| Ref | Part Number | Description |
|---|
| 1 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 1 |
532174620 |
CHASSIS Price: $93.99 |
| 2 |
532180384 |
Drawbar Price: $11.99 |
| 2 |
58-5460 |
VALVE-SELECTOR Price: $479.05 |
| 3 |
340-22 |
FITTING-TEE Price: $90.38 |
| 3 |
817000612 |
Screw Hex Wsh Thdr 3/8-16 x 3/4 This part replaces 817060612. Price: $2.99 |
| 4 |
115-8017 |
REEL MOTOR KIT This part replaces 93-1412. Price: $1,999.51 |
| 5 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 5 |
532155272 |
BUMPER.RUBBER.HOOD Price: $3.99 |
| 6 |
532184419 |
Saddle Price: $8.99 |
| 7 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 8 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 8 |
532126471 |
CLIP,INSULATOR Price: $2.99 |
| 9 |
33014-00 |
NUT-HEX Price: $0.25 |
| 9 |
532194688 |
Price: $78.99 |
| 10 |
48-9530 |
NUT Price: $1.78 |
| 10 |
872110608 |
Bolt, Carriage 3/8-16 x 1 Gr. 5 This part replaces 872140608. Price: $3.99 |
| 11 |
323-6 |
SCREW-HH Price: $0.66 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX Price: $8.99 |
| 12 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 13 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 13 |
532172105 |
PANEL This part replaces 532181719. Price: $14.99 |
| 14 |
340-93 |
TEE-ADAPTER Price: $57.05 |
| 15 |
105-9271-01 |
BRACKET-BUMPER Price: $84.53 |
| 15 |
874180512 |
SCREW Price: $3.99 |
| 16 |
48-3280 |
STOP-BUMP Price: $35.14 |
| 16 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873510500. Price: $2.69 |
| 17 |
532182716 |
Price: $101.99 |
| 17 |
60-0090 |
PIN-PIVOT Price: $93.25 |
| 18 |
532184921 |
BUMPER.HOOD.LARGE.1.75" Price: $3.99 |
| 18 |
60-0190 |
STRIP Price: $36.98 |
| 19 |
33114-016 |
SCREW-HH Price: $0.27 |
| 20 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 21 |
60-0100 |
PIN-PIVOT Price: $94.46 |
| 23 |
68-6480 |
BUSHING-FLANGE Price: $3.19 |
| 24 |
115-8048-01 |
NO. 4 LIFT ARM ASM This part replaces 92-9296-01. Price: $986.93 |
| 24 |
874780616 |
BOLT Price: $3.99 |
| 25 |
325-34 |
SCREW-HH Price: $2.37 |
| 25 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 26 |
58-4380 |
PIN Price: $25.11 |
| 26 |
873680600 |
Nut This part replaces 873800600. Price: $1.99 |
| 27 |
60-1280 |
PIN Price: $3.53 |
| 28 |
532431522 |
Price: $124.99 |
| 28 |
60-1350 |
ROD-PUSH Price: $87.82 |
| 29 |
60-1640 |
STRIP Price: $26.76 |
| 30 |
324-6 |
SCREW-HH Price: $0.81 |
| 30 |
532197364 |
Fender Price: $101.99 |
| 31 |
115-8049-01 |
NO. 5 LIFT ARM ASM This part replaces 92-9297-01. Price: $924.15 |
| 31 |
532165156 |
BRACKET SUPPORT FENDER Price: $4.99 |
| 33 |
323-14 |
SCREW-HH Price: $1.34 |
| 33 |
532182507 |
FOOTREST.LH This part replaces 532179716. Price: $17.99 |
| 34 |
115-8011 |
CYLINDER-HYD This part replaces 104-5225. Price: $784.12 |
| 34 |
532182508 |
FOOTREST.RH This part replaces 532179717. Price: $17.99 |
| 35 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 35 |
872110606 |
