. Sq. Neckiage 3/8 16 x 3/4 Price: $4.99 |
| 64 |
532174997 |
DASH LOWER Price: $24.99 |
| 74 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 90 |
532124346 |
NUT.PUSH.3/16 Price: $6.99 |
| 142 |
532175702 |
PLATE REINFORCEMENT Price: $7.99 |
| 143 |
532186689 |
BRACKET, SWAYBAR CHASSIS Price: $5.99 |
| 144 |
532175582 |
BRKT, FOOT REST Price: $4.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 154 |
532161897 |
BRACKET DASH STEALTH(R) Price: $5.99 |
| 155 |
532161900 |
BRACKET DASH STEALTH LH Price: $5.99 |
| 158 |
532162037 |
BRACKET PARKING BRAKE Price: $3.39 |
| 159 |
532191120 |
CUPHOLDER.RIGHT.GREY This part replaces 532185434. Price: $8.99 |
| 161 |
532164655 |
EXTRUSION BUMPER (3 2) (2 2) Price: $5.99 |
| 206 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 209 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 213 |
532177587 |
SKIRT GRILLE LH Price: $23.99 |
| 214 |
532177586 |
SKIRT GRILLE RH Price: $37.99 |
| 217 |
532179132 |
CONSOLE FUEL WINDOW GRAY This part replaces 532185436. Price: $7.99 |
| 278 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
