| Ref | Part Number | Description |
|---|
| 1 |
117-0959 |
ROLLER-WIEHLE, PLASTIC Price: $366.77 |
| 1A |
631776A |
SHAFT & LEV This part replaces 631776. Price: $12.00 |
| 2 |
117-0957 |
SHAFT-ROLLER, WIEHLE Price: $105.15 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $29.99 |
| 2 |
631970 |
RET SPRING This part replaces 631777. Price: $3.00 |
| 3 |
631778 |
SHUTTER Price: $1.20 |
| 4 |
650506 |
SCREW Price: $0.87 |
| 5 |
630766 |
SPRING Price: $1.25 |
| 5A |
630738 |
SPRING Price: $1.25 |
| 6 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7C |
631779 |
SHAFT & LEV Price: $5.16 |
| 8A |
631780B |
RET SPRING This part replaces 631780. Price: $1.25 |
| 9 |
584908001 |
KEEPER BELT ENGINE This part replaces 532194320. Price: $2.99 |
| 9 |
631753 |
SHUTTER Price: $1.25 |
| 10 |
630748 |
WELCH PLUG This part replaces 631746. Price: $1.17 |
| 11 |
631027 |
WELCH PLUG Price: $1.17 |
| 12 |
532405471 |
PULLY ENGINE Price: $64.99 |
| 12 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 13 |
631022 |
CLIP Price: $1.25 |
| 14 |
632019A |
FLOAT This part replaces 631023. Price: $5.85 |
| 15 |
532430646 |
TANK ASM.FRONT.CARB.1.5GA.E10 Price: $279.99 |
| 15 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 16 |
631867 |
FLOAT BOWL Price: $2.34 |
| 17 |
27136A |
DRAIN ASSY Price: $5.96 |
| 18 |
27554 |
GASKET Price: $1.05 |
| 18 |
532430219 |
CAP ASM.FUEL.2.25"FRT.CARB Price: $39.99 |
| 20 |
583045801 |
CNTRL.TH/CK.PADDL.20_2.BLK.#37 This part replaces 532170545. Price: $24.99 |
| 20 |
631861 |
POWER SCREW Price: $7.29 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 21 |
631334A |
GASKET This part replaces 631334. Price: $2.25 |
| 23 |
630740 |
O RING Price: $1.49 |
| 24 |
630898 |
ADJ SCREW Price: $1.69 |
| 25 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 26A |
632527 |
FUEL FITTING This part replaces 631775. Price: $6.03 |
| 27 |
630739 |
WASHER Price: $1.25 |
| 28 |
532401137 |
LINE.FUEL.20"FRONT.EMI Price: $9.99 |
| 29 |
532131780 |
Kit Spark Arrestor 1 25 Price: Call Us |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 50 |
114-5430 |
ROLLER REBUILD KIT Price: $99.53 |
| 69 |
532272293 |
Gasket Eng 1 313 Id Tin Plated (AYP part number) This part replaces 532165291. Price: $7.99 |
| 79 |
532192334 |
SCREW.SOCKET HD.5/16-1 Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $2.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $11.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 85 |
501606501 |
Speed Clip This part replaces 532173937. Price: $1.99 |
| 87 |
532171877 |
BOLT, 5/16-18 X 1 3/4 Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 94 |
581880901 |
EXHAUST.TUBE.B&S.28/31 This part replaces 532405450. Price: $17.99 |
| 96 |
819091416 |
WASHER Price: $3.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
| 109 |
532414114 |
CANNISTER, CARBON Price: $32.99 |
| 111 |
532448562 |
KIT.PURGE.LINE.55" This part replaces 532414119. Price: $14.99 |