BOLT Price: $2.99 |
| 37 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 37 |
817490508 |
Screw, Hex Washer Head Threaded, Rolling 5/16-18 x 1/2 Price: $3.99 |
| 38 |
532181748 |
Bracket Asm Pivot Mower Rear Price: $1.99 |
| 39 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 39 |
532407807 |
BRACKET PIVOT Price: $14.99 |
| 40 |
58-2720 |
PIN Price: $49.81 |
| 41 |
115-8045-01 |
NO. 1 LIFT ARM ASM This part replaces 92-9289-01. Price: $977.54 |
| 42 |
58-9210 |
CAM Price: $92.20 |
| 43 |
60-0080 |
BUSHING Price: $14.79 |
| 44 |
53-5940 |
SCREW Price: $2.90 |
| 45 |
60-1340 |
ROD-PUSH Price: $85.25 |
| 46 |
58-3570 |
SPRING Price: $16.80 |
| 47 |
117-8981 |
BUSHING-RUBBER This part replaces 59-7140. Price: $13.27 |
| 48 |
58-9630 |
SLEEVE Price: $123.35 |
| 49 |
340-17 |
FITTING-ELBOW, 90 DEG Price: $42.29 |
| 50 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 51 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 52 |
93-7331 |
DECAL-WARNING Price: $10.35 |
| 53 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 54 |
3217-6 |
NUT-HEX Price: $1.19 |
| 56 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 57 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 69 |
532142432 |
SCREW.HI-LO.CONSOLE Price: $3.99 |
| 89 |
532197366 |
Console Crd Auto Price: $8.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD Price: $8.99 |
| 162 |
532180382 |
Bracket Exten Chassis Lh CRD Price: $13.99 |
| 163 |
532180383 |
Bracket Exten Chassis Rh CRD Price: $13.99 |
| 164 |
532165605 |
SUPPORT Price: $51.99 |
| 165 |
532181356 |
Cover Battery Price: $4.99 |
| 170 |
532199488 |
Backplate CRD Price: Call Us |
| 171 |
872140620 |
BOLT Price: $3.99 |
| 172 |
819132012 |
Washer 13/32 X 1-1/4 X 12 Ga This part replaces 819132016. Price: $2.99 |
| 173 |
873510600 |
NUT ** Price: $3.99 |
| 175 |
532188203 |
Door Trap Price: $5.99 |
| 179 |
532188202 |
Rod Pivot FBI CRD Price: $2.99 |
| 184 |
532174662 |
Bracket Actuator Bagger CRD Price: $2.99 |
| 185 |
532181101 |
Price: Call Us |
| 186 |
532160793 |
LATCH ASSY Price: $7.99 |
| 187 |
532002029 |
NUT.WELD.#10-24 This part replaces 532125004. Price: $2.69 |
| 188 |
819061216 |
WASHER Price: $2.69 |
| 189 |
810071000 |
LOCKWASHER Price: $2.99 |
| 190 |
871081010 |
SCREW Price: $3.49 |
| 198 |
532168937 |
NUT Price: $2.99 |
| 205 |
817490608 |
SCREW LT Price: $3.99 |
| 207 |
817670508 |
SCREW, 5/16-18 X 1/2 Price: $3.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $2.99 |
| 209 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 212 |
532184248 |
Price: $4.99 |
| 256 |
532181361 |
Cover Fender Rack Price: $3.99 |
| 258 |
532190507 |
Price: $6.99 |
| 259 |
532190508 |
Price: $5.99 |
| 260 |
532408382 |
Price: Call Us |
| 261 |
532408395 |
Price: Call Us |
| 265 |
532185704 |
Seal Side RH Bagger Price: $8.99 |
| 266 |
532185703 |
Seal Side LH Bagger Price: $8.99 |
| 278 |
532416358 |
SCREW.#10 X 0.750.BOS THREAD Price: $2.99 |
