| Ref | Part Number | Description |
|---|
| 1 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 1 |
98-9339 |
GAUGE-FUEL Price: $115.28 |
| 2 |
104-9325 |
SPEEDOMETER KIT,RM5000 SERIES This part replaces 85-4420. Price: $449.92 |
| 2 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 3 |
3290-489 |
KNOB Price: $46.30 |
| 3 |
532180017 |
BEARING, FLANGE Price: $22.99 |
| 4 |
218-498 |
NUT-LOCK Price: $0.68 |
| 4 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 5 |
532435789 |
PLATE.RUBBER.WHEEL.BLACK This part replaces 532199509. Price: $7.99 |
| 5 |
74-5950 |
LATCH-SWELL Price: $21.28 |
| 6 |
585021001 |
RING.RUBBER.4.5".SNOW.DR(2 2MC This part replaces 532179831. Price: $22.99 |
| 7 |
112-6561 |
WARNING LIGHT ASM This part replaces 98-9306. Price: $121.84 |
| 7 |
532178613 |
HUB, RUBBER WHEEL Price: $22.99 |
| 8 |
596322201 |
BOLT HEXAGON BOLT 5/16-18 X 7/ This part replaces 874760514. Price: $2.99 |
| 8 |
98-9308 |
GAUGE-TEMPERATURE Price: $112.90 |
| 9 |
597412801 |
BEARING HOUSING ASSY TRUNNION This part replaces 532175344. Price: $29.99 |
| 9 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 10 |
218-446 |
NUT-HEX Price: $6.09 |
| 10 |
583607301 |
RING.RETAINING. This part replaces 812000012. Price: $2.99 |
| 11 |
218-447 |
WASHER-LOCK Price: $3.79 |
| 11 |
532180066 |
SHAFT.HEX.LONG Price: $84.99 |
| 12 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 12 |
532180065 |
GEAR, PINION Price: $12.99 |
| 13 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 13 |
532192616 |
PLATE.AUXILIARY.BLACK This part replaces 532192907. Price: $4.99 |
| 14 |
532179270 |
SPACER, PLATE Price: $9.99 |
| 14 |
93-6683 |
PANEL - CONSOLE Price: $58.11 |
| 15 |
532441417 |
KIT.GEAR.DRIVE.SNOW This part replaces 532180082. Price: $199.99 |
| 15 |
75-6270-03 |
COVER-BOX, CONTROL This part replaces 75-6270. Price: $87.82 |
| 16 |
532180134 |
SHAFT, AUXILIARY Price: $6.99 |
| 16 |
75-1010 |
SWITCH-REEL Price: $84.90 |
| 17 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 17 |
532405485 |
ARM, AUGER CONTROL Price: $6.99 |
| 18 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 18 |
532057079 |
THRUST WASHER Price: $1.99 |
| 19 |
27-2360 |
SWITCH Price: $46.56 |
| 19 |
532429668 |
KIT.CONTROL.SHAFT.SNOW This part replaces 532427542. Price: $29.99 |
| 20 |
532198580 |
CLEVIS PIN Price: $4.99 |
| 21 |
532184080 |
LEVER, SPEED CONTROL Price: $12.99 |
| 22 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 22 |
532435793 |
BRACKET.SHIFT.PIVOT.BLACK This part replaces 532187857. Price: $5.99 |
| 23 |
532178807 |
PIN, PIVOT Price: $3.99 |
| 23 |
93-7587 |
BRACKET-FUSE BLOCK/PANEL Price: $19.16 |
| 24 |
532180135 |
SPRING, BIAS Price: $3.99 |
| 24 |
75-5740-03 |
BOX-CONTROL ASM This part replaces 75-5740. Price: $261.87 |
| 25 |
532187101 |
LINK, SPEED CONTROL Price: $64.99 |
| 26 |
321-39 |
SCREW-HH Price: $0.42 |
| 26 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 27 |
532700279 |
RETAINER CLIP Price: $2.99 |
| 27 |
94-6767 |
DECAL-FUSES Price: $11.45 |
| 28 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 Price: $4.99 |
| 29 |
3254-20 |
WASHER-LOCK, INT This part replaces 218-589. Price: $1.29 |
| 29 |
532416921 |
PLATE.REAR.SNOW.PNT.ORANGE Price: $11.99 |
| 30 |
532415433 |
BRACKET.SHIFTER.PLATE.BZP Price: $3.99 |
| 31 |
139-5984 |
CONTROLLER-ELECTRONIC This part replaces 92-5720. Price: $2,183.63 |
| 31 |
532416864 |
BRACKET.CLUTCH.PLATE.BZP Price: $3.99 |
| 32 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 32 |
532415450 |
PLATE.SHIFTER.BZP Price: $6.99 |
| 33 |
321-15 |
SCREW-HH Price: $0.61 |
| 33 |
532415435 |
PLATE.CLUTCH.BZP Price: $2.99 |
| 34 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 34 |
532402881 |
BOLT.SHOULDER.3/X.25 Price: $3.99 |
| 35 |
322-3 |
SCREW-HH Price: $0.79 |
| 36 |
3290-354 |
NUT-SPEED Price: $9.99 |
| 37 |
98-2195 |
JOYSTICK Price: $520.10 |
| 38 |
94-8104 |
MICROSWITCH Price: $71.74 |
| 39 |
94-8103 |
DISCONTINUED Price: Call Us |
| 40 |
3290-488 |
DISCONTINUED Price: Call Us |
| 41 |
98-9782 |
LIFT CONTROL KIT Price: $272.96 |
| 45 |
3273-26 |
SCREW-HSH Price: $0.41 |
| 46 |
32144-18 |
SCREW-HWH Price: $1.80 |
| 47 |
120-2244 |
HOURMETER This part replaces 75-6820. Price: $48.06 |
| 50 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 53 |
2412-126 |
R-CLAMP Price: $2.51 |
| 54 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 55 |
32128-33 |
NUT-HF Price: $0.25 |
| 56 |
98-4551 |
HARNESS - ELECTRICAL Price: $1,742.12 |
| 58 |
93-3625 |
SPRING-RETURN Price: $20.57 |
| 59 |
75-5780 |
HINGE-STEEL Price: $18.08 |
| 60 |
93-8744 |
RIVET-BLIND Price: $0.75 |
| 61 |
93-8053 |
DECAL Price: $14.96 |
| 62 |
98-9783 |
TUBE - INTERLOCK Price: $68.65 |
| 63 |
94-3055 |
CAP - LOWER, JOYSTICK Price: $26.29 |
| 64 |
94-3056 |
DISCONTINUED Price: Call Us |
| 65 |
94-3057 |
SPRING-COMPRESS,JOYSTICK Price: $15.18 |
| 66 |
94-3058 |
DISCONTINUED Price: Call Us |
