| Ref | Part Number | Description |
|---|
| 1 |
52-9260 |
SCREW-SET Price: $8.09 |
| 3 |
52-9230 |
RING-RETAINING Price: $26.68 |
| 4 |
52-9240 |
BUSHING Price: $65.67 |
| 7 |
59-6730 |
RACE Price: $10.63 |
| 8 |
59-6740 |
BEARING Price: $28.82 |
| 11 |
59-6820 |
CENTERING SPRING KIT Price: $50.64 |
| 14 |
92-9732 |
PLATE-WEAR Price: $101.64 |
| 15 |
52-9320 |
DRIVE Price: $141.01 |
| 16 |
76-6300 |
GEROTOR ASM Price: $478.69 |
| 17 |
76-6320 |
SPACER Price: $9.40 |
| 18 |
92-9730 |
CAP-END Price: $167.54 |
| 19 |
92-9736 |
SCREW-CAP Price: $4.82 |
| 20 |
59-6830 |
CENTERING PIN KIT Price: $3.98 |
| 21 |
52-9290 |
RETAINER-CHECKBALL Price: $15.41 |
| 22 |
52-9280 |
CHECKBALL Price: $7.01 |
| 24 |
52-9270 |
SEAT-CHECKBALL Price: $35.12 |
| 501220001 |
501220001 |
SCREEN Price: $0.99 |
| 501220101 |
501220101 |
LOCKING RING Price: $0.69 |
| 501220201 |
501220201 |
PLUG (TIL 179-60X) Price: $2.25 |
| 501220301 |
501220301 |
Plug Price: $0.85 |
| 501220401 |
501220401 |
BALL Price: $11.99 |
| 501220501 |
501220501 |
SPRING Price: $3.99 |
| 501220801 |
501220801 |
GASKET, METERING SIDE Price: $3.99 |
| 501220901 |
501220901 |
METERING DIAPHRAGM Price: $14.99 |
| 501221001 |
501221001 |
CAP Price: $5.99 |
| 501221201 |
501221201 |
FUEL PUMP DIAPHRAGM Price: $7.99 |
| 501221301 |
501221301 |
GASKET, PUMP SIDE Price: $3.99 |
| 501221401 |
501221401 |
CAP Price: $27.99 |
| 501221501 |
501221501 |
SCREW Price: $3.99 |
| 501221701 |
501221701 |
SPRING Price: $3.99 |
| 501222001 |
501222001 |
LEVER Price: $4.99 |
| 501222101 |
501222101 |
SHAFT Price: $6.99 |
| 501222201 |
501222201 |
SCREW Price: $1.30 |
| 501222401 |
578004601 |
FILTER This part replaces 501222401. Price: $0.99 |
| 501222501 |
501222501 |
SPRING Price: $3.99 |
| 501223001 |
503652701 |
SCREW This part replaces 501223001. Price: $4.99 |
| 501223201 |
501223201 |
THROTTLE FLAP Price: $4.99 |
| 501238801 |
503534001 |
NIPPLE This part replaces 501238801. Price: $14.99 |
| 501268501 |
501268501 |
IDLE ADJ. SCREW Price: $17.99 |
| 501268901 |
501268901 |
NEEDLE H Price: $6.99 |
| 501269001 |
501269001 |
SPRING Price: $4.99 |
| 501427101 |
501427101 |
Bushing Price: $1.00 |
| 501466701 |
503117001 |
VALVE/INLET. This part replaces 501466701. Price: $19.99 |
| 501494802 |
501494802 |
DIAPHRAGM SET Price: $17.99 |
| 501527701 |
501527701 |
Price: $86.94 |
| 501576101 |
501576101 |
CHOKE SHAFT AND LEVER Price: $9.99 |
| 501815801 |
501815801 |
SPRING Price: $2.07 |
| 501822601 |
501814401 |
THROTTLE SHAFT This part replaces 501822601. Price: $6.99 |
| 502012201 |
502012201 |
CHOKE FLAP Price: $2.62 |
